Gebwell Aries User Manual

Ground source heat pump
Hide thumbs
Table of Contents

Advertisement

Quick Links

User Manual
Aries Ground Source Heat Pump
WWW.GEBWELL.COM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aries and is the answer not in the manual?

Questions and answers

Related Manuals for Gebwell Aries

Summary of Contents for Gebwell Aries

  • Page 1 User Manual Aries Ground Source Heat Pump WWW.GEBWELL.COM...

  • Page 2: Table Of Contents

    MARKING: The CE mark is the manufacturer’s declaration that the product conforms to EU legal requirements. Gebwell Ltd affirms that the product meets all of the requirements of relevant EU directives. The purpose of the CE mark is to facilitate the free movement of goods on the internal market in Europe.

  • Page 3: Warranty

    1 WARRANTY Gebwell Ltd Patruunapolku 5, 79100 LEPPÄVIRTA, Finland, tel. +358 20 1230 800, info@gebwell.fi issues this product, Aries ground source heat pump with the following warranty regarding manufacturing and material faults. This warranty has been given on the condition that the product is...
  • Page 4 Some features of the Aries heat pump require a mobile data con- service request, the following things must be taken into considera- nection (such as 3G or 4G). If Aries is installed at a site with a tion: poor or non-existent mobile data connection, Gebwell cannot guarantee the proper operation of all the features (such as remote •...
  • Page 5 GEBWELL ARIES – A FINNISH INVERTER GROUND SOURCE HEAT PUMP Gebwell Ltd is a Finnish manufacturer of heat pumps and Gebwell Aries is an advanced heat pump for heating buildings and hot domestic water. Aries’ compressor is frequency-controlled, so the heat pump adapts automatically to your house’s energy needs.

  • Page 6: Operating The Aries Ground Source Heat Pump

    Some features of the Aries heat pump require a mobile With the application you can control Aries either via heat data connection (such as 3G or 4G). If Aries is installed at a site with a poor or non-existent mobile data connection, pump’s WLAN (Wifi) or remotely.
  • Page 7 ANDROID operating system 2. Turn on Wifi (switch to  3. Select “Security” and select ON-position) and select ”Add “WPA/WPA2”. network…” Enter the network name and password. These details are shown on the ID plate on the inner side of the heat pump’s door (Network name: SSID, password: Wifi Key).
  • Page 8 3. Go to front page of Wifi  4. Open Additional information settings and choose Wifi set- menu tings  5. Open Connect automatical- 6. Turn off the automatic con- ly -menu nection to Wifi networks (slid- ers to off position) Gebwell Aries user manual...

  • Page 9: The Aries Ground Source Heat Pump Id Plate

    The Aries heat pump user interface is an application downloaded on a smart device. The app is available for smart devices using Android or iOS operating systems. You can download the app on the Google Play store for Android devices and the App Store for iOS devices.

  • Page 10: Registering As Gebwell Smart User

    Note! Username is the e-mail address you gave at the regis- tration. 2.5 LOGGING INTO THE GEBWELL SMART APP Note! When logging into the application your smart device must be connected to the Internet.  1. Choose Login. Read and 2.

  • Page 11: Connecting To Heat Pump's Wifi Network

    2.6 CONNECTING TO HEAT PUMP’S WIFI NETWORK NOTE! If you want to control Aries remotely, you do not have to do this, go directly to page 12. Turn off all the network connections on your smart device (mobile data / Wifi network, you used in logging in the applica- tion) and connect to heat pump’s Wifi network.

  • Page 12: Controlling Aries Heat Pump With Gebwell Smart Application

    1. Connection status Cloud symbol indicates that the application connected to the Aries heat pump remotely. Wifi symbol indicates the app is connected to heat pump’s WLAN (Wifi). A line across the symbol indicates that there is no connection to Aries momentarily.

  • Page 13: Home/Out Of Home Setting

    3.2 HOME/OUT OF HOME SETTING You can set different heating and domestic water heating functions for when you are at home and when you are out of home for a longer period of time e.g. on a holiday or a business trip. ...

  • Page 14: The App's Main Menu

    This screen allows you to add/edit users or details of the device(s) connected to the account. Adding a user / editing user information Additional user must first download the Gebwell Smart application and regis- ter as a user (see page 10). ‘Additional user’ is chosen as User level in this case.

  • Page 15: System

    3.5 SYSTEM This screen shows your system’s functions in more detail. Outdoor temperature: The temperature indicated by the outdoor temperature sensor connected to the system Domestic water: The temperature of the water in the domestic water reservoir Supply water - heating: The temperature of the water going to the heating circuit Supply water - Domestic water charge: The temperature of the water going to the domestic water reservoir...

  • Page 16: Measurements

     1. Measurement data can be 2. You can set measurement shown by tapping the arrow data in Favourites by tapping next to the group. the button at the end of the row, turning it green. Gebwell Aries user manual...

  • Page 17: Events

    3.8 EVENTS The screen lists events related to the device, Active events shown Active tab and event history on All tab. Events listed: Alerts Restarts Fault reports Service requests sent by users The maintenance operations that have been carried out 3.9 SETTINGS The settings menu allows you to adjust the device’s settings.
  • Page 18 Transferring the adjustment curve horizontally so that the gradient of the curve does not change Supply water set point (C°) Setting the limits for heating supply water temperature set points Effect of the room temperature sensor (%) Setting the room temperature sensor’s effect on the heating Gebwell Aries user manual...
  • Page 19 CHANGING THE ADJUSTMENT CURVE  1. Select the heating circuit 3. Adjust the control curve by whose settings you want to selecting a point to change and change using the ± selection. 2. Select the adjustment 4. Remember to confirm your curves.
  • Page 20 3. Select the day of the week cleaning function on by slid- for cleaning. ing the on/off toggle to the Go to time selection by click- right ing the selected day for clean- ing. 4. Select the time. 5. Confirm the changes Gebwell Aries user manual...
  • Page 21 DEVICE MANAGEMENT Device status Automation The device is operating normally Stop The device has stopped Emergency use The device is using the electric heater without the compressor and collection pump Restart Restarting the device ADVANCED SETTINGS Note that if adjustments are not made with care, they may lead to damage to your heating device. ...

  • Page 22: Support And Servicing

    Only in case of disturbances SUPPORT AND SERVICING This screen allows you to contact customer support or servicing. Phone call You can call Gebwell Ltd.’s customer service directly. Order servicing You can order servicing for your device. USER GUIDE The screen will display the user guide, which reviews the app’s functionality in detail.

  • Page 23: Energy Labels

    ENERGY LABELS v1-8 28012020...
  • Page 24 Products are provided with a CE marking of conformity. Produkterna är försedda med CE-märkning av överensstämmelse. Leppävirta 30.10.2019 Tuure Stenberg Managing Director Gebwell Ltd. | Patruunapolku 5, FI-79100 Leppävirta, FINLAND | Tel. +358 20 1230 800 | info@gebwell.fi | www.gebwell.fi...

  • Page 25: Id Plate Of Your Aries Heat Pump

    ID PLATE OF YOUR ARIES HEAT PUMP: On the plate you can find e.g. the serial number of your heat pump, which is needed when registering as a user of Gebwell Smart application. Gebwell Ltd. Patruunapolku 5, FI-79100 Leppävirta, FINLAND Customer service Tel.
