- Page 1 30 V - 5 A Power Supply PSD3005 User Manual...
- Page 2 Information in this manual supercede all corresponding previous released material. Scientific continues to improve products and reserves rights to amend part or all of the specifications, procedures, equipment at any time without notice.
-
Page 3: Table Of Contents
General Information…..……………………......8 Safety…..……………………...…………...... 8 Operating Conditions …...……………………..... 8 First Time Operation…..……………………….....9 Operation …..……………………........9 Maintenance ………………………………..….…....11 Power Line Fuse Replacement …………….......11 Dispatch Procedure for............12 Service………………………………..………… .. 12 ....Warranty Conditions..……………..…...….....13 List of Service Centers..……………........14 User Manual PSD3005... -
Page 4: Introduction
A dual 3 digit display for voltage and current are used to read the instantaneous values. In addition to low residual ripple and noise as well as excellent line and load regulation, the PSD3005 is provided with all protective circuits to ensure trouble free operation. User Manual PSD3005... -
Page 5: Technical Specifications
230 V + 10 % , 50-60 Hz (100/120/220/240 V available on request) Operating Condition 0 - 40 C , 95 % RH Dimension W 165 , H 215 , D 360 mm Weight 6.5 kgs. Approx. (Subject to change) User Manual PSD3005... -
Page 6: Front Panel Ontrols
Front Panel Controls 30.0 30.0 3.00 5.00 POWER 30V, 5A POWER SUPPLY PSD3005 FINE COARSE Iset 30V/5A User Manual PSD3005... - Page 7 ON , other wise trips again. If the tapping is at 230 V , and mains goes beyond 245 V approx. Instrument will trip and shows HV , in such cases use tapping at 240 V . User Manual PSD3005...
-
Page 8: Operating Instructions
+ 40 C and should not exceed. - 40 C or + 70 C during transport or storage. The ° ° ° operational position is optional, however, the ventilation holes on the PSD3005 must not be obstructed. Prior to calibration a preheat run of approx. 30 minutes is required. User Manual PSD3005... -
Page 9: First Time Operation
ON the power ON is indicated by liting of displays. Operation The power supply has an electrically floating output. This permits easy series or parallel connection with other power supply units, to increase supply voltage or current respectively. PSD3005 Fixed Output voltage operation 30.0 30.0 3.00 5.00... - Page 10 , it trips and LED “ ” is lit. After the mains normalized, switch OFF once the instrument and then switch ON again, if the mains is below 253 V, the instrument get switched ON , other wise trips again. User Manual PSD3005...
-
Page 11: Maintenance
. The rating of the fuse is 3 A , 250 V, sloblow , 5x20 mm glass fuse. Do not use a fuse with a higher value other wise it may damage the instrument in case, the mains voltage goes much higher than the rating of the mains fluctuation of 10%. ± User Manual PSD3005... -
Page 12: Dispatch Procedure For
Dispatch the instrument (only on the receipt of our advise) securely packed in original packing duly insured and freight paid along with accessories and a copy of the faults details noticed at our Service Center listed on last page of this manual, nearest to you. User Manual PSD3005... -
Page 13: Warranty Conditions
Warranty Conditions Scientific warrants all its Instruments to be free from defects in material and workmanship when used under normal operating conditions in accordance with the instructions given in the manual for a period of 12 (Twelve) months from date of purchase from Scientific or its authorised dealers. The service during the warranty period will be rendered on return to factory /service center basis. -
Page 14: List Of Service Centers
Notes User Manual PSD3005... - Page 15 Notes User Manual PSD3005...
- Page 16 Major Service Centers Phone / Fax / Email Scientific Mes-Technik Pvt. Ltd., Ph : (0731) 2309741,2422330-31 92, Electronics Complex, Fax :(0731)2422334, 2561641 Pardeshipura, info@scientificindia.com Indore M. P. 452 010 Scientific Mes-Technik Pvt. Ltd., Ph : (011) 65638100, 65638101 B-13, D.S.I.D.C Packging Complex...
