MULTI-FUEL FURNACE
Owner's Manual
Please read this entire manual before installation and use of this appliance. Failure to follow
these instructions could result in property damage, bodily injury, or even death.
Contact your local building or fire officials about restrictions and installation inspection
requirements in your area.
Save these instructions.
UNITED STATES STOVE COMPANY • 227 INDUSTRIAL PARK ROAD • SOUTH PITTSBURG, TENNESSEE 37380 • WWW.USSTOVE.COM
FOR TECHNICAL ASSISTANCE:
PHONE: (800) 750-2723
FAX: (423) 837-2109
Part No.: 851566
USSC
1
Advertisement
Table of Contents
Related Manuals for USSC American Harvest 6100
Summary of Contents for USSC American Harvest 6100
- Page 1 Contact your local building or fire officials about restrictions and installation inspection requirements in your area. Save these instructions. UNITED STATES STOVE COMPANY • 227 INDUSTRIAL PARK ROAD • SOUTH PITTSBURG, TENNESSEE 37380 • WWW.USSTOVE.COM FOR TECHNICAL ASSISTANCE: PHONE: (800) 750-2723 FAX: (423) 837-2109 Part No.: 851566...
-
Page 2: Table Of Contents
TABLE OF CONTENTS ... 2 SAFETY PRECAUTIONS ... 3 SPECIFICATIONS ... 4 Heating Specifications ... 4 Dimensions ... 4 Electrical Specifications ... 4 Safety and EPA Compliance ... 4 Fuel Considerations ... 5 INSTALLATION ... 5 Installation Options... 6 Floor Protection ... 6 Clearances ... -
Page 3: Safety Precautions
IMPORTANT: Read this entire manual before installing and operating this product. Failure to do so may result in property damage, bodily injury, or even death. Proper installation of this furnace is crucial for safe and efficient operation. Install vent at clearances specified by the vent manufacturer. -
Page 4: Specifications
Heating Specifications Heat Output Heating Capacity Fuel Burn Rate Burn Time (lowest setting) Hopper Capacity BTU output will vary depending on the quality and type of fuel. Use PFI listed fuels for the best results. Heating capacity will vary depending on floor plan layout of your home, degree of insulation, and the outside temperature. Fuel size may effect the actual rate of fuel feed and burn times. -
Page 5: Fuel Considerations
SHELLED CORN • Optimum moisture content of corn should be 11% or less. Wet corn will rapidly deteriorate furnace components, reduce efficiency and void all warranties. Purchase a moisture tester if in doubt. • Corn must be clean and free from debris. Never burn corn right from the field. Damage caused by dirty corn is not covered by the product warranty. -
Page 6: Installation
INSTALLATION OPTIONS Read this entire manual before you install and use your Multi-Fuel Furnace. Failure to follow instructions may result in property damage, bodily injury, or even death! (See specific installation details for clearances and other installation requirements) As a Primary Furnace—the unit functions independently of any other system. The “Room Air” blowers will come on when the plenum and Exhaust temperatures reach a preset point on the furnace’s circuit board (PCB). -
Page 7: Clearances
CLEARANCES NOTE: Distance on the left-hand side of your Multi-Fuel Furnace is set at 24 inches for suitable access to the control panel and for fuel loading. This distance may be less, but not less than 7 inches. USSC Installation... -
Page 8: Venting Requirements
VENTING REQUIREMENTS Install vent at clearances specified by the vent manufacturer. Do not connect the pellet vent to a vent serving any other appliance or furnace. Do not install a flue damper in the exhaust venting system of this unit. The following installation guidelines must be followed to ensure conformity with both the safety listing of this furnace and to local building codes. -
Page 9: Vent Termination Clearances
VENT TERMINATION CLEARANCES: A ----- Minimum 4-foot clearance below or beside any door or window that opens. B ----- Minimum 1-foot clearance above any door or window that opens. C ----- Minimum 3-foot clearance from any adjacent building. D ----- Minimum 7-foot clearance from any grade when adjacent to public walkways. -
Page 10: Through The Wall Installation
THROUGH THE WALL INSTALLATION To vent the unit through the wall, connect the pipe adapter to the exhaust motor adapter. If the exhaust adapter is at least 18-inches above ground level, a straight section of pellet vent pipe can be used through the wall. Your furnace dealer should be able to provide you with a kit that will handle most of this installation, which will wall thimble that will allow the proper clearance through a combustible wall. -
Page 11: Primary And Secondary Furnace Illustrations
Installation PRIMARY FURNACE SECONDARY (ADD-ON) FURNACE When installed as a seondary furnace, a Duct Damper must be installed between the air discarge of the Pellet furnace and the primary (Gas, Electric, etc.). Damper must be an electric style damper in order to connect to the multi fuel furnace’s PCB (Printed Circuit Board). -
Page 12: Operation
Do not operate your furnace with the viewing door open. The auger will not feed fuel under these circumstances and a safety concern may arise from sparks or fumes entering the room. A working smoke detector must be installed in the same room as this product. Hopper Lid must be closed during operation. -
Page 13: Control Panel
Operation CONTROL PANEL Turning the furnace OFF/ON, as well as adjustments for the fuel feed rate and room fan speed are performed by pressing the appropriate button(s) on the control panel which is located on the lower left-hand side of your American Harvest furnace. -
Page 14: Unit Preparation
UNIT PREPARATION After carefully unpacking and reading the instructions for installing your furnace, you will need to perform the following steps: Attach the included spring handle to the door handle by screwing it on in a respective location. Attach the electrical cord to the back of the furnace first; then plug it into a 110-volt outlet (an outlet surge protector is highly recommended). -
Page 15: Daily Operation
DAILY OPERATION The hopper and furnace top will be hot during operation; therefore, you should always use some type of hand protection when refueling your furnace. Never place your hand near the auger while the furnace is in operation. In the event of a power outage, the furnace WILL NOT function. It is very important that unit be vented properly, as the natural draft is needed to clear the smoke from the furnace during a power outage. -
Page 16: Interior Chambers
Maintenance INTERIOR CHAMBERS Remove the two(2) cleanout plates on each side of the damper control. Using the cleaning tools provided, clean all ash and fuel matter from the burn chamber. This may need to be done daily depending on fuel consumption. Periodically remove and clean the burnpot and the area inside the burnpot housing. -
Page 17: Repair Parts Diagram & List
Parts Diagram USSC... -
Page 18: Parts List
Item Part No. Title 891282 Assembly, Hopper 891267 Access Panel, Back 891266 Filter Guide, Bottom 891265 Filter Guide, Top 891287 Assembly, Lid 891247 Assembly, Top Cover 891292 Side Panel, Right 891251 Weld., Left Side Panel 69524 Assembly, Feed Door 25080 Latch, Door 83508 5/16-18 x 3/4 Bolt... -
Page 19: Wiring Diagram
Wiring Diagram USSC... -
Page 20: Trouble Shooting
Disconnect the power cord before performing any maintenance! NOTE: Turning the ON/OFF Switch to ”OFF” does not disconnect all power to the electrical components of the furnace. Never try to repair or replace any part of the furnace unless instructions for doing so are given in this manual. -
Page 21: Error Codes
Below is a chart describing the Error Codes that might be displayed if your unit has the Type B controller. Error Error Code Descrption Err1 The high limit temperature sensor has tripped. Err2 Furnace ran out of fuel during normal operation. -
Page 22: Notes
Notes USSC... - Page 23 Notes USSC...
- Page 24 WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFOR- MATION AS SHOWN IN THIS LIST: 1. THE PART NUMBER 2. THE PART DESCRIPTION 3. THE MODEL NUMBER: 6100 4. THE SERIAL NUMBER:____________________ United States Stove Company 227 Industrial Park Road P.O.
