NUUO SCB-C24 User Manual

The intelligent surveillance solution
Hide thumbs Also See for SCB-C24:
Table of Contents

Advertisement

Quick Links

Download this manual
The Intelligent Surveillance Solution
SCB-C24
User Manual
Ver. 1.0.120723.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SCB-C24 and is the answer not in the manual?

Questions and answers

Related Manuals for NUUO SCB-C24

Summary of Contents for NUUO SCB-C24

  • Page 1 The Intelligent Surveillance Solution SCB-C24 User Manual Ver. 1.0.120723.00...

  • Page 2: Table Of Contents

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System TABLE OF CONTENTS TABLE OF CONTENTS ..........................1 1. INTRODUCTION ..........................2 1.1.Key Features ................................. 3 1.2. OS Requirement ..............................4 1.3. Hardware Requirement ............................. 4 1.4. Specification ................................ 5 2. OVERVIEW ............................7 2.1.

  • Page 3: Introduction

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System Introduction C24 is an I/O box to intermediate the communication between a surveillance server and multiple peripherals. It joins up all the major components in your surveillance network to deliver your prospective management and protection over your property.

  • Page 4: Key Features

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 1.1.Key Features Supports wide range of DC-in voltages. Supports ASCII and Modbus/RTU protocols Supports baud rates from 1.2Kbps to 115.2 Kbps. Digital output signal with 3750Vrms isolation protection Supports dual watchdog: Hardware (module) watchdog & software (host) watchdog.

  • Page 5: Os Requirement

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 1.2. OS Requirement 32 bits MS Windows XP pro SP3 / Vista SP1 / Win 7 SP1 64 bits Win 7 SP1/ Win Server 2008 R2 1.3. Hardware Requirement S of all cam...

  • Page 6: Specification

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 1.4. Specification Communication & Data Transmission Protocol ASCII and Modbus RTU Interface RS-485 differential 2 half/duplex wires Speed 1.2Kbps to 115.2Kbps auto-switching Data Format Data bit 8; Parity Check: None; Stop Bit: 1...
  • Page 7 The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System Environment Characteristics Operating Temperature 0 to 65 degrees C Storage Temperature -20 to 65 degrees C Humidity 10~90%, non-condensing...

  • Page 8: Overview

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 2. Overview To apply C24 to your surveillance system, get to know it first. Take a look around C24. The illustration below depicts C24 by top view and side view, with all major components and dimensions called out.

  • Page 9: Pin Definition

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 2.1. Pin Definition Name Description EXT PWR External power for isolation. Max. 30V DC. EXT. GND External ground for isolation. Max. 30V DC. Digital output Channel 10 Digital output Channel 11 Digital output Channel 12...

  • Page 10: Configure Protocol & Self-Test

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 3. Configure Protocol & Self-test C24 supports two protocols, Modbus RTU and ASCII, to communicate with the monitoring peripherals. Which protocol to use is adjustable by the 2-toggle dip-switch on one side of C24 as depicted in Overview.

  • Page 11: Communication Defaults

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 3.1. Communication Defaults In default state, C24 communicates by the following profile: Item Description Protocol Modbus RTU ID address Baud rate 9600 DIO mode type Checksum Disabled RS485 data format  Data bit 8;...

  • Page 12: Back To Initial

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 3.2. Back to Initial The dip-switch supports “Back to Initial”, a function that puts a set of communication settings back to “initial” state in case they cannot be remembered and thus disable C24 from being communicated with.

  • Page 13: Network Deployment Diagram

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 4. Network Deployment Diagram This diagram shows how server, converter (C08), I/O box (C24) are deployed within the surveillance network to work. C08 is subject to connection to maximum 256 I/O boxes (C24/C26/C28), with each I/O box identified by an address ranging from 0~255.

  • Page 14: Hardware Setup

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 5. Hardware Setup This chapter combs through the necessary setup for the major components in the surveillance network including: peripherals, I/O box C24, converter C08, Windows-based server PC. 5.1. Connect C08 to Server PC An average Windows-based PC isn’t capable of RS485 communication.

  • Page 15: Connect C24 To C08

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System 5.2. Connect C24 to C08 After C08 and server are connected and a COM port is up between them, proceed to connect C24 to C08. Connect C08 (TX+, DATA+) to C24 (DATA+). Connect C08 (TX-, DATA-) to C24 (DATA-).

  • Page 16: Configure Mainconsole

    The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System Step 4: IOConfig opens. Step 5: On the left pane of IOConfig, click Scan button. Step 6: IOConfig proceeds to check the COM port, baud rate and address for the connected C24.
  • Page 17 The Intelligent Surveillance Solution NUUO NVR/DVR/Hybrid NDVR System Baud Rate & Address. Step 10: By ID, select the ID address for C24. Step 11: Run Digital Output Simulation. If the graphic in question lights on red, the setup is successfully made.
