Universal Power Group 12V 2A Specification Sheet

Universal power group battery chargers & maintainers specification sheet

Advertisement

Quick Links

Safely charges & maintains 12V lead-acid batteries.
12V 4A SPECIFICATIONS
■ Input Voltage
100-120Vac
■ Input Frequency
47-63 Hz
■ Output Voltage
Fast Charge (Bulk): DC 14.4V
Float DC: 13.6V
■ Output Current
Fast Charge (Bulk): DC 4,000mA
■ Battery Capacity
10-40Ahr (Suggested)
■ Operation Temperature +32°F/O°C to +104°F/40°C
■ Storage Temperature
-4°F to +104°F
FEATURES
■ 3-Stage: Fast Charge stage, Topping Charge stage & Float stage
■ Short-circuit protection: Protects the charger from short-circuit damage
■ Over-current protection: Protects the charger from over-current damage
■ Over-voltage protection: Protects the battery being charged from damage
■ Reverse polarity protection: Protects the charger and battery against incorrectly connected cables
■ Multi-color LED display indicates the charging status
■ Engineered for safe automatic charging
■ Maintains a full charge
■ Built-to-last
■ Compact, light and powerful
Contact Us:
TF 866 . 892 . 1122
P
469 . 892 . 1122
E
sales@upgi.com
UPG # 71708
For Battery Types: Deep Cycle • Starting • Sealed Lead-Acid • Automotive • Marine
12V Chargers
12V 2A & 12V 4A
Battery Chargers & Maintainers
12V 2A SPECIFICATIONS
■ Input Voltage
100-120Vac
■ Input Frequency
47-63 Hz
■ Output Voltage
Fast Charge (Bulk): DC 14.4V
Float DC: 13.6V
■ Output Current
Fast Charge (Bulk): DC 2,000mA
■ Battery Capacity
5-20Ahr (Suggested)
■ Operation Temperature +32°F/O°C to +104°F/40°C
■ Storage Temperature
-4°F to +104°F
Specifications are subject to change without notice.
RvAC118
UPG # 71707
www.upgi.com
VR101606
