Ultra Series
Models:
UL2824
UL2830
UL2836
CONTENTS:
Part 1 - Planning The Installation
Part 2 - Electrical Connection
Part 3 - Direction of Vent and
Securing The Hood
Part 4 - Use & Care
Before beginning installation, please thoroughly read and become familiar with these instructions. Installation and
service must be completed by a qualified installer. Failure to properly install this product may void the warranty.
Installer:
Please leave these installation instructions with the range hood.
Owner:
Please keep these installation instructions for local electrical inspector's use and for future reference.
WARNINGS: Must be followed carefully to avoid personal injury
IMPORTANT: Must be followed carefully to avoid damage
TIPS: Contain helpful information
WARNING! TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO
PERSONS OBSERVE THE FOLLOWING:
Use this unit only in the manner intended by the manufacturer. If you have any questions, contact the
manufacturer.
Before servicing or cleaning unit, switch power off at service panel and lock the service disconnecting means to
prevent power from being switched on accidentally. When the service disconnecting means cannot be locked,
securely fasten a prominent warning device, such as a tag to the service panel.
Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable
codes and standards, including fire-rated construction.
Item No. 0AL00-UL-001
Revised 10/05/04
READ AND SAVE THESE INSTRUCTIONS
Copyright (C) 2004, Universal Metal Industries, Inc.
INSTALLATION INSTRUCTIONS &
USE & CARE GUIDE
®
Air-O
Ultra Series Range Hoods
Page 1
Advertisement
Table of Contents
Related Manuals for Air-O Hoods UL2824
Summary of Contents for Air-O Hoods UL2824
-
Page 1: Installation Instructions
Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction. Item No. 0AL00-UL-001 Revised 10/05/04 INSTALLATION INSTRUCTIONS & USE & CARE GUIDE ® Air-O Copyright (C) 2004, Universal Metal Industries, Inc. Ultra Series Range Hoods Page 1... - Page 2 This can create a potential hazard. Consult a licensed ventilation contractor or qualified technician for proper installation of exhaust ducting. Item No. 0AL00-UL-001 Revised 10/05/04 Copyright (C) 2004, Universal Metal Industries, Inc. Page 2...
- Page 3 Follow all instructions regarding minimum safe clearances and installation location. Failure to do so may result in a safety hazard or fire. To reduce the risk of fire use only metal ductwork. Item No. 0AL00-UL-001 Revised 10/05/04 Copyright (C) 2004, Universal Metal Industries, Inc. Page 3...
- Page 4 The neutral wire (white) must only be connected to the white neutral wire coming in from the electrical panel. House Electrical Panel Item No. 0AL00-UL-001 Revised 10/05/04 ® hood is supplied with a 5.0 amp variable speed fan control. Green White 120V Black (L) Hood Copyright (C) 2004, Universal Metal Industries, Inc. Page 4...
- Page 5 When connected to the back of the hood (horziontal ventilation), be sure the damper swings open from the bottom side; the hinge will be on the top. Otherwise, it will NOT close when the motor is off. Item No. 0AL00-UL-001 Revised 10/05/04 Copyright (C) 2004, Universal Metal Industries, Inc. Page 5...
- Page 6 Lowe’s, Menards, Fry’s, Kroger, Ace Hardware, Albertsons, True Value, and Home Depot. Universal Metal Industries, Inc. has a policy of continuous improvements and reserves the right to modify (at any time, without notice) any or all of its products, features, designs, components and specifications. For exact dimensions, see the installation instructions included with each product.
