Cooling port
The UPS can generate large leakage currents. A circuit breaker equipped with an RCD is not
recommended. If leakage protection is required, select a recommended circuit breaker.
Table 2-5 Requirements for the upstream circuit breaker of the smart module
Load
≤ 7.5 kW
7.5–15 kW

2.4 Site Requirements

Figure 2-1
Issue 02 (2016-11-15)
Specifications
Condensate drain outlet: for draining
condensate from the air conditioner.
Humidifier water pipe port: Connects to
external water pipes to supply water to the
humidifier.
If any of the requirements is not met, contact Huawei technical support.
Recommended
Circuit Breaker (for
the Air Conditioner
Without Heating and
Humidification)
Recommendation 1:
D63A/3P
Recommendation 2:
C80A/3P
Recommendation 1:
D63A/3P
Recommendation 2:
C80A/3P
and Figure 2-2 show the space requirements for the equipment room.
 The cabinet layouts shown in the figures are for ease of description and do not provide reference for
engineering layout.

If the site conditions do not meet the space requirements, contact Huawei technical support.
 The Smart Module can be installed with one side against a wall.
