- Page 1 www.usamps.com Copyright 2007 U.S.Amps. All rights reserved. series series Owners Manual Owners Manual Installation Installation Guide Guide...
-
Page 2: Table Of Contents
Did You Buy the Right U.S.Amp? Installation WARNING Amplifier Mounting Ventilation Amplifier and Crossover Input Signal Level Input Gain Control Adjustment Batteries Getting Wired Amplifier Controls & Features AX-TU600C AX-1000/2000 AX-TU4360C AX-5600 AX-600DE/3200DE Wiring Instructions AX-TU600C/1000/2000 AX-TU4360C AX-5600 AX-600DE AX-3200DE Power &... -
Page 3: Did You Buy The Right U.s.amp
Did You Buy the Right U.S.Amp? There is a U.S.Amp for every purpose! From raw power to exquisite sound quality and everything in between, U.S.Amps offers state-of-the-art technology to meet your every need. INSTALLATION Amplifier Mounting: sure your choice is free from excess heat, moisture, and vibration. Under the vehicle seat or in the trunk are common mounting locations. -
Page 4: Batteries
CARE AND FEEDING OF YOUR BATTERIES As mentioned before, most batteries are built for the relatively light chore of starting the engine. Unless you have the room and ambition to install an upgraded high-powered alternator, your system current requirements may exceed the charging capability of your car’s electrical system. -
Page 5: Ax-Tu600C
For the internal amplifier, adjustable from 50 Hz to 500 Hz @ 12dB. WARNING: All U.S.Amps require a grounded input connection. DO NOT use ground-loop isolation devices or high/low conversion devices on the input of your U.S.Amp! AX-TU600C 2-Channel Amplifiers Controls and Features Full Subsonic... -
Page 6: Ax-1000/2000
(Shown here is AX-1000, but the diagram is also applicable to AX-2000.) Amplifier Input The amplifier MUST receive input on BOTH RCA jacks for proper operation. Amplifier Output The low level output can be connected to other amplifiers. Input Gain is variable from 1 to 9 volts for full output. -
Page 7: Ax-Tu4360C
The AX-4360C features a selectable two-way electronic crossover with independent front and rear mid-high frequency adjustment and 2 ohm per channel stability. Power is provided by four 75 watt channels that can be bridged as front and rear pairs into a 4 ohm load for a total of 180 watts per bridged pair. -
Page 8: Ax-5600
Rear LP Rear HP XOver XOver AX-5600 Five Channel Amplifier U.S.A. DE Sub Channel The AX-5600 comes with an optional “Remote Bass Gain” or “RBG” that AX-5600 5-Channel Amplifier Controls and Features NEVER use ground-loop isolation Front Gain 50 500... -
Page 9: Ax-600De/3200De
INPUT Gain AX-600DE INPUT One Ohm Stable Design (Shown here is AX-600DE, but the diagram is also applicable to AX-3200DE.) Amplifier Input The amplifier MUST receive input on BOTH RCA jacks for proper operation. Input Gain is variable from 150 mV to 3 volts for full output. Best results are achieved by adjusting the control to the lowest setting in relation to the output of the source unit. -
Page 10: Wiring Instructions Ax-Tu600C/1000/2000
Wiring Instructions for AX-TU600C/1000/2000 Power Output AX-TU600C 165W X 2 @ 4Ω 300W X 2 @ 2Ω AX-1000 300W X 2 @ 4Ω 500W X 2 @ 2Ω AX-2000 600W X 2 @ 4Ω 1000W X 2 @ 2Ω Source Unit... -
Page 11: Ax-Tu4360C
11 to 15 volts DC Vehicle Ground – Left Speaker [2 channel Operation] DO NOT OPERATE AX-4360C BRIDGED MONO AT LESS THAN 4Ω PER BRIDGED CHANNEL WARNING: on the input of your U.S.Amp! It doesn’t need it! Front Left Speaker –... -
Page 12: Ax-5600
8-gauge Wire) to Vehicle Ground − Vehicle Battery 11 to 15 volts DC Vehicle Ground (Note: The front and rear channels of the AX-5600) WARNING: on the input of your U.S.Amp! It doesn’t need it! Front Left Speaker Negative 12V... -
Page 13: Special Note
Wiring Instructions for AX-600DE Source Unit Positive 12V Remote Turn-on Negative 12V to Vehicle Ground (Use minimum 8-gauge Wire) − Vehicle Battery 11 to 15 volts DC Vehicle Ground SPECIAL NOTE: Class “DE” amplifiers are single-ended mono designs, and are not bridgeable. BE SURE the TOTAL LOAD of ALL connected speakers does not fall beneath 1Ω. - Page 14 Wiring Instructions for AX-3200DE SPECIAL NOTE: Class “DE” amplifiers are single-ended mono designs, and are not bridgeable. BE SURE the TOTAL LOAD of ALL connected speakers does not fall beneath 1Ω. WARNING: NEVER use ground-loop isolation on the input of your U.S.Amp! It doesn’t need it!
-
Page 15: Ax-600De
U.S.Amps Amplifier Power & Fuse MODEL 4 Ω 300W X 2 AX-1000 600W X 2 AX-2000 75W X 4 AX-5600 250W X 1 AX-600DE 1200W X 1 AX-3200DE 165W X 2 AX-TU600C 75W X 4 AX-TU4360C 150W X 2 AX-2000HC Copyright 2007 U.S.Amps. -
Page 16: Specifications
U.S.Amps Amplifier Specification Bridged MODEL AX-1000 1000W X 1 @ 4Ω AX-2000 2000W X 1 @ 4Ω AX-5600 AX-600DE AX-3200DE 600W X 1 @ 4Ω AX-TU600C 180W X 2 @ 4Ω AX-TU4360C 600W X 1 @ 4Ω AX-2000HC 2000W X 1 @ 1Ω... -
Page 17: Vacuum Tube Current Sync Drive
Why Tubes? You may know that a transistor is a modern, efficient, less expensive version of a vacuum tube, which is the device that made sound recording and reproduction possible in the first place. Now, the electronics industry has been trying for many years to equal the sound quality available from tubes. -
Page 18: Benefits Of Class "De
VTCSD (continued) VTCSD “follows” the high voltage tube signal STRAIGHT INTO THE SPEAKERS, adding only current in a form of “amplifier power steering” — free from voltage gain or negative amplifier feedback! Vaccum tubes are renowned for their high dynamic range and smooth emphasis of even-order harmonics. -
Page 19: Note
NOTE... -
Page 20: Limited Warranty
NEVER, NEVER, NEVER! NEVER USE A U.S.AMP WITH A GROUND LOOP ISOLATOR ON THE RCA’S OR AN ISOLATED INPUT SIGNAL. U.S.Amps are input-isolated at the factory and require an input ground for proper operation. NEVER INSTALL OR MOUNT YOUR AMPLIFIER DIRECTLY TO A SPEAKER ENCLOSURE OR ANYWHERE ELSE WHERE SEVERE VIBRATION IS PRESENT.
