Summary of Contents for Sonnet M.2 4x4 PCIe Card
- Page 1 Sonnet M. PCIe Card ® Quick Start Guide Windows...
- Page 2 • Mac computer with Thunderbolt 3 or Thunderbolt 2 ports via 3. Click the PCIe Cards link. 4. Click the Sonnet M.2 4x4 PCIe Card link, and then click the a Thunderbolt 3 or 2 to PCIe card expansion system with Manual link.
- Page 3 Handle all electronic components by their edges, and avoid touching connector traces and component pins. 1. Handling the card by its edges, remove the Sonnet M.2 4x4 PCIe Card from its packaging. 2. Place the card upside-down on a flat, level surface (Figure 1).
- Page 4 (Figure 5). Figure 5 10. Holding the heatsink firmly against the card, flip the Sonnet M.2 4x4 PCIe Card over (Figure 7). 11. Secure the heatsink to the card with five of the screws you removed previously (Figure 7); do not overtighten the screws.
- Page 5 Tel: 1-949-472-2772 Windows: (Monday–Friday, 9 a.m.–5 p.m. Pacific Time) Sonnet M.2 4x4 PCIe Card supports RAID 0, RAID 1, RAID 5, and concatenated disk set configurations of SSDs. For Customers Outside North America For support on this product, contact your reseller or local Windows: distributor.
- Page 6 ©2020 Sonnet Technologies, Inc. All rights reserved. Sonnet and the Sonnet logotype are trademarks of Sonnet Technologies, Inc. Mac, the Mac logo, macOS and Mac Pro are trademarks of Apple Inc., registered in the United States and other countries. Thunderbolt and the Thunderbolt logo are trademarks of Intel Corporation in the U.S. and/or other countries. Other...
