King/Ashley Pellet Stove
Please read this entire manual before installation and use of this appliance. Failure to follow
these instructions could result in property damage, bodily injury, or even death.
Contact your local building or fire officials about restrictions and installation inspection
requirements in your area.
Save these instructions.
UNITED STATES STOVE COMPANY • 227 INDUSTRIAL PARK ROAD • SOUTH PITTSBURG, TENNESSEE 37380 • WWW.USSTOVE.COM
USSC
UNITED STATES STOVE COMPANY
Owner's Manual
FOR TECHNICAL ASSISTANCE:
PelletKing.com
"Keeping North America Warm Since 1869"
PHONE: (800) 750-2723
model 5500/5500XL
model 5500/5500XL
model 5500/5500XL
model 5500/5500XL
model 5500/5500XL
FAX: (423) 837-2109
Part No.: 851641
1
Advertisement
Table of Contents
Related Manuals for USSC 5500/5500XL
Summary of Contents for USSC 5500/5500XL
- Page 1 Contact your local building or fire officials about restrictions and installation inspection requirements in your area. Save these instructions. UNITED STATES STOVE COMPANY • 227 INDUSTRIAL PARK ROAD • SOUTH PITTSBURG, TENNESSEE 37380 • WWW.USSTOVE.COM FOR TECHNICAL ASSISTANCE: USSC “Keeping North America Warm Since 1869”...
-
Page 2: Table Of Contents
TABLE OF CONTENTS ... 2 SAFETY PRECAUTIONS ... 3 SPECIFICATIONS ... 4 Heating Specifications ... 4 Dimensions ... 4 Electrical Specifications ... 4 Fuel Considerations ... 4 Safety and EPA Compliance ... 4 INSTALLATION ... 5 Installation Options... 5 Floor Protection ... 5 Clearances ... -
Page 3: Safety Precautions
IMPORTANT: Read this entire manual before installing and operating this product. Failure to do so may result in property damage, bodily injury, or even death. Proper installation of this stove is crucial for safe and efficient operation. Install vent at clearances specified by the vent manufacturer. -
Page 4: Specifications
Heating Specifications Heat Output Heating Capacity Fuel Burn Rate Burn Time (lowest setting) Hopper Capacity BTU output will vary depending on the quality of fuel. Use PFI listed fuels for the best results. Heating capacity will vary depending on floor plan layout of your home, degree of insulation, and the outside temperature. Pellet size may effect the actual rate of fuel feed and burn times. -
Page 5: Installation
INSTALLATION OPTIONS Read this entire manual before you install and use your King/Ashley stove. Failure to follow instructions may result in property damage, bodily injury, or even death! (See specific installation details for clearances and other installation requirements) A Freestanding Unit—supported by pedestal/legs and placed on a non-combustible floor surface in compliance with clearance requirements for a freestanding stove installation. -
Page 6: Clearances
CLEARANCES Your King/Ashley stove has been tested and listed for installation in residential, mobile home, and alcove applications in accordance with the clearances given in FIGURES 3-5 and TABLE 1. NOTE: Distance “C” on the left-hand side of your King/Ashley stove may need to be greater than the minimum required clearance for suitable access to the control panel. -
Page 7: Venting Requirements
VENTING REQUIREMENTS Install vent at clearances specified by the vent manufacturer. Do not connect the pellet vent to a vent serving any other appliance or stove. Do not install a flue damper in the exhaust venting system of this unit. The following installation guidelines must be followed to ensure conformity with both the safety listing of this stove and to local building codes. -
Page 8: Vent Termination Clearances
VENT TERMINATION CLEARANCES: Minimum 4-foot clearance below or beside any door or window that opens. Minimum 1-foot clearance above any door or window that opens. Minimum 3-foot clearance form any adjacent building. Minimum 7-foot clearance from any grade when adjacent to public walkways. Minimum 2-foot clearance above any grass, plants, or other combustible materials. -
Page 9: Through The Wall Installation
Installation THROUGH THE WALL INSTALLATION (RECOMMENDED INSTALLATION) To vent the unit through the wall, connect the pipe adapter to the exhaust motor adapter. If the exhaust adapter is at least 18-inches above ground level, a straight section of pellet vent pipe can be used through the wall. Your King/Ashley dealer should be able to provide you with a kit that will handle most of this installation, which will... -
Page 10: Outside Air Supply
OUTSIDE AIR SUPPLY (optional) Depending on your location and home construction, outside air may be necessary for optimal performance. Metal pipe (solid or flexible) must be used for the outside air installation. PVC pipe is NOT approved and should NEVER be used. -
Page 11: Operation
Do not operate your stove with the viewing door open. The auger will not feed pellets under these circumstances and a safety concern may arise from sparks or fumes entering the room. This heater is designed and approved for premium hardwood pellet fuel only. Any other type of fuel burned in this heater will void the warranty and safety listing. -
Page 12: Control Panel
CONTROL PANEL Turning the stove OFF/ON, as well as adjustments for the fuel feed rate and room air fan speed are performed by pressing the appropriate button(s) on the control panel which is located on the lower left-hand side of your King/Ashley stove (see FIGURE 10). -
Page 13: Start-Up Procedure
START-UP PROCEDURE Never use gasoline, gasoline-type lantern fuel, kerosene, charcoal lighter fluid, or similar liquids to start or “freshen up” a fire in this stove. Keep all such liquids well away from the stove while it is in use. Verify that the hopper is clean and free of foreign matter. Verify that all of the required exhaust/inlet connections have been made in accordance with this manual and that the stove is plugged into an outlet (an outlet surge protector is highly recommended). -
Page 14: Daily Operation
DAILY OPERATION The hopper and stove top will be hot during operation; therefore, you should always use some type of hand protection when refueling your stove. Never place your hand near the auger while the stove is in operation. This unit should be filled when the hopper level drops below 3-inches. In the event of a power outage, the stove WILL NOT function. -
Page 15: Interior Chambers
Maintenance INTERIOR CHAMBERS Periodically remove and clean the burnpot and the area inside the burnpot housing. In particular it is advisable to clean out the holes in the burnpot to remove any build up that may prevent air from moving through the burn pot freely. If a vacuum is used to clean your stove, we suggest using a vacuum designed for ash removal. -
Page 16: Trouble Shooting
Disconnect the power cord before performing any maintenance! NOTE: Turning the ON/OFF Switch to ”OFF” does not disconnect all power to the electrical components of the stove. Never try to repair or replace any part of the stove unless instructions for doing so are given in this manual. All other work should be done by a trained technician. -
Page 17: Repair Parts Diagram/List
Parts Diagram model 5500 and 5500XL Note: All repair parts (other than Cabinet Sides, Hopper Assy., and Door Assy.) are same for models 5500 and 5500XL. PelletKing.com USSC... -
Page 18: Repair Parts List
Parts Diagram/List models 5500 & 5500XL Model 5500 Item Part No. Title 25490 Door Weldment 891166 Ceramic Glass 891185 Glass Retainer, Top 891186 Glass Retainer, Bottom 891160 Handle, Door 891168 Latch, Door 88082 3/4” Rope Gasket Model 5500XL Item Part No. Title 25266 Feed Door 891067... -
Page 19: Wiring Diagram
Item Part No. Title 86624 Burnpot Assembly 86625 Housing Assy, Burnpot 86628 Weldment, Exhaust Duct 86633 Weldment, Igniter Tube 80481 Igniter Cartridge 25506 Weldment, Door Hinge 69512 Door Assembly 69518 Hopper Assembly (5500) 69522 Hopper Assembly (5500XL) 891164 Weldment Auger Housing 69513 Assy., Bushing Retainer Bottom 10.1... - Page 20 1. THE PART NUMBER 2. THE PART DESCRIPTION 3. THE MODEL NUMBER: 5500 4. THE SERIAL NUMBER:____________________ HOW TO ORDER REPAIR PARTS United States Stove Company 227 Industrial Park Road P.O. Box 151 South Pittsburg, TN 37380 (423) 837-2100 WWW.USSTOVE.COM PelletKing.com...
