- Page 1 用户手册 USER MANUAL Intel H61 Express Chipset ECB-H61102H 400-2009-08 http://www.strontech.com Industrial Leadrt In Embedded Computing...
- Page 2 ECB-H61102H Revision: 1.0 Release date: October 21, 2014 Trademark: * Specifications and Information contained in this documentation are furnished for information use only, and are subject to change at any time without notice, and should not be construed as a commitment by manufacturer.
-
Page 3: Table Of Contents
ECB-H61102H TABLE OF CONTENT ENVIRONMENTAL SAFETY INSTRUCTION ......1 USER’S NOTICE ..............4 MANUAL REVISION INFORMATION ........4 ITEM CHECKLIST ..............4 CHAPTER 1 INTRODUCTION OF THE MOTHERBOARD FEATURE OF MOTHERBOARD ......... 5 SPECIFICATION ............6 LAYOUT DIAGRAM ............ 8 CHAPTER 2 HARDWARE INSTALLATION JUMPER SETTING ............ -
Page 4: Environmental Safety Instruction
ECB-H61102H Environmental Safety Instruction Avoid the dusty, humidity and temperature extremes. Do not place the product in any area where it may become wet. 0 to 60 centigrade is the suitable temperature. (The figure comes from the request of the main chipset) -
Page 5: User's Notice
ECB-H61102H USER’S NOTICE COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE REPRODUCED, TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR BY ANYMEANS WITHOUT WRITTEN PERMISSION OF THE MANUFACTURER. -
Page 6: Chapter 1 Introduction Of The Motherboard
ECB-H61102H Chapter 1 Introduction of the Motherboard 1-1 Feature of Motherboard Intel® H61 express chipset Support LGA 1155 CPU socket Intel® Core™ i7 processors / Intel® Core™ i5 processors / Intel® Core™ i3 processors Support DDRIII 1066/1333/1600 MHz 板载4GB Integrated with Realtek RTL8111G Gigabit Ethernet... -
Page 7: Specification
ECB-H61102H 1-2 Specification Spec Description Design Mini-ITX form factor 6 layers ; PCB size: 17.0x17.0cm Chipset Intel H61 Express Chipset ® ® Support Intel Core™ i7 Processor, Intel Core™ i5 ® Processor, Intel Core™ i3 Processor in the LGA 1155... - Page 8 ECB-H61102H 2 * 9-Pin USB 2.0/1.1 header for four USB 2.0/1.1 ports 8* COM header 2* TX-RXCOM header (Support RS422/RS485 function) 1*Parallel port header 1*GPIO header 1* LVDS inverter header 1 *24-bit Dual Channel LVDS header ...
-
Page 9: Layout Diagram
ECB-H61102H 1-3 Layout Diagram Rear IO Diagram Model-1 RJ-45 LAN Ports Serial Port VGA Port (COM3) Line-IN PS/2 Mouse Port Line-OUT PS/2 MIC-IN Keyboard Port DVI-D Port Serial Port USB 2.0 Ports (COM1) Model-2 RJ-45 LAN Ports VGA Port Line-IN... - Page 10 ECB-H61102H Motherboard Internal Diagram--Front Speaker Header & Power LED Header Parallel Port SYSFAN1 Header INVERTER1 Header Front Panel HDMI Header Serial Port Headers Header USB Headers LVDS1 TX-RX COM Headers SATAII Ports Full-size Half-size GPIO Header MSATA Slot Main Mini-PCIE Slot...
- Page 11 ECB-H61102H Motherboard Internal Diagram--Back - 10 -...
- Page 12 ECB-H61102H Motherboard Jumper Position JCOM4 JCOM10 JBAT1 JCOM3 JCOM1 - 11 -...
- Page 13 ECB-H61102H Jumper Jumper Name Description JBAT1 CMOS RAM Clear Function Setting 3-pin Block INVERTER1 Backlight VCC3.3V/5V/12V Select 4-pin Block LVDS1 VCC 3.3V/5V/12V Select 4-pin Block Mini PCI-E Slot VCC3.3V/3.3VSB Select 3-pin Block KB/MS Power on Function Setting 3-pin Block JCOM3...
- Page 14 ECB-H61102H Headers Header Name Description FP_AUDIO Front Panel Audio Header 9-pin Block HDMI_SPDIF HDMI_SPDIF Out Header 2-pin Block SPEAK_CON External Amplifier Header 4-pin Block JW_FP1 Front Panel Header(PWR LED/ 9-pin Block HD LED/ Power Button /Reset) SPEAK1 Speaker Header 4-pin Block...
-
Page 15: Chapter 2 Hardware Installation
ECB-H61102H Chapter 2 Hardware Installation 2-1 Jumper Setting JBAT1 (3-pin): Clear CMOS Function Setting JBAT 1-2 Closed: Normal; 2-3 Closed:Clear CMOS. JP9 (4-pin): INVERTER1 Backlight VCC 3.3V/5V /12V Select 2-4 Closed: 3-4 Closed: 4-6 Closed: Inverter Backlight Inverter Backlight Inverter Backlight VCC= +3.3V;... - Page 16 ECB-H61102H JP7 (4-pin): LVDS1 VCC 3.3V/5V/12V Select 2-4 Closed: 3-4 Closed: 4-6 Closed: VCC = +3.3V; VCC = +5V; VCC = +12V. JP8 (3-pin): Mini PCI-E Slot VCC3.3V/ SB 3.3 V Select 1-2 Closed ： MINI PCI-E VCC= 3.3V; 2-3 Closed ： MINI PCI-E VCC= 3.3VSB...
- Page 17 ECB-H61102H JP1 (4-pin): KB/MS Power on Function Setting 1-2 Closed: KB/MS Power on Function Disabled(default); 2-3 Closed: KB/MS Power on Function Enabled. JCOM3 (6-pin): COM3 Port Pin9 Function Select JCOM3 2 4 6 2 4 6 1 3 5 1 3 5...
- Page 18 ECB-H61102H JCOM1 (6-pin): COM1 Port Pin9 Function Select JCOM1 2 4 6 2 4 6 1 3 5 1 3 5 2-4 Closed: 3-4 Closed: 4-6 Closed: RI=RS232; RI= +5V; RI= +12V. JCOM4 (6-pin): COM4 Header RS232/485/422 Function Select JCOM4 3-4 Closed : RS485;...
-
Page 19: Connectors And Headers
ECB-H61102H JCOM10 (6-pin): COM10 Header RS232/485/422 Function Select JCOM10 3-4 Closed : RS485; 1-2 Closed: RS232; 5-6 Closed : RS422 Connectors and Headers 2-2-1 Connectors (1) Rear Panel Connectors RJ-45 LAN Ports Serial Port VGA Port (COM3) Line-IN PS/2 Mouse Port... - Page 20 ECB-H61102H (2) SATA1/SATA2(7-pin block): SATA II Port connector These connectors are high-speed SATAII ports that support 3 Gbps transfer rate. Pin No. Defnition (3) ATXPWR (24-pin block): Power Connector - 19 -...
-
Page 21: Headers
ECB-H61102H (4) ATX12V (4-pin block): ATX12V Type Power Connector 2-2-2 Headers (1) FP_AUDIO (9-pin): Line-Out, MIC-In Header This header connects to Front Panel Line-out, MIC-In connector with cable - 20 -... - Page 22 ECB-H61102H (2) HDMI_SPDIF (2-pin): HDMI-SPDIF Out header Pin1 SPDIF HDMI_SPDIF Header (3) SPEAKER_CON (4-pin): External Amplifier Header - 21 -...
- Page 23 ECB-H61102H (4) JW-FP1 (9-pin): Front Panel Header Pin 1 (5) SPEAK1 (4-pin): Speaker Header Pin 1 - 22 -...
- Page 24 ECB-H61102H (6) PWRLED1 (3-pin): PWR LED Header Pin 1 (7) F_USB1/F_USB2 (9-pin): USB Port Headers Pin 1 - 23 -...
- Page 25 ECB-H61102H (8) COM2/4/5/6/7/8/9/10(9-Pin): Serial Port Headers Pin6 Pin1 Pin5 (9) TX-RXCOM4/TX-RXCOM10 (4-Pin): RS422/485 Header Pin 1 - 24 -...
- Page 26 ECB-H61102H (10) PARALLEL (25-pin): Parallel Port Header Pin 14 Pin 1 Parallel Port Header Pin NO. Pin Definition Pin NO. Pin Definition STB- AFD- Pin 1 Pin 2 ERR- Pin 3 Pin 4 INIT- Pin 5 Pin 6 SLIN- Pin 7...
- Page 27 ECB-H61102H (11) GPIO_CON(10-pin): GPIO Header Pin 1 (12) INVERTER1 (6-Pin): LVDS1 Inverter Header Pin No. Definition BKLT_PWR1 BKLT_PWR2 BKLT_EN BKLT_PWM GND1 GND2 - 26 -...
- Page 28 ECB-H61102H (13) LVDS1 (30-Pin): 24-bit Pin 2 Pin 1 LVDS1 Header Pin NO. Pin Define Pin NO. Pin Define Pin 1 LVDS_VCC Pin 2 LVDS_VCC Pin 3 LVDS_VCC Pin 4 Pin 5 Pin 6 Pin 7 LVDSA_DATAN0 Pin 8 LVDSA_DATAP0...
- Page 29 ECB-H61102H (14) SYSFAN1 (3-pin), SYSFAN2 (4-pin), CPUFAN1 (4-pin): FAN Headers Pin1 +12V Fan Power Fan Clock SYSFAN1 Pin1 Pin1 CPUFAN (15) HDMI1 (20-pin): HDMI Header Pin 2 Pin 1 HDMI Header - 28 -...
- Page 30 ECB-H61102H Pin NO. Pin Definition Pin NO. Pin Definition HDMI_TXP2 Pin 1 Pin 2 HDMI_TXP1 HDMI_TXN2 Pin 3 Pin 4 Pin 5 HDMI_TXN1 Pin 6 HDMI_TXP0 Pin 7 Pin 8 Pin 9 HDMI_TXCP Pin 10 HDMI_TXN0 HDMI_TXCN Pin 11 Pin 12...
