Explanation of WARNING Symbols
The lightning flash with arrowhead symbol, within an equilateral triangle, is
intended to alert the user to the presence dangerous voltage within the
inside of the product that may be sufficient level to constitute a risk of electric
shock.
The exclamation point within an equilateral triangle is intended to alert the
user to the presence of important operating and servicing instructions.
Safety instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this LCD TV near water.
6) Clean only with dry cloth. Do not use liquid, alcohol, or aerosol cleaners.
7) Do not block any ventilation openings. Install your LCD TV in a well ventilated
area.
8) Keep your LCD TV away from moisture, excessive dust and any heat sources,
such as radiators, heat registers, stoves, or any other apparatus (including
amplifiers) that produce heat.
9) Do not remove the back cover. There are no user-serviceable parts inside.
10) Do not defeat the safety purpose of the polarized or grounding-type plug. A
polarized plug has two blades with one wider than the other. A grounding type plug
has two blades and a third grounding prong. The third prong is provided for your
safety. If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
11) Protect the power cord from being walked on or pinched particularly at plugs,
receptacles, and the point where they exit from the LCD TV.
12) Never rest objects on the power cord or place it in high traffic areas.
13) Only use attachments/accessories specified by the
manufacturer.
14) Use only with stand, tripod, bracket, or table specified by
the manufacturer, or sold with the LCD TV. When a cart is
used, use caution to avoid injury from tip-over.
15) Unplug this LCD TV during lightening storms or when
unused for long periods of time.
16) Refer all servicing to qualified service personnel--
Servicing may be required if the LCD TV has been damaged in any way, such as
power-supply cord or plug damage, liquid has been spilled or objects have fallen
into the LCD TV, the LCD TV has been exposed to rain or moisture, does not
operate normally, or has been dropped.
Advertisement
Table of Contents
Related Manuals for V7 19" LCD TVs LTV19HD
Summary of Contents for V7 19" LCD TVs LTV19HD
-
Page 1: Safety Instructions
Explanation of WARNING Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence dangerous voltage within the inside of the product that may be sufficient level to constitute a risk of electric shock. - Page 2 17) Do not expose your LCD TV to dripping or splashing, and do not place objects filled with liquids on it. 18) The Shock Hazard Marking and Associated Graphical Symbol are provided on the back panel of unit. 19) This product is only to perform the useful function of entertainment and visual display tasks are excluded.
-
Page 3: Table Of Contents
ACCESSORIES... 1 FRONT PANEL BUTTONS ... 2 BACK PANEL BUTTONS... 3 REMOTE CONTROL ... 4 INSTALLATION... 6 Connecting RF antenna and Cable TV ... 6 Connecting to DVD / Set Top Box... 6 Connecting to the Headphone ... 8 Connecting to a Computer... 8 Connecting with the power cord ... -
Page 4: Accessories
ACCESSORIES Thank you for purchasing this LCD-TV. This LCD-TV package comes with: LCD TV User’s Guide Warranty Card Remote control Battery AA x 2 Power Cord VGA Cable RCA A/V Cable... -
Page 5: Front Panel Buttons
FRONT PANEL BUTTONS Volume Down Volume Up On Screen Display Menu On/Off CH Down CH Up Input Source Selection (Enter) Power ON/OFF button Power LED Indicator/ Remote Control Receiver... -
Page 6: Back Panel Buttons
BACK PANEL BUTTONS Power (AC input) Headphone Jack PC/ DVI Audio input VGA signal input Composite Video input YPbPr signal input AV/ S-Video/ YPbPr signal Audio input (left/right) S-Video input HDMI Input Terminal Cable/ Air TV input... -
Page 7: Remote Control
REMOTE CONTROL... - Page 8 Remote control button function as follows: INPUT ENTER - VOL + LIST GUIDE 0~9, - number POWER UP/ DOWN/ LEFT/ RIGHT MENU ▼ ▲ ZOOM MUTE INFO SLEEP LAST Input source select Confirm selection or enter selected menu Direct to TV source Adjust volume UP/DOWN Select channel from program list Select electronic program guide (EPG)
-
Page 9: Installation
INSTALLATION Connecting RF antenna and Cable TV Make sure the power is OFF before installing your LCD TV. 1) AIR TV: Connect the LCD TV to TV antenna with 75-ohm coaxial cable. Preset the air TV channels into memory with Auto Scan function when using an antenna TV system. This air input jack both support TV and DTV systems. - Page 10 2) With S-Video cable: 3) With YPbPr cable: 4) With HDMI cable: S-Video Cable (not supplied) Audio Cable (not supplied) YPbPr Cable (not supplied) HDMI Cable (not supplied) VCD or DVD Player Audio Cable (not supplied) VCD or DVD Player VCD or DVD Player (DVD Player should have the HDMI output terminal)
-
Page 11: Connecting To The Headphone
With HDMI-DVI cable: Connecting to the Headphone Connect the headphone to the headphone output terminal of the LCD TV. (Headphone sold separately). Connecting to a Computer 1) With VGA Cable: Connect the VGA cable from VGA output of the computer to the VGA terminal input of your LCD TV. -
Page 12: Connecting With The Power Cord
2) With HDMI-DVI Cable: Connect the HDMI-DVI cable from the DVI output of the computer to the HDMI terminal input of the LCD TV. Also, connect the Audio In cable (green) from the audio output of your computer to the audio input terminal (green) of the LCD TV. Connecting with the power cord Connect the power cord to the AC inlet on the back of your LCD TV, after all connections have been completed, and plug the other end of the power cord into a correctly grounded electrical... -
Page 13: Basic Operation
BASIC OPERATION To operate your LCD TV, you may use the TV remote control or top panel buttons to select input source, change channels, or adjust volume. Turning on the LCD TV Before using the LCD TV: 1. Connect external equipment properly. 2. -
Page 14: Electronic Program Guide (Epg)
Electronic Program Guide (EPG) Press the GUIDE button on the remote control and the program information for the channel you are watching will be displayed on the screen. * The picture here shows an example of the GUIDE screen in a DTV source. Channel Select Press number key or ▼CH▲... -
Page 15: Favorite Channels
Favorite Channels Press FAV button to show Favorite List and select your favorite channels that have already been stored. (You need to preset the favorite channels from the OSD menu to enable this function.) Sleep Time Setting Repeatedly press SLEEP button to set the off timer. The function is used to automatically shut off the LCD TV after a preset period of time passed. -
Page 16: Advanced Operation-Osd Menu
ADVANCED OPERATION—OSD MENU PICTURE Menu —To adjust the picture quality In TV, AV, S-Video, YPbPr, HDMI source: Note: When in AV, S-Video, YPbPr or HDMI source, the TIME and TV Menu options are disabled. In D-SUB source: Auto Adjust: To auto adjust picture’s horizontal position, vertical position, fine tune and H-Size. (only enabled in D-SUB source) Aspect Ratio: To select image size from Full, 4:3, Movie Scale, or Zoom In. -
Page 17: Sound Menu
Tint: To adjust tint level. Color: To adjust color. (right: brilliant color, left: pale color.) Advance: To adjust advanced D-SUB functions, press ► to enter. (only enabled in D-SUB source) Phase: To adjust delay time of phase in order to reduce the noise of picture. Clock: To adjust clock frequency in order to get optimized horizontal size. -
Page 18: Time Menu
In ATV, AV, S-Video, YPbPr, HDMI, D-SUB source: Bass: To adjust bass. Treble: To adjust the treble. Balance: To adjust left and right audio balance. Audio Language: To select the available audio languages. (only enabled in DTV mode) TIME Menu —To set up time zone It is only active in TV source. -
Page 19: Option Menu
OPTION Menu —To set up OSD window In TV, AV, S-Video source: In YPbPr, HDMI, D-SUB source: OSD Language: To select an OSD language from English, French or Spanish. OSD Timer: To setup the display time of OSD. (5, 10, 15, 25, 40, and 60 seconds) - Page 20 Closed Caption: To set close caption options. CC Mode: To select Closed Caption Mode from Off, On, or CC on Mute. Basic Selection: To set basic analog closed caption options. (CC1~CC4, TEXT1~TEXT4) Advanced Selection: To select closed caption signal formats and set up caption modes for digital TV channels.
-
Page 21: Parent Menu
PARENT Menu —To set up parental control In TV, AV, S-Video, YPbPr, HDMI source: Enter Password: Enter password and the screen below will show. (The default password is 0000.) Change Password: To change the password, press ►, and the screen on the right appears. Follow the instructions to change password. - Page 22 US: Press ► to set TV or MPAA ratings. TV: To adjust TV blocking level in the US. You can select between TV-Y, TV-Y7, TV-G, TV-PG, TV-14, or TV-MA. The TV Ratings in the US are defined as following. TV-Y All children TV-Y7 Directed to older children: this...
- Page 23 Canada: Press ► to set Canadian English and French ratings. Canada Eng: To adjust blocking level in English-speaking region of Canada. You can select between E, C, C8+, G, PG, 14+, 18+. The Canadian English Ratings are defined as following. Exempt Children Children eight years and older...
-
Page 24: Tv Menu
Note: This picture is an example of the content of RRT Setting. However, the selections and sub-selections of RRT Setting may be different in your OSD menu according to the local broadcasting system. Reset RRT: Press ► to reset RRT Setting. TV Menu —To set up for TV It is only active in TV source. - Page 25 Show/Hide Ch.: Press ENTER to skip the selected channel. To restore the channel, press ENTER again. Channel Name: Press ► to edit a name for the current channel. Use ▲▼ to choose letters or signs, ◄► to move forward or backward, and then press MENU or ENTER to exit.
-
Page 26: Technical Specification
TECHNICAL SPECIFICATION Type Color Filter Glass surface Input signal Video Audio Compatibility Resolution Recommended and supported Speaker Output Audio Output Power Voltage Display area Full Scan Operating Temperature conditions Humidity Altitude Storage condition Temperature Humidity Altitude Dimensions Physical Weight Regulations Power saving modes Stand by Preset Timing Mode (Pre-adjusted to GTF®... -
Page 27: Safety Precautions
SAFETY PRECAUTIONS This LCD TV is manufactured and tested to insure the user’s safety. Improper use or installation may result danger to the LCD TV as well as to the user. Carefully go over the following WARNINGS before installation and keep this guide handy. WARNINGS This LCD TV should be operated only at the correct power sources indicated on the label on the rear end of the LCD TV. -
Page 28: Care And Maintenance
CARE AND MAINTENANCE Care Avoid exposing your LCD TV directly to sunlight or other heat source. Place your LCD TV away from the sun to reduce glare. Put your LCD TV in a well ventilated area. Do not place anything heavy on top of your LCD TV. Make certain your LCD TV is installed in a clean and moisture-free area.
