- Page 1 Operating Manual For Easy Clicker UR3L-SR4 Universal Remote Control, Inc. www.universalremote.com...
-
Page 3: Replacing Batteries
Introduction This remote control is designed to operate most Digital and Analog Cable Boxes, as well as TVs, and a VCR or DVD player. Replacing Batteries Before you program or operate the remote control, you must install two new AAA alkaline batteries. STEP1 Remove the battery compartment cover from the back of your remote control. -
Page 4: Button Functions
Button Functions Programming the Remote Control. *Note : In this section, when you are instructed to press a [DEVICE] button, that means you should press either the CBL, TV, or DVD button, depending on which device you are programming the remote to operate. Manual Pr ogramming Manual Pr... -
Page 5: Auto Sear Ch Method
STEP1 Turn on the equipment that you want the remote con- trol to operate Cable Box, TV and DVD. STEP2 Press the [DEVICE] button and the [OK/SEL] button simultaneously for three seconds. The corresponding device LED will turn on indicating that it is ready to be programmed. - Page 6 STEP3 Press the [CH+] or [CH-] button one at a time or keep it pressed. The remote will emit a series of Power ON/OFF code signals. Release the [CH+] or [CH-] but- ton as soon as the equipment turns off. *Note : You can verify that you selected the correct code by pressing the [POWER] button.
- Page 7 The Lear ning Method The Lear ning Method STEP1 Press the [COMPONENT] button (CBL, TV or DVD) to be programmed and the [INPUT] buttons simultane- ously for 3 seconds until the Component LED light turns on. STEP2 Line up the UR3L-SR4 to the other remote, head-to- head, 1 or 2 inches apart.
- Page 8 Erasing All Lear Erasing All Lear One Component One Component STEP1 Press the [COMPONENT] and [INPUT] buttons simul- taneously for 3 seconds until the Component LED light turns on. STEP2 Press and hold both the [COMPONENT] button you want to erase and the [PAUSE] button for 5 seconds. The Component LED will blink twice to confirm the erasure.
- Page 9 **Note : The FAV button is not programmable if you have a Digital Cable Box made by Pace, Pioneer or CISCO/SA. STEP1 Press the [CBL] button to select the CBL mode. STEP2 Press the [MACRO] button and [OK/SEL] button simultaneously for 3 seconds. The [CBL] button will turn on for 30 seconds.
- Page 10 Assigning the V Assigning the V ent Device ent Device CBL : TV TV : TV DVD : TV STEP1 Press the [OK/SEL] button and [CBL] button simulta- neously for three seconds. The device LED Will turn on for 30 seconds. The next step must be performed while the LED in on.
- Page 11 Low Batter Low Batter When the battery is low (2.3V-2.0V) and needs to be replaced with fresh batteries, device LED will blink 2 times in sequence whenever a [DEVICE] button is pressed to turn on equipment. Memor y Lock System. Memor y Lock System.
-
Page 12: Set-Up Code Tables
Set-up Code Tables CABLE TV MAKER(BRAND) NAME CISCO/SA MOTOROLA GENERAL INSTRUMENT JERROLD DIGEO DIRECTV MOXI NFUSION PACE PIONEER SAMSUNG TELNET CONVERTER EXPLORER Series 8600X 8600 8540,8570,8590 8500 DCT Series (DVR Model) DCT Series,DCH Series, CFT2200 DL4,DQNV/DRX,DPBB,DPV/DP/DQN,DRZ 027 BMC9012/BMC9022 DSR470 CFT2000 DL4,DQNV/DRX,DPBB,DPV/DP/DQN,DRZ 027 2056-MSX HR20,HR21... - Page 13 MAKER(BRAND) NAME ADMIRAL 072 081 160 161 096 ADVENT AIWA 141 145 AKAI 070 146 004 148 124 226 104 108 AKIO ALARON AMARK 112 127 AMERICA ACTION 043 AMPRO 073 167 ANAM 043 054 056 080 112 131 058 070 004 112 APEX APEX DIGITAL 015 150 037...
- Page 14 MAKER(BRAND) NAME FISHER 007 057 ELECTROBAND ELECTROHOME 024 076 127 ELEMENT 004 110 EMERSON 005 028 043 048 076 096 155 004 051 151 153 154 127 121 ENVISION EPSON 087 228 FUJITSU 164 197 028 157 149 066 217 FUNAI 028 043 052 168 FUTURETECH...
- Page 15 MAKER(BRAND) NAME 004 106 112 127 086 LODGENET LOEWE 196 164 LOGIK LUXMAN 007 015 052 081 160 164 MAGNAVOX 070 003 004 022 059 060 061 063 064 127 164 094 160 056 028 035 211 205 218 050 138 MAJESTIC MARANTZ 164 070 143 169...
- Page 16 MAKER(BRAND) NAME PORTLAND 004 103 127 PRISM PROSCAN 144 160 161 167 PROTON 004 058 171 173 193 127 163 PROTRON 102 213 004 115 PROVIEW PROX QUASAR 034 056 RADIO SHACK 004 019 127 043 160 161 144 156 065 070 004 023 024 056 074 152 081 209 REALISTIC 007 019...
- Page 17 MAKER(BRAND) NAME TATUNG 056 062 TECHNICS 034 080 TECHNOL ACE TECHVIEW TECHWOOD TEKNIKA 002 003 004 024 028 043 072 101 103 164 127 TELERENT TERA THOMPSON TNCI TOSHIBA 015 030 007 040 062 101 142 045 137 TOTEVISION TRUTECH UNIVERSAL 008 009 VIDEO CONCEPTS 146...
- Page 18 MAKER(BRAND) NAME ADCOM AIWA 210 214 AKAI ALPINE APEX DIGITAL 240 197 247 248 196 ARCAM 165 148 AUDIOVOX BOSE 244 245 CAMBRIDGE AUDIO 224 145 CARY AUDIO DESIGN 249 149 CLASSE COBY CYBERHOME 170 212 DAEWOO DENON 184 226 225 DURABRAND EMERSON FUNAI...
- Page 19 MAKER(BRAND) NAME ONKYO 207 236 128 OPPO OPTIMUS ORITRON PANASONIC 076 173 184 219 192 PARASOUND PHILIPS 074 164 176 177 191 195 209 127 PIONEER 175 180 187 221 223 POLAROID 075 084 085 PRIMARE 250 251 PROCEED PROSCAN 188 189 188 189 086 SANSUI...
- Page 20 VCR(DVD) MAKER(BRAND) NAME ADVENTURA AIWA AKAI ANAM AUDIO DYNAMICS 512 543 AUDIOVOX BROOKSONIC CALIX CANON CITIZEN CRAIG 503 602 CURTIS MATHES DAEWOO 512 543 DYNATECH ELECTROHOME ELECTROPHONIC 601 EMERSON 506 645 534 601 629 631 653 FISHER 503 508 FUNAI GARRARD 645 647 644 GO VIDEO...
- Page 21 VCR(DVD) MAKER(BRAND) NAME MEMOREX 601 503 645 534 602 MINOLTA MITSUBISHI 559 513 MOTOROLA 534 602 MULTITECH 512 543 548 NIKKO NORDMENDE OPTIMUS PANASONIC 570 645 667 PENTAX 513 645 PHILCO 645 534 567 PHILIPS 645 567 534 601 PILOT PIONEER 513 548 RADIO SHACK...
- Page 22 VCR(DVD) MAKER(BRAND) NAME VIDEO CONCEPTS 512 534 VIDEOSONIC VILLAIN WARDS 503 513 645 534 602 631 XR-1000 645 534 YAMAHA 512 534 543 ZENITH 548 601 534 558 TV/VCR Combos EMERSON FUNAI GOLDSTAR 601 623 HARLEY DAVIDSON 534 HITACHI JCPENNEY 601 623 LLOYD MAGNAVOX...
- Page 24 OCE-0082A Rev 01...
