Owner's Operation and Instruction Manual
US ENVIRONMENTAL PROTECTION
AGENCY PHASE II CERTIFIED
WOODSTOVE
CAUTION!
Read All Instructions Carefully
Before Starting The Installation
or Operating This Heater.
Improper Installation Could Void
Your Warranty!
THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU
TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.E
Ussc
SAFETY NOTICE:
If this heater is not properly installed, a house fire may
result. For your safety, follow the installation instruc-
tions. Contact local building or fire officials about
restrictions and installation requirements in your area.
SAVE THIS MANUAL FOR FUTURE REFERENCE
Manufactured by:
United States Stove Company
227 Industrial Park Road
South Pittsburg, TN 37380
Licensed by: Drolet Stoves and Fireplaces Inc.
P.O. Box 151
Model 2015
TESTED TO
UL 1482
&
ULC - S627
C
R
851573A
U S
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for USSC 2015
Summary of Contents for USSC 2015
- Page 1 THIS MANUAL WILL HELP YOU TO OBTAIN EFFICIENT, DEPENDABLE SERVICE FROM THE HEATER, AND ENABLE YOU TO ORDER REPAIR PARTS CORRECTLY. KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.E United States Stove Company Licensed by: Drolet Stoves and Fireplaces Inc.
- Page 2 You've purchased a heater from North America's oldest manufacturer of wood burning products. By heating with wood you're helping to CONSERVE ENERGY! Wood is our only Renewable Energy Resource. Please do your part to preserve our wood supply. Plant at least one The instructions pertainning to the installation of your wood stove comply ULC-S627 and UL-1482 standards.
- Page 3 ASSEMBLY Leg Assembly: 1. Remove the firebrick form the unit. Tilt the unit on its side. DO NOT tilt the unit on its back, this could possibly bend or distort the blower chute on the back of the unit. 2. Remove the four(4) Lag Screws holding the two boards to the unit. 3.
-
Page 4: Blower Assembly
BLOWER ASSEMBLY ASSEMBLY INSTRUCTIONS THE BLOWER ASSEMBLY MUST BE DISCONNECTED FROM THE SOURCE OF ELECTRI- CAL SUPPLY BEFORE ATTEMPTING THE INSTALLATION. Step 1. Fix the assembly to the back of the stove with the four screws provided. HE BLOWER ASSEMBLY IS INTENDED FOR USE ONLY WITH A STOVE THAT IS MARKED TO INDICATE SUCH USE. -
Page 5: Installation
INSTALLATION SAFETY NOTICE • IF THIS STOVE IS NOT PROPERLY INSTALLED, A HOUSE FIRE MAY RESULT. TO REDUCE THE RISK OF FIRE, FOLLOW THE INSTALLATION INSTRUCTIONS. FAILURE TO FOLLOW INSTRUCTIONS MAY RESULT IN PROPERTY DAMAGE, BODILY INJURY, OR EVEN DEATH. •... -
Page 6: Floor Protector
FLOOR PROTECTOR Your wood stove should be placed on a non-combustible surface with a R value of 1.0. For multiple layers, add R-values of each layer to determine the overall R-value. The floor protector should be under the stove, eighteen inches beyond the front and eight inches beyond each side of the fuel loading and ash removal opening. -
Page 7: Clearances To Combustibles
CLEARANCES TO COMBUSTIBLES It is of utmost importance that the clearances to combustible materials be strictly adhered to during installation of the stove. Refer to the tables below : 23/24 • Floor to ceiling height must be at least 7’ (84”) in all cases. •... -
Page 8: Reduced Clearances (Canada Only)
REDUCED CLEARANCES (CANADA ONLY) You may decrease the clearances by installing heat radiation shields between the walls or the ceiling and the stove. These heat radiation shields must be installed permanently, and can include sheet metal, a rigid non-combustible sheet or a masonry wall. Clearances of not less than 1" (25 mm) and not more than 3"... - Page 9 CHIMNEY Your wood stove may be hooked up with a factory built or masonry chimney. If you are using a factory built chimney, it must comply with UL 103 or ULC S629 standards; therefore it must be a Type HT (2100°F).
-
Page 10: Chimney Connector (Stove Pipe)
CHIMNEY CONNECTOR (STOVE PIPE) Your chimney connector and chimney must have the same diameter as the stove outlet. If this is not the case, we recommend you contact your dealer in order to insure there will be no problem with the draft. -
Page 11: Typical Installations
TYPICAL INSTALLATIONS FACTORY BUILT CHIMNEY : Wall Installation Vertical Installation Ussc... - Page 12 TYPICAL INSTALLATIONS continued... MASONRY CHIMNEY : Ussc...
- Page 13 TYPICAL INSTALLATIONS continued... FACTORY BUILT THIMBLE : BUILT THIMBLE : Ussc...
-
Page 14: Outside Combustion Air
OUTSIDE COMBUSTION AIR Your Magnolia stove is approved to be installed with an outside air intake which is necessary for a mobile home. This type of installation is also required in air tight houses and houses with negative pressure problems. You can purchase this option through your Magnolia dealer. Make sure to specify this part number: #AC02080. - Page 15 WOODSTOVE UTILIZATION Your heating unit was designed to burn wood only; no other materials should be burned. Waste and other flammable materials should not be burned in your stove. Any type of wood may be used in your stove, but specific varieties have better energy yields than others. Please consult the following table in order to make the best possible choice.
-
Page 16: Testing Your Wood
TESTING YOUR WOOD When the stove is thoroughly warmed, place one piece of split wood (about five inches in diameter) parallel to the door on the bed of red embers. Keep the air control full open by pulling on it and close the door. If ignition of the piece is accomplished within 90 seconds from the time if was placed in the stove, your wood is correctly dried. -
Page 17: Reloading
WARNINGS • NEVER OVERFIRE YOUR STOVE. IF ANY PART OF THE STOVE STARTS TO GLOW RED, OVER FIRING IS HAPPENING. READJUST THE AIR INTAKE CONTROL AT A LOWER SETTING. • THE INSTALLATION OF A LOG CRADLE IS NOT RECOMMENDED IN YOUR MAGNOLIA WOOD STOVE. -
Page 18: Ash Disposal
ASH DISPOSAL Ashes should be removed from the stove every few days or when ashes get to 2 to 3 inches deep. Always empty the stove when it is cold, such as in the morning. Always dispose of ashes in a metal container with a tight fitting lid. -
Page 19: Repair Parts
Ussc REPAIR PARTS KEY DESCRIPTION Flue Collar Feed Door Door Handle Door Handle Pin Hinge Pin Magnolia Glass Bottom Glass Retainer Top Glass Retainer Heat Shield Deflector Blower Back Blower Motor Blower Cover Ash Pan Fire Brick (4½ x 9) Fire Brick (6 x 8¼) Half Brick (2¼... -
Page 20: How To Order Repair Parts
WHEN ORDERING REPAIR PARTS, ALWAYS GIVE THE FOLLOWING INFORMATION AS SHOWN IN THIS LIST: 1. THE PART NUMBER 2. THE PART DESCRIPTION 3. THE MODEL NUMBER: 2015 4. THE SERIAL NUMBER:____________________ HOW TO ORDER REPAIR PARTS UNITED STATES STOVE COMPANY 227 INDUSTRIAL PARK ROAD P.O.BOX 151...
