GNS8360
GNS8365 BT
Car Navigation System
Operation Manual &
Quick Start Guide
OPERATION MANUAL

Advertisement

Table of Contents
loading

Related Manuals for Uniden GNS8360

Summary of Contents for Uniden GNS8360

  • Page 1 GNS8360 GNS8365 BT Car Navigation System Operation Manual & Quick Start Guide OPERATION MANUAL...
  • Page 3 GNS8360 cannot be guaranteed accurate as road layout may change. Always follow the posted road signs and traffic laws. Do not mount the GNS8360 in a position which may obstruct the driver's view or prevent the safe operation of the vehicle.

  • Page 4: Contents

    Quick Start Guide Software CD Stylus-Pen +12V to +24V Cigarette Lighter Power Cord Start Here SD Memory Card Carrying Case BOX CONTENTS Optional Accessories Please contact your place of purchase if any of the following items are missing. AC Power Adaptor External GPS Antenna SD Card Reader Box Contents...
  • Page 5 Ensure the mount location; Allows room to raise the GPS antenna horizontally. Allows for the GNS8360 to be slotted in and out of the mount stand. Allows for the tilt angle to avoid reflected sunlight. iii i...
  • Page 6 4. Release the two grey buttons and check the unit is secure. Connect Power 1. Insert DC plug of Cigarette Lighter Lead into the DC Power socket of your GNS8360 and connect the other end to the +12V - 24V cigarette lighter socket. Ensure the cord does not interfere with safe...
  • Page 7 On when the buttons left and right of the screen are lit with a blue LED backlight. Press the POWER button at the left side of the GNS8360 momentarily to turn power On or Off. The screen may be turned on or off by pressing (GNS8360 model only).
  • Page 8 Built in GPS antenna 400MHz processor SIRF III GPS Bluetooth capability for hands-free Mobile phone use (GNS8365 BT model only) Updateable Software* for; Operation Map data * For operation software updates please visit www.uniden.com.au (Australian model) or www.uniden.co.nz (New Zealand model).
  • Page 9 CONTROLS & VIEWS FRONT BACK LEFT SIDE Main Menu Button Screen On/Off Button (Bluetooth Button - for GNS8365 BT model only) 3&4 Map Zoom In/Out Stereo Speaker Mount Holder Bracket GPS Antenna Secure Digital Card Slot Audio-Out Jack GPS Antenna Power On/Off Button Volume Control Power-Supply Jack...
  • Page 10 Safe Mode ON. See Safety Warnings on page 18 for Safe Mode setting. CARE & MAINTENANCE Please take the following steps to ensure your GNS8360 is looked after. Always transport and store the GNS8360 using the carry case. Keep the GNS8360 free from dust by regularly cleaning the screen with an LCD cleaner.
  • Page 11 3 Select an available application: applications are working simultaneously. Turning the screen off temporarily (GNS8360 model only) This function is used to turn the LCD screen off temporarily without ending the current program.
  • Page 12 PLAYING MUSIC FILES The GNS8360 will play MP3 and wav music files (converted for Windows Mobile(WIN CE)) saved onto the SD memory card. If the supplied SD memory card is short of capacity do not delete the map file to increase capacity.
  • Page 13 PLAYING MOVIE FILES When a movie file (avi file converted for Windows Mobile (WIN CE)) exists in the SD memory card that is inserted into the device, it automatically searches and shows both the file list and the movie start screen. If the supplied SD memory card is short of capacity do not delete the map file to increase capacity.
  • Page 14 VIEWING PICTURES To view an image file, the bmp, jpeg, gif or png file must be saved in a SD memory card. If the supplied SD memory card is short of capacity do not delete the map file to increase capacity. Purchase another SD card then you can save more files.
  • Page 15 GAME PAIRS GAME This is a simple pairs game where you pair 2 cards with the same picture from among 32 different picture cards. Once you start the game, the preview mode will display all the cards for 5 seconds before starting actual game.
  • Page 16 SETTINGS Environment Settings Settings are applied immediately. The screen setting tabs appear. When accessing the screen setting tab, the last setting status appears. If a screen with changes is exited without touching the ‘Save’ button, the change is canceled.
  • Page 17 Setting Options Calibrate (Screen) Opening Screen Setting...
  • Page 18 BUILT IN BATTERY SPECIFICATION...
  • Page 19 BLUETOOTH (GNS8365 BT Model Only) The GNS8365 BT includes Bluetooth® connectivity. With its integrated microphone, the GNS8365 BT allows you to answer and make calls from the touch screen. Pressing the Bluetooth button on the front of the GNS8365 BT launches the Bluetooth system.
  • Page 20 Using GNS8365 BT to Connect to Your Phone Tapping Add Device will cause the GNS8365 BT to search for available Bluetooth devices. NOTE: During this process, please watch your phone screen for any additional Select your phone from the list and tap Connect to connect the phone.
  • Page 21 Using your Phone to Connect to GNS8365 BT Tapping Find Me will cause the enter "discoverable mode," allowing other Bluetooth devices to connect to it. You can now use your device to pair with the GNS8365 BT . Once you enter the PIN number on your phone, the GNS8365 BT will ask that you verify the PIN.
  • Page 22 Managing Bluetooth Devices You may have multiple phones set up for connection with your Delphi You can add and remove phones from your list and disconnect and connect to different phones using the List Screen. If you have phones already paired to the but have none of them currently connected, the following screen appears when you select Hands Free from the Main Menu.
  • Page 23 Favorites Tapping Favorites accesses a list of your previously stored favorite numbers Adding Favorites If you have no Favorites on the Favorites list, the following screen is displayed. Tap Yes to display the touch pad to add a Favorite. You can also add a favorite number by selecting Add Favor.

  • Page 24: Features

    History Tapping History accesses a list of your previously called or received numbers. Voice Call Tapping Voice Call allows you to make a call by speaking the name of a previously recorded voice call number on your phone. NOTE: Voice calling must be set up on your phone to use this feature.
  • Page 25 (not supplied) to a PC for updating the navigation software or uploading media files. The supplied CD disc contains a PDF copy of this owner's manual, the GNS8360 Navigation manual and a back up copy of the GNS8360 Navigation software.
  • Page 26 TROUBLESHOOTING PROBLEM SOLUTION Make sure power supply is +12V or +24V No Display Touchscreen not responding No Sound Searching For Satellites' still showing. PROBLEM The unit powers on but does not boot up. Check power connection. If touchscreen not responding while driving then Safe Mode is on (see page 18).
  • Page 27 Warranty is only valid in the original country of purchase. ELEMENT OF WARRANTY: Uniden warrants to the original retail owner for the duration of this warranty, its GNS8360 (herein after referred to as the Product), to be free from defects in materials and craftsmanship with only the limitations or exclusions set out below.
  • Page 28 THANK YOU FOR BUYING A UNIDEN PRODUCT. © 2007 Uniden Australia Pty Limited. Uniden New Zealand Ltd. Printed in China...

  • Page 29: Navigation Manual

    GNS8360 GNS8365 BT Car Navigation System Navigation Manual NAVIGATION MANUAL...

  • Page 30: Copyright Note

    Copyright note The product and the information contained herein may be changed at any time without prior notification. This manual nor any parts thereof may not be reproduced or transmitted in any form either electronically or mechanically, including photocopying and recording, without the express written consent of Carpoint Co., Ltd .
  • Page 31 Note Throughout this manual the model name to the models GNS8360 and GNS8365 BT. Thank you for choosing iGO as your door-to-door in-car navigator. Read the Quick Start Guide first and start using iGO right away. This document is the detailed description of the software.

  • Page 32: Table Of Contents

    Table of Contents Warnings and safety information... 8 Table of Contents General information... 9 Operating iGO (Controls) ... 10 3.1 Screen buttons and controls... 10 3.1.1 Direct selectors... 10 3.1.2 List selectors ... 10 Warnings and safety information... 8 3.1.3 Sliders ...
  • Page 33 4.5.2 Zoom in and out (No. 2 & 3) ... 30 4.5.3 Tilt up and down (No. 4 & 5)... 30 4.5.4 Lock to GPS position and heading (No. 6) ... 30 4.5.5 Cursor (No. 7)... 31 4.5.6 Map scale (No. 8) ... 31 4.5.7 Menu (No.
  • Page 34 5.1.4 Warn When Speeding ... 55 5.1.4.1 Speeding tolerance... 56 5.1.4.2 Alternative speed limit... 56 5.1.4.3 Alternative speeding tolerance ... 56 5.1.5 Route Recalculation ... 57 5.1.5.1 Automatic... 57 5.1.5.2 Ask First... 57 5.1.5.3 Disabled... 57 5.2 Map settings ... 58 5.2.1 Daylight / Night colour profile...

  • Page 35: Troubleshooting

    5.7.2.1 Brightness... 67 5.7.3 Brightness ... 67 5.7.4 Smart Zoom... 67 5.7.4.1 Smart Zoom settings... 68 5.7.4.2 Enable Overview mode... 68 5.7.4.3 Restore Lock-to-Position and Smart Zoom... 68 5.7.5 Route options ... 69 5.7.5.1 Off-route sensitivity and Recalculation delay ... 70 5.7.5.2 U-turn penalty ...

  • Page 36: Warnings And Safety Information

    *PNA - Portable Navigation Accessory IE: GNS8360 GNS365 BT. Never place the PNA where it can obstruct the view of the driver, is within the deployment zone of airbags, or where it can cause injuries in case of an accident.

  • Page 37: General Information

    2 General information iGO is a navigation system optimised for in-car use. It provides door-to-door 2 General information navigation for both single and multi-point routes using adaptable route parameters. iGO is capable of planning routes throughout the whole map region installed on the memory card.

  • Page 38: Operating Igo (Controls)

    3 Operating iGO (Controls) iGO is designed for easy operation. All controls are operable by fingertips. Wherever possible, pushbuttons and lists are provided to make accessing functions or 3 Operating iGO (Controls) changing settings as easy as possible. iGO is designed for easy operation. All controls are operable by fingertips. Wherever possible, pushbuttons and lists are provided to make accessing functions or 3.1 Screen buttons and controls changing settings as easy as possible.

  • Page 39: Sliders

    Note: The only exception for this is the Manual GPS Configuration screen (Page ) where you can confirm your new set of selections by tapping the button, or leave the previous settings untouched by exiting with the button in the top left corner.

  • Page 40: Switches In The Quick Menu

    some vehicle types. When such a vehicle is selected, not only the lamp but also the whole line becomes inactive and dark. These switches look different on a square display. The lamp is placed not left of the label but below it, and its shape is also different. Use these buttons the same way as you would other switches.

  • Page 41: Abc-Type Keyboards

    3.1.7.1 ABC-type keyboards These keyboards contain only letters (Latin, Hebraic, Greek or Cyrillic). If you wish to enter numbers, you need to tap the Keys ( ) button to switch to the numeric keyboard. Use Backspace (arrow pointing left between Space and Keys) to delete the last letter you have entered if you have made a mistake, tap Space to enter more words, and hit Done to finish entering the text.

  • Page 42: The Numeric Keyboard

    3.1.7.3 The numeric keyboard The numeric keyboard only contains numbers, on huge buttons. The special keys you find on the other keyboards (except Space) are available here as well. Although QWERTY-type keyboards also contain number keys, when entering a house number, the program offers the more convenient numeric keypad.

  • Page 43: Main Menu

    4 Discovering the program through the screens The best way to discover iGO is to explore each screen in detail, and to find out how to move from one to another. Read this chapter for a guided tour. iGO starts by displaying the Main menu. This is the root of the screen hierarchy, but you only need to return here in a few cases.

  • Page 44: About Screen

    Button to open Cockpit screen Button to open Find menu Button to open Settings Button that displays GPS Status and opens the GPS Data screen Current position Current date and time Button to open Map screen Button to open About screen Button to exit iGO** (navigation stops) * Depends on program settings ** Same as removing the SD card...

  • Page 45: Gps Data Displayed

    4.3.1 GPS data displayed The virtual sky on the left represents the currently visible part of the sky above you, with your position as the centre. The satellites are shown at their current positions. The GPS receives data from both the green and grey satellites. Signals from the grey satellites are only received, while green ones are used by the GPS to calculate your current location.

  • Page 46: Gps Data Quality Indicator

    other colours may not appear with a built-in GPS. Should any of these appear, this means a faulty operation of your device. Note: When the GPS connection cannot be established with the last used parameters (protocol, port and speed), iGO keeps on trying to connect. To save the battery power in cases when you use iGO without a GPS, iGO first tries to open the port in every few seconds, but later only twice every minute.

  • Page 47: The Map

    Turn on the Auto Correction switch to let iGO frequently check and correct the PNA time with the GPS time. Below that button you will see the current values of the GPS and the PNA clocks. You can check here whether any correction is needed. Tap the button to manually synchronize the time.

  • Page 48: Zoom Levels

    Note: Using the Advanced settings, you can force Cockpit mode to always start in 3D Track-up view (Page ). You can still rotate and tilt the maps in either mode, but the next time you enter this screen, the preset look will reappear. Note: Similarly you can force Map mode to always start in 2D North-up view.

  • Page 49: Streets And Roads

    You can change between day and night views manually in the Quick Menu (Page 43) or let iGO do it automatically ( Page 55) for you. Note: The automatic day/night mode is based upon the current date and GPS position by which iGO calculates the exact sunrise and sunset times on the particular day at the particular location.

  • Page 50: Other Objects

    Streets and roads have names or numbers for identification. Of course, this information can be displayed on the map. iGO uses two different ways to show street labels. The conventional way is the same as a roadmap – it displays the name of the street aligned with the street.

  • Page 51: Current Position And Lock-On-Road

    4.4.6 Current position and Lock-on-Road When your GPS position is available, a blue arrow (yellow when using night colours) shows your location on the map. The direction of the arrow represents your heading. The arrow is sized and vertically rotated with the zoom and tilt levels to always look realistic. iGO has a built-in Lock-on-Road feature that always puts the position arrow on the road, on the axis of the street in case of one-way streets, or on the side of the road where you drive (e.g.

  • Page 52: Marked Map Points (Pin)

    pin, or save it as a POI. The cursor, when visible, is also the reference point for map scaling. Note: When your GPS position is available, and Lock-to-Position (Page ) is active, the cursor is the current GPS position, the blue arrow. When you select another point by tapping the map, or using the Find menu (Page 74), the new Cursor is shown on the display with the red dot and the radiating red circles.
  • Page 53 POIs are represented by icons on the map. For a built-in POI it is the icon of the subcategory of the actual POI. For points you create, it is the icon you had chosen when you created the POI (it can be changed later). These icons are large enough to recognise the symbol, and semi-transparent so as not to cover the streets and junctions behind them.

  • Page 54: The Start Point, Via Points And The Destination

    4.4.10 Elements of the Active Route iGO uses a multi-destination routing system in which you have a start point (your current location if GPS position is available), a destination, the line of the active leg of the route, and optionally via points and inactive legs. They are all shown on the map.

  • Page 55: Screens With Map

    4.4.10.4 Inactive legs of the route Future sections of a route are inactive. They are also shown on the map with the same colour but a darker tint than the active one. An inactive route section becomes active as soon as you reach its starting Via point. 4.4.10.5 Roads in the route excluded by your preferences Although you can choose whether to include or avoid some road types in Route...
  • Page 56 There are several controls that function in a similar fashion on the two screens. They are described on the following pages. Map screen contents: Cockpit screen contents: Display (Cockpit only) Turn preview* Indicates that Lock to GPS position and heading is inactive Selected map point (Cursor) (Map only) Map scale Map orientation and Overview...

  • Page 57: Turn Preview (No. 1)

    Display GPS position quality Battery status Sound on or muted Track Log recording or playback (Cockpit only) Current street (Cockpit only) Travel and Route data** (Cockpit only) Distance to next turn*** (Cockpit only) Next street*** (Cockpit only) Approaching next turn**** * On Map screen only when a route is active ** Contents differ when a route is active *** Appears only when a route is active...

  • Page 58: Zoom In And Out (No. 2 & 3)

    4.5.2 Zoom in and out (No. 2 & 3) These semi-transparent buttons are only displayed if "Zoom & Tilt" is enabled in the Quick menu (Page Zoom will change the scale of the map. Zoom out shows a larger part of the map, while Zoom in shows a smaller part of the map in more detail.

  • Page 59: Cursor (No. 7)

    This semi-transparent icon is displayed if GPS position is available, and the map has been moved. It also appears when you scale or tilt the map while Smart Zoom is enabled. This semi-transparent icon is displayed if GPS position is available, and the map has been moved or rotated.

  • Page 60: Menu (No. 9)

    You can use it in both 2D and 3D modes to scale the map. Drag and pull it right to zoom in, or left to zoom out. 4.5.7 Menu (No. 9) This button opens the Menu with the Find engine, the Quick menu, the Route menu and the exit button that takes you to the Main menu screen.

  • Page 61: Gps Position Quality (No. 11)

    Tap the icon again to return to Track-up (automatic rotation) mode. 4.5.9 GPS position quality (No. 11) Similarly to the icon found on the GPS Data screen (Page inform you about the GPS signal: The black satellite dish with the red exclamation mark shows there is no connection with the GPS receiver.

  • Page 62: Sound Muting (No. 13)

    4.5.11 Sound muting (No. 13) By tapping this button you can quickly mute all sounds of the PNA. This will not modify the volume level and the enabled or disabled status of the voice guidance or the key sounds (all to be set on the Sound Settings screen: Page sound output.
  • Page 63 When you open the menu manually, it will stay on until you close it or switch to another screen. Tip: If you want to see the map around the Cursor, close the Cursor menu and reopen it. When this menu is opened manually, the map is always moved to have the cursor in the centre.

  • Page 64: Current Street (No. 16)

    Edit Cam: you can edit the parameters of the camera near or at the Cursor, or delete it. This menu point replaces Add Cam and is available only if the selected point is near or at a speed camera. A window will open up that contains the same settings as in Add Cam.

  • Page 65: Distance To Next Turn (No. 18)

    While navigating a route, these fields show the estimated time needed to reach the destination (ETE), the distance to destination, and the estimated arrival time at the destination (ETA) by default. You can choose what to display in these three fields during navigation, by going to Advanced settings / Display Options (Page The only restriction is that you cannot select a value that already appears in another field.

  • Page 66: Approaching Next Turn (No. 20)

    4.5.18 Approaching next turn (No. 20) This bar is only visible when approaching the next route event. It appears on the screen to visualise the distance when you get closer than 300 meters (1000 feet) to the next turn, and it remains visible till you reach the turn. This field is displayed only when navigating a route.

  • Page 67: Route Line

    4.6.1.1 Route line The upper part of this screen shows your planned route as a horizontal line. Its leftmost point is the start of the route, the rightmost one is the final destination, and you can see your via point flags along the line, spaced in proportion to their distance. The blue (yellow at night) arrow representing your position will travel from the left to the right, giving you visual feedback of your journey.

  • Page 68: Estimated Arrival

    4.6.1.5 Estimated Arrival This is an estimated value that can also be displayed in one of the Route data fields on the Cockpit screen as ‘ETA to destination’. It shows the estimated arrival time at the final destination of the route based on information available for the remaining segments of the route.

  • Page 69: Fit To Screen

    This icon warns you that iGO had to recommend a route that does not match all your preferences given at the Route Parameters settings. The recommended route contains areas only accessible to pedestrians. The recommended route contains unpaved roads. The recommended route contains roads that require a permit or permission to enter.

  • Page 70: Find Tab

    4.7.1 Find tab The first page of the Menu is Find. It lets you select a destination without first having to locate it on the map. The Find menu will be described in detail later here: Page 4.7.2 Quick tab This provides quick access to some configurable options.

  • Page 71: Night Mode (Switch)

    4.7.2.3 Night Mode (switch) Turn on or off the night colours manually to override the automatic colour scheme switching. Note: Using this option turns off the Automatic Night Colours feature. You need to re- enable it at the General settings screen (Page 54) to have the colours change automatically again.
  • Page 72 Groups shown with a grey icon are hidden; blue icons are visible on the map, while the ones shown in two colours have some of their subcategories shown and some others hidden. If you highlight any of the POI groups by tapping them, the button in the bottom left corner will become Show if the POI group is hidden, or Hide if the group is shown or partly shown.
  • Page 73 When the My POI Groups are displayed, you have the following options: Show/Hide: similarly to built-in POIs, you have the possibility to show or hide all POIs of the selected category on the map. Groups with a blue icon are displayed; groups with a grey icon are hidden.

  • Page 74: Popup Information (Switch)

    Here you have the following options: OK: if you tap this button, the map screen returns with the selected POI in the middle. Edit: you can edit the attributes (name, icon and group) of the selected POI. Delete: you can delete any of your previously saved POIs. iGO will ask you to confirm this action.
  • Page 75 The original name of a track log is the date and time when it was recorded. You can change their name to something more meaningful if you wish. Each track log has a colour, shown to the left of its name when the track log is visible on the map.
  • Page 76 or export the data to the SD card in GPX format (Track export button). Replay: push this button to see a simulation of the saved track log on the map. A green icon (Page ) will appear on the map screens to let you know it is not a fly over but a simulation based on a real saved log.

  • Page 77: Route Tab

    4.7.3 Route tab This menu contains options to manage different settings in the program. 4.7.3.1 Recalculate This menu point is only available if an active route exists and GPS position is present. It brings up a menu with four options. Using one of these functions you can modify the current route.

  • Page 78: Delete

    Note: This function is to give you an alternative for the next section of the recommended route. To change later parts of the route or to avoid specific streets or turns, use the Avoid function in Itinerary instead (Page Note: When you use this feature, iGO will keep on excluding the same part of the map from later routes until you manually delete the route (Page ), or restart iGO.
  • Page 79 The Itinerary is live and constantly updated when navigating a route. The list item coming next in navigation is the highlighted one until you highlight another one by tapping. After that, the highlight remains on the item you have selected. Detailed Instructions: this is the list displayed when Itinerary is opened.

  • Page 80: Fly Over

    Note: You need not open Itinerary if you run into a roadblock or traffic jam. To get an immediate alternative route use the Bypass function of Recalculate (Page Note: When you use this feature, iGO will keep on excluding the same part of the map from later routes until you manually delete the route (Page Note: When you use this feature, iGO will keep on excluding the same part of the map from later routes until you manually delete the route (Page...

  • Page 81: Info

    Use the arrows on the right to browse through the list and tap any line to highlight it. You can perform the following operations: Add: you can add a new route point (or a new final destination if the highlighted item is the last one in the list) after the selected point.

  • Page 82: Settings

    5 Settings iGO provides several settings in order to let you customise the functions of the program. The Settings screen can be accessed directly from the Main menu screen (Page ) and from the map screens by using the battery icon (Page 33), while some of its sub-screens are accessible from other parts of the program.

  • Page 83: Set Favourite Destinations

    5.1.2 Set Favourite Destinations You can select two of your most frequent destinations to be your favourites (Page 83). You can start navigating to either of them by only two taps on the screen. The original names of these points are Home and Work. You can rename them and specify their locations.

  • Page 84: Speeding Tolerance

    You can set two different kinds of behaviour for the warning: one is applied up to a certain speed limit and the other one is used above that. 5.1.4.1 Speeding tolerance iGO will warn you when you exceed the speed limit by the amount specified here. Select whether you want to specify the tolerance as a Fixed value (offset to the speed limit) or as a Percentage.

  • Page 85: Route Recalculation

    Speed limit 160 km/h 5.1.5 Route Recalculation Once a route is planned, this setting will tell iGO what to do when you deviate from that route. 5.1.5.1 Automatic The route will be recalculated automatically a few seconds after you go astray. 5.1.5.2 Ask First iGO can also ask your preference each time you leave the planned route.

  • Page 86: Map Settings

    5.2 Map settings You can set a few parameters determining the appearance of the maps in iGO. 5.2.1 Daylight / Night colour profile iGO comes with different colour schemes for both daylight and night use. There is always one selected daytime scheme and one selected night-time scheme. iGO uses these when switching from day to night and back.

  • Page 87: Textured Polygons

    Note: You can only disable street names and POI icons if iGO follows your position. As soon as you move the map and Lock-to-Position (Page ) is disabled, street names and icons become visible again. Tap Lock to re-enable Lock-to-Position and have the labels and icons disappear again.

  • Page 88: Key Sound Volume/Switch

    5.3.3 Key sound volume/switch The switch on the left can turn the key sounds on or off. Key sounds are audible confirmations of either pressing hardware buttons or tapping the touch screen. When key sounds are turned on, the slider on the right will adjust their loudness. In its leftmost position the key sounds are suppressed, in its rightmost position they are played at the master volume level.

  • Page 89: Route Parameter Settings

    5.4 Route parameter settings This is a very important page. Settings here determine how routes will be calculated. This screen is directly accessible from the Route Information screen (Page 5.4.1 Method Use the handle to set the speed of the route calculation. In the leftmost position the route may not be optimal but the calculation will be very fast.

  • Page 90: Road Types To Include/Exclude

    motorways for pedestrians), or some of the restrictions may not be taken into account (e.g. emergency vehicles have no restrictions). Available values: Taxi Lorry Emergency Bicycle Pedestrian 5.4.4 Road types to include/exclude To let the route fit your needs you can also set which road types are to be considered for or to be excluded from the route if possible.

  • Page 91: Permit Needed

    Turning back on dual carriageways is not considered as a u-turn. Note: If you are not totally against u-turns, leave them on here, and add a certain penalty (equivalent extra distance to travel) in Advanced settings Route options (Page Note: Via points are handled as stopovers with regards to u-turns. It means disabling u-turns on this page will avoid u-turns during the entire route if possible, but when reaching a via point, the following part of the route may be planned starting in the opposite direction.

  • Page 92: Voice Language

    5.5.2 Voice language This button shows the current language of the voice guidance. By tapping the button you can select from a list of available languages and speakers. Tap any of these to hear a sample voice prompt. Just tap OK when you have selected the new spoken language.

  • Page 93: Display Options

    5.6.1 Display options These settings determine how iGO displays different content elements or how it presents the screens. 5.6.1.1 2D in Map mode (and North-up orientation) The normal use of the Map mode is to browse the map and look for different places on it.

  • Page 94: Coordinate Display Format

    5.6.1.4 Coordinate display format Positions are sometimes displayed with their addresses, and sometimes with their coordinates. This setting lets you choose between displaying coordinates in degrees (dd.dddddd); degrees and minutes (dd mm.mmm); or degrees, minutes and seconds (dd mm ss.s). Note: the coordinate display mode is independent from the coordinate input in Find menu.

  • Page 95: Brightness

    You can choose to have the lights always on. Use device settings You can preserve the PNA device settings (previously set in the operating system at Start/Settings/Backlight). Smart powersave You can also initiate this special feature of iGO. When running on battery Smart Powersave will light up the screen only when you press or tap a button, or if iGO has something to show you.

  • Page 96: Smart Zoom Settings

    5.7.4.1 Smart Zoom settings You can set how close Smart Zoom can zoom in when approaching the next turn (Zoom-in limit), and the maximum zoom level to zoom out when the next turn is further away (Zoom-out limit). The default values are set to be optimal in most cases. 5.7.4.2 Enable Overview mode You can configure how the Overview mode is triggered when the next turn is at a distance.

  • Page 97: Route Options

    Restore Lock-to-Position Turn this switch on if you want iGO to return to your current GPS position after you have moved the map during navigation. This is useful if you have moved the map accidentally, or if you have moved it to quickly check something near your route. After a certain timeout set below, the Lock button disappears, and the map immediately jumps back to show your current position.

  • Page 98: Off-Route Sensitivity And Recalculation Delay

    5.7.5.1 Off-route sensitivity and Recalculation delay Depending on the quality of your GPS device, the GPS antenna location in the car and the environment you are driving in, route recalculation can behave differently. iGO may think you have departed the proposed route and perform a recalculation even if you have not done so.

  • Page 99: User Data Management

    Note: By turning off Lock-on-Road you also turn off the GPS position error filtering. The position shown on the map will be subject to all position errors and position fluctuations. 5.7.6 User data management Everything that was saved (pins, My POIs, Favourites, track logs etc.) or modified (Settings, History lists) since iGO was installed is stored in a user database located in the internal memory of the Car Point PND.

  • Page 100: Remove Pins

    5.7.6.3 Remove Pins Normally Pins can be deleted one by one. Since they are shown at all zoom levels, and you may end up having too many of them, this button lets you delete all of them together. iGO will warn you that you are about to lose all your Pins. 5.7.6.4 Clear Data This button will delete all user data.

  • Page 101: Find

    6 Find One of the most frequently used functions of iGO is selecting the destination. Once you have the destination, you can start navigating. Getting to this point should be as fast as possible. iGO provides you with a versatile search engine designed to find your chosen destination after only a few taps on the screen.

  • Page 102: Using The Find Menu

    Tip: If you want the selected point shown in the centre of the map, close and reopen the menu or wait until it closes and open it again. By opening the Cursor menu manually, the map will be moved to have the selected location in the centre. 6.3 Using the Find menu The Find menu is accessible by the Find &...

  • Page 103: Selecting The City, State And Country To Search In

    You enter the module at Level 3. From this point you can go forward (down) to give the name of the street, then the house number or intersection, or backward (up) to change the city, state or country to search. 6.3.1.1 Selecting the city, state and country to search in The first screen of the address-search module is the list of recently used cities (and states in Australia).
  • Page 104 You can accomplish this by using an alphabetic input screen (either an ABC- or a QWERTY-type). You only need to enter the first few letters, as the program only searches among the settlements that exist in the given state or country. If the name of the settlement is of more than one word, the searched pattern can be any or the combination of those.
  • Page 105 Once you have selected the city, you can continue by entering the street name as described here: Page Changing the state (Australia, USA, etc.) Some of the maps contain state information. If the settlement you are looking for is in a different state, tap Other City then Change State from the list of recently used cities, then select the appropriate state.

  • Page 106: Selecting A Street Or The Centre Of The Settlement

    6.3.1.2 Selecting a street or the centre of the settlement Once the settlement (or state in Australia) is selected, you can continue by specifying the street you are looking for. Selecting the centre of the settlement If you wish to navigate to the settlement displayed in the top centre of the screen, just tap Done before entering any letters.

  • Page 107: How To Select An Intersection Instead Of A House Number

    Enter the number, tap Done, and iGO will show you the selected location on the map (or will start navigating immediately if you have selected Find & GO at the Main menu). Note: House numbers may not be available on the map of your region. Ask your local dealer for details.

  • Page 108: Find In History

    As several settlements have Paris in their name, the list of cities is not shown automatically. Tap Done to get the list of settlements containing ‘Paris’. The first settlement in the list is Paris, as it is the exact match. Tap it. Now you need to enter the name of the street.

  • Page 109: Find A Poi

    When you enter this page, the coordinates of the current GPS position (or the selected map point, the Cursor, if Lock-to-Position is inactive) are shown at the top of the display. The coordinates are always shown in the format configured in Advanced settingsDisplay options (Page ), but you can enter the coordinates in any of the three formats.
  • Page 110 The search will be carried out around a certain reference point. Always look at the current reference point shown in the green field above the POI category buttons and confirm that it matches what you want. To change the reference, tap the Change ref. button in the top right corner.

  • Page 111: Find One Of The Favourites (Home/Work)

    Filter from all the POIs of that level: tapping the Filter button will bring up a text input screen to let you narrow the list of POIs. If you tap Filter in the list of subgroups, you will only search in the group you are already in. See all POIs of the current group in a list: tapping the All button opens the list of all points in the group or subgroup you are already in.
  • Page 112 Using the Find & GO function at the Main menu it is only two taps to start navigating to one of your Favourites. Note: If you try to access a favourite destination that you have not yet set up, iGO will lead you to the setup page.

  • Page 113: Troubleshooting Guide

    7 Troubleshooting guide Thank you again for purchasing our product. We hope you will enjoy every minute of using it. However you may face difficulties before you get really accustomed to iGO. 7 Troubleshooting guide In such cases, please, refer to this table of frequently encountered problematic situations.
  • Page 114 on the Today screen, or the iGO icon in the Start/Programs section of the operating system to run iGO manually. You will still be able to exit iGO by removing the card. Creating a multi-point route I have tapped the ‘Route To’ button once for each destination but only the last one appears in the list, all previous points have disappeared.
  • Page 115 I would like to create a new POI but there are others near its location, and the new menu point (POI) opens the list of POI instead of creating a new one. Look for the New button in the bottom left corner of the newly opened list. Using that button you can add your new POI as if it was opened from the Cursor menu.

  • Page 116: Glossary

    8 Glossary The manual may contain many technical terms. Please look below for an explanation if you are unfamiliar with some of them. 2D/3D GPS reception: The GPS receiver uses satellite signals to calculate its (your) position. Depending on the current positions of the ever moving satellites in the sky, and the objects in your environment, the signal that your GPS device receives may be weaker or stronger.
  • Page 117 Automatic day/night colours: Based on the time and position given by the GPS device, iGO is able to calculate when the sun rises and sets at your current location on this particular day. Using that information iGO can change between the day and the night colour schemes a few minutes before sunrise and a few minutes after sunset (Page ).
  • Page 118 also in Page . However for pedestrian use it can be permanently turned off in Advanced settings (Page 70). Lock-on-Road: This function of iGO will always keep the blue (yellow at night) arrow representing your actual position on the nearest road. This automatic feature is necessary as the position given by the GPS receiver is not perfectly accurate.
  • Page 119 SiRF: This is the name of a popular GPS chipset manufacturer. Their specific communication protocol can be processed by iGO. SiRF based GPS devices are also capable of NMEA communication, the factory setting of communication protocol in iGO. Track log: In iGO you have the possibility to record your journeys using the position data your GPS provides in every second or every few seconds (depending on your GPS settings).
  • Page 120 THANK YOU FOR BUYING A UNIDEN PRODUCT. © 2007 Uniden Australia Pty Limited. Uniden New Zealand Ltd. Printed in China...

This manual is also suitable for:

Gns8365bt

Table of Contents
