Trade-wind ULT2820 Installation Instructions And Use And Care Manual

Trade-wind ULT2820 Installation Instructions And Use And Care Manual

410 cfm ultra series

Advertisement

Quick Links

410 CFM
Ultra Series Models:
ULT2820
ULT2824
ULT2830
ULT2836
CONTENTS:
Part 1 - Planning The
Installation
Part 2 - Electrical Connection
Part 3 - Direction of Vent and
Securing The Hood
Part 4 - Use & Care
Before beginning installation, please thoroughly read and become familiar with these instructions. Installation and
service must be completed by a qualified installer. Failure to properly install this product may void the warranty.
Please leave these installation instructions with the range hood.
Installer:
Please keep these installation instructions for local electrical inspector's use and for future reference.
Owner:
WARNINGS: Must be followed carefully to avoid personal injury
IMPORTANT: Must be followed carefully to avoid damage
TIPS: Contain helpful information
WARNING! TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO
PERSONS OBSERVE THE FOLLOWING:
1. Use this unit only in the manner intended by the manufacturer. If you have any questions, contact the
manufacturer.
2. Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to
prevent power from being switched on accidentally. When the service disconnecting means cannot be locked,
securely fasten a prominent warning device, such as a tag to the service panel.
3. Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable
codes and standards, including fire-rated construction.
Item No. 0AL00-UL-001
Revised 02/02/06
READ AND SAVE THESE INSTRUCTIONS
Copyright (C) 2006, Universal Metal Industries, Inc.
INSTALLATION INSTRUCTIONS &
USE & CARE GUIDE
®
Trade-Wind
Ultra Series Range Hoods
Page 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ULT2820 and is the answer not in the manual?

Questions and answers

Summary of Contents for Trade-wind ULT2820

  • Page 1: Installation Instructions

    3. Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction. Item No. 0AL00-UL-001 Revised 02/02/06 INSTALLATION INSTRUCTIONS & USE & CARE GUIDE Trade-Wind Copyright (C) 2006, Universal Metal Industries, Inc. ® Ultra Series Range Hoods Page 1...
  • Page 2 5. Ducts must be of adequate size and duct runs should be as short as possible. Where turns are necessary, keep turning radius as large and as smooth as possible. Item No. 0AL00-UL-001 Revised 02/02/06 Copyright (C) 2006, Universal Metal Industries, Inc. Page 2...
  • Page 3 Follow all instructions regarding minimum safe clearances and installation location. Failure to do so may result in a safety hazard or fire. To reduce the risk of fire use only metal ductwork. Item No. 0AL00-UL-001 Revised 02/02/06 Copyright (C) 2006, Universal Metal Industries, Inc. Page 3...
  • Page 4 The neutral wire (white) must only be connected to the white neutral wire coming in from the electrical panel. House Electrical Panel Item No. 0AL00-UL-001 Revised 02/02/06 ® hood is supplied with a 5.0 amp variable speed fan Green White 120V Black (L) Hood Copyright (C) 2006, Universal Metal Industries, Inc. Page 4...
  • Page 5 When connected to the back of the hood (horziontal ventilation), be sure the damper swings open from the bottom side; the hinge will be on the top. Otherwise, it will NOT close when the motor is off. Item No. 0AL00-UL-001 Revised 02/02/06 Copyright (C) 2006, Universal Metal Industries, Inc. Page 5...
  • Page 6 McCoys, Lowe’s, Fry’s, Kroger, Albertsons, True Value, Home Depot, etc. Universal Metal Industries, Inc. has a policy of continuous improvements and reserves the right to modify (at any time, without notice) any or all of its products, features, designs, components and specifications. For exact dimensions, see the installation instructions included with each product.
