Linear iPad 360
Assembly Instructions
A
Front Cover
C
B
Mounting
Rear Housing
Bracket
H
G
Accessible Home
Linear Joining
Button Cover
Bar
L
Non- Accessible
Home Button Cover
P
M5 x 12mm Tamper
Proof Screws
T
8mm Spanner
www.xldisplays.co.uk
D
E
Concrete Raw
Rotating Arm
Plugs
J
I
4.8 x30mm
Cable Holder
Screws
N
M
M6 x 35mm Button
M6 Wing Nuts
Head Screws
Q
R
12mm Washers
14mm Washers
U
V
3mm Allen
Tamper Proof
Key
Key
01733 511030
F
M5 12mm Button
Head Screws
K
M4 x 16mm Socket
Head Cap Screws
O
M5 Nuts
S
M5 x 8mm Tamper
Proof Screws
W
4mm Allen
Key
Advertisement
Related Manuals for XL displays Linear iPad 360
Summary of Contents for XL displays Linear iPad 360
- Page 1 Linear iPad 360 Assembly Instructions 01733 511030 Concrete Raw M5 12mm Button Mounting Rotating Arm Front Cover Rear Housing Head Screws Plugs Bracket M4 x 16mm Socket Accessible Home Linear Joining 4.8 x30mm Cable Holder Head Cap Screws Button Cover...
- Page 2 Linear iPad 360 - Swivel Bracket Assembly Assembly Instructions 01733 511030...
- Page 3 Linear iPad 360 - iPad Housing Assembly Assembly Instructions 01733 511030...
- Page 4 Linear iPad 360 - Desktop Mount Assembly Assembly Instructions 01733 511030 Desktop Mount Hole Dimensions...
- Page 5 Linear iPad 360 Assembly Instructions 01733 511030 Linear Post Mount Assembly Wall Mount Assembly...
- Page 6 Linear iPad 360 - iPad Air Fittings Assembly Instructions 01733 511030...
