Summary of Contents for Bluewave SilverWave 2019

  • Page 2: Table Of Contents

    TABLE OF CONTENTS 12.3 DISPLAY Night Mode Alerts Volume Up / Down MAP SCREEN Navigation Controls Waypoint Bearing Course Select Course New Course 11-12 New Auto Course 13-14 STEREO SCREEN Satellite Radio AM / FM Radio / Weather Viper II Bluetooth USB Input Auxiliary Input Equalization / Preset EQ...
  • Page 3 TABLE OF CONTENTS DEPTH SCREEN CONTROLS SCREEN SETTINGS SCREEN Bluetooth Backlighting Depth Alarm Air Temp Offset Trim Calibration Fuel Calibration Units Time Zone System Diagnostics About MEDIA SCREEN 12.3 Camera 1&2 Media View File Transfer...

  • Page 4: 12.3" Display

    12.3" DISPLAY The high-resolution touch control displays bring more features to the surface providing an unmatched user experience. Critical information including engine performance, fuel level and depth is always in view or just a touch away. The center of each window screen swaps out with a touch of the top level destination page buttons.

  • Page 5: Alerts

    ALERTS 1- Warning Triangle Icon / Button 2- MIL Indicator/Button (will present for 3 seconds when display powers up) 3- Acknowledgment Button VOLUME UP / DOWN Touch VOLUME UP VOLUME DOWN to bring up the VOLUME CONTROL MENU. Adjust the volume of the interior, tower and master speakers in the VOLUME CONTROL MENU.

  • Page 6: Map Screen

    MAP SCREEN Touch the button to bring up navigation. The Navionics Navigation System uses GPS (Global Positioning System) satellites, and a map database to calculate and display route directions. SD Card with Map Data is required. 1- Waypoint Control 4- GPS Control 2- Course Control 5- Zoom In/Out 3- Screen Orientation...

  • Page 7: Waypoint

    WAYPOINT WAYPOINT Touch the button to place a waypoint at the cursor position. Position the cursor over an existing waypoint to EDIT, MOVE or DELETE it. WAYPOINT ICON Choose a to mark the waypoint with a meaningful reminder. BEARING NORTH / BEARING Touch the button to change the method of TRACKING position.

  • Page 8: Gps

    Touch the button to view available SATELLITE STATUS. IT CAN TAKE SEVERAL MINUTES FOR GPS SATELLITES TO LOCATE AND POSITION THE BOAT ON THE MAP.

  • Page 9: Course

    COURSE COURSE Touch the button to SELECT, CREATE, STOP or CANCEL a course. NEW AUTO COURSE records the actual route the boat is traveling to be saved and recalled later. NEW COURSE allows the user to build a future course of NEW user created waypoints.

  • Page 10: Select Course

    SELECT COURSE COURSE SELECT Touch the then button to PICK, UNPICK or DELETE a course. Picking a course will display the course on the map. Multiple courses can be displayed on the map.

  • Page 11: New Course

    NEW COURSE NEW COURSE allows the user to build a future course of NEW user COURSE created waypoints. To begin, touch then and then COURSE SELECT WAYPOINT LOCATION Touch , then position the cursor on the map for the first waypoint.
  • Page 12 COURSE COMPLETE The last waypoint must be a waypoint to finalize the course. A course cannot be changed or edited once created. COURSE SELECT Touch the button, then the button to PICK, UNPICK or DELETE a course. Picking a course will display the course on the map. Multiple courses can be displayed on the map.

  • Page 13: New Auto Course

    NEW AUTO COURSE NEW AUTO COURSE records the actual route the boat is traveling to be COURSE saved and recalled later. To begin, touch then and then NEW AUTO COURSE SELECT WAYPOINT LOCATION Touch , then position the cursor on the map for the first waypoint.
  • Page 14 WAYPOINT Touch the button, then choose an icon and name for the waypoint. Continue with this same procedure to create all remaining waypoints. The last waypoint must be a COURSE COMPLETE waypoint to finalize the course. A course cannot be changed or edited once created. COURSE SELECT Touch the...

  • Page 16: Stereo Screen

    STEREO SCREEN STEREO Touch the button for direct access to certain audio controls including AM/FM stereo channels, Bluetooth wireless, Satellite, USB and Auxiliary input ports. SIRIUS XM screen is only accessible after module and antenna are connected to the black box radio. 1- FM Radio 5- AM Radio 2- Satellite Radio...

  • Page 17: Satellite Radio

    SATELLITE RADIO SATELLITE Touch for satellite radio stations. 1- Source Select 6- Lock Channel 2- Favorite's Scroll 7- Equalization Adjustment 3- Power On/Off 8- Classic Audio Control 4- Direct Channel 9- Save Settings 5- Seek Forward / Back AM / FM RADIO / WEATHER AM RADIO FM RADIO WEATHER...

  • Page 18: Viper Ii Bluetooth

    VIPER II BLUETOOTH BLUETOOTH Touch to play songs on your phone or mobile device with Bluetooth wireless technology. SETTINGS Bluetooth must be turned in the menu. Then scan for the display from your mobile device USB INPUT MENU Touch to access USB input ports. Press to view full navigation popup.

  • Page 19: Auxiliary Input

    AUXILIARY INPUT AUXILIARY Touch to access the auxiliary input port. EQUALIZATION / PRESET EQ Touch to adjust the loudness, bass, treble, fade, balance and sub of the music. IVOL when available, will allow adjustment of the MAX turn on volume of the radio.
  • Page 20 DEPTH SCREEN DEPTH Touch the button at the top of the screen to view a graphical representation of depth in addition to WATER, AIR TEMP, bluetooth information and clock. A SHALLOW WATER ALARM sounds and a NOTICE is displayed when the water depth is less than the shallow setting. The shallow water level is adjusted in the settings menu.
  • Page 21 CONTROLS SCREEN CONTROLS Touch the button to manage navigation, accent lighting, pump options, and manage system settings. 1- Navigation Lights 7- Ski Locker 2- Anchor Lights 8- Accesory 1 3- Docking Lights 9- Accesory 2 4- System Settings 10- Accesory 3 5- Interior Lights 11- Accesory 4 6- Exterior Lights...
  • Page 22 SETTINGS SETTINGS Touch the button to manage system settings, options, troubleshooting, and software updates. View the available settings list with the SCROLL BAR on the right side of the screen and touch an item on list to VIEW available SETTINGS CHOICES. Changes will automatically be saved upon leaving the SETTINGS screen.
  • Page 23 BACKLIGHTING Touch BACKLIGHTING to adjust the BRIGHTNESS setting from 0-100% of the display in DAYTIME and NIGHT MODES. The NIGHT button on the GAUGE SCREEN toggles between the two settings. DEPTH ALARM DEPTH ALARM Touch to adjust the SHALLOW DEPTH ALARM setting. Setting to 0' will disable the alarm.
  • Page 24 AIR TEMP OFFSET AIR TEMP OFFSET Touch to calibrate the ambient air temperature sensor offset. TRIM CALIBRATION TRIM CALIBRATION Touch to calibrate the drive trim gauge.
  • Page 25 FUEL / CALIBRATION FUEL SOURCE / CALIBRATION Touch to calibrate fuel tank levels. Calibration will not take full effect until all three points here are calibrated. UNITS UNITS Touch to choose from ENGLISH to METRIC units.
  • Page 26 TIME ZONE SETTINGS TIME ZONE SETTINGS Touch to select time zone. SYSTEM DIAGNOSTICS SYSTEM DIAGNOSTICS Touch to be provided troubleshooting information by a trained technician.
  • Page 27 ABOUT ABOUT (UPDATE) Touch to view the installed software version and instructions for how to install a software update here. During the update process ensure stable power to the display and do not interrupt the process. After pressing "Update" wait for up to 30 seconds and the counter will show update progress.
  • Page 28 MEDIA SCREEN View a PDF document or video from an SD card or USB. This feature functions ONLY when the engine is OFF 1- Camera #1 4- PDF Viewer 2- Camera #2 5- File Transfer 3- Media Player CAMERA 1 & 2 Video Input buttons will display video feed from the analog video inputs into the display.
  • Page 29 MEDIA VIEWER MEDIA button will allow the user to and play videos that have been stored on the SD card in the SeaRay folder. Touch the name of the desired file to play. 1- Exit Player 6- Last Video 2- Play All Videos 7- Stop Video 3- Play/Pause Video 8- Volume Up...
  • Page 30 FILE TRANSFER Move Files from USB input device to SD Card. Highlight file to be deleted or copied. USB 1 input is located in the starboard side helm storage. The optional USB 2 (if installed) will be located in the glove box. Wait sufficient time for larger files to transfer.
  • Page 32 Draft 04...
