Asha Coffee Table
Assembly Instructions
9
Doors x4
E
G
E
G
E
G
E
H
H
G
E
F
J
Attach 8x wheels (F) and (G) to doors [7] as shown, and secure
with 64x screws (E). Tighten with a screwdriver. Attach 4x handles (J)
to doors [7] and secure with 8x bolt (H). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
E
H
G
H
E
7
F
E
F
J
E
F
7
10
7
7
Note: If the door is not sliding smoothly or
sitting straight, there is a screw in the
middle of the wheel on the bottom of each
door that can be tightened/loosened until
the door is sitting properly.
Attach doors [7] as shown, starting with the back door first and then the
front door. Press the clip down on the back of the door to assemble the
door. Push the clip back up to lock into place. Ensure unit is balanced
and steady before use. You're done, enjoy!
