Summary of Contents for Uniden EXS9005
-
Page 2: Rechargeable Nickel-Cadmium Batteries Must Be Recycled Or Disposed Of Properly
Before you read anything else, please observe the following: Warning! Uniden America Corporation DOES NOT represent this unit to be waterproof. To reduce the risk of fire, electrical shock, or damage to the unit, DO NOT expose this unit to rain or moisture. - Page 3 Controls and Keys 1. Talk/Batt Low Indicator – talk • batt low 2. Talk Key – talk 3. Numeric Keypad 4. Memory Key – 5. Microphone 6. Redial Key – redial 7. Flash Key – flash 8. Pause Key – pause 9.
-
Page 4: Table Of Contents
Included with the EXS9005 ........ -
Page 5: Important Safety Instructions
11. To reduce the risk of electric shock, do not disassemble this product. Take it to qualified service personnel when service or repair work is required. Opening or removing covers may expose you to dangerous voltages or other risks. Incorrect reassembly can cause electric shock when the appliance is subsequently used. EXS9005... -
Page 6: Battery Safety Precautions
5. Charge the Battery Pack provided with or identified for use with this product only in accordance with the instructions and limitations specified in the instruction manual provided for this product. 6. Observe proper polarity orientation between the Battery Pack and battery charger. SAVE THESE INSTRUCTIONS! EXS9005... -
Page 7: Introduction
Auto Channel Scan - During a call, your EXS9005 constantly monitors the noise levels of the channel. If the channel becomes too noisy, the unit automatically switches to a clearer channel to maintain the best transmission quality. -
Page 8: Included With The Exs9005
Included with the EXS9005 If any of these items are missing or damaged, contact Uniden Parts Department at (800) 554-3988, 8:00 a.m. to 5:00 p.m. Central, Monday through Friday. Handset Base Unit AC Adapter Rechargeable Battery Long Telephone Cord Short Telephone Cord... -
Page 9: Important Electrical Considerations
Please do not attempt to unplug any appliance during an electrical storm. Caution: Changes or modifications to this product not expressly approved by Uniden, or operation of this product in any way other than as detailed by this Operating Guide, could void your authority to operate this product. -
Page 10: Radio Interference
Because of the inherent physical properties of radio waves, your communications can be received by radio receiving devices other than your own cordless telephone unit. Consequently, any communications using your cordless telephone may not be private. EXS9005 Privacy... -
Page 11: Installation
Some equipment is wired directly to a phone jack, and these types of installations require a modular jack converter. This type of installation is not difficult; however, you should contact your Uniden telephone dealer or a telephone supply store for advice about the proper adapter or converter for your particular situation. -
Page 12: Applying Power To The Base Unit
Do Not alter the shape of the blades of the polarized plug! If you cannot plug the AC adapter into the outlet, contact someone about replacing the outlet. EXS9005... -
Page 13: Desk Or Tabletop Installation
2. Place the AC Adapter cord around the strain relief notch. 3. Plug one end of the long telephone cord into the TEL LINE jack on the Base Unit. 4. Plug the other end of the cord into the telephone jack on the wall. EXS9005... - Page 14 120 VAC wall outlet. Do not use an outlet controlled by a wall switch. Use only the Uniden AC Adapter supplied with this phone. 6. Place the Base Unit on a desk or tabletop. In desk or table top installation, the Handset is designed to stand only vertically in the Base Unit.
-
Page 15: Wall Installation
To attach the wall mount to the Base Unit: 1. Slide the wall mount into the notches at the top of the Base Unit. 2. Rotate the wall mount stand down and snap into place. 3. Plug the AC Adapter into the Base Unit. EXS9005... - Page 16 Base Unit. Then plug the other end of the telephone cord into the modular jack on the wall. 6. Place the Base Unit on the posts of the wall plate and push down until it’s firmly seated. EXS9005...
-
Page 17: Direct Wall Mounting
1. Insert two mounting screws 3-15/16 inches apart. Allow about 3/16 of an inch between the wall and screw heads for mounting the phone. 2. Slide the wall mount into the notches at the top of the Base Unit. EXS9005... - Page 18 3. Rotate the wall mount stand down and snap into place. 4. Plug the AC Adapter into the Base Unit. 5. Wrap the AC Adapter cord around the strain relief notch. Then put the AC Adapter cord inside the molded channel. EXS9005...
- Page 19 8. Plug the other end of the telephone line cord into the wall jack. 9. Plug the AC Adapter into a standard 120 VAC wall outlet. Do not use an outlet controlled by a wall switch. EXS9005...
-
Page 20: Setting Up Your Phone
Nickel-Cadmium battery pack with its socket and plug it in. The black lead will be on the left when the plug is properly aligned. 3. Place the battery pack inside the battery compartment and slide the battery cover back on. EXS9005... -
Page 21: Charging The Battery Pack
2. Make sure the LED lights. If the status LED doesn’t light, check to see that the AC adapter is plugged in and that the Handset is making good contact with the Base Unit charging contacts. EXS9005... -
Page 22: Battery Memory Effect
LED flashes. talk • batt low Complete your call as quickly as possible. Return the Handset to the Base Unit for charging. Allow 15 to 20 hours without any interruption for the Handset to fully recharge. EXS9005... -
Page 23: Cleaning The Battery Contacts
Setting the Pulse/Tone Switch Be sure the PULSE/TONE switch is in the TONE position. Most phone systems are Tone dialing. Check with your local phone company if you are not sure whether your system is Tone or Pulse dialing EXS9005... -
Page 24: Adjusting Ringer Controls
While the phone is not in use, press either (up) or volume Receiver volume While you are on a call, press either (up) or volume The phone has 8 receiver volume levels. Each time you press volume the receiver volume changes. EXS9005 flash (down). (down). -
Page 25: Changing The Beltclip
Attach the beltclip 1. Remove the slot cover. 2. Put the beltclip in the slot and press down until it clicks. Remove the Beltclip 1. Pull back on the release tab and pull up. 2. Replace the slot cover. EXS9005... -
Page 26: Using Your Phone
Using Your Phone Making and Receiving Calls The following features of the EXS9005 phones are different depending on the Handset’s location when you make or receive a call. Handset On Base Unit ANSWER CALL Pick up Handset (AutoTalk). 1) Pick up Handset. -
Page 27: Programming Your Phone
(up to 16 digits). 4. If a pause is needed during dialing to access a long distance service, press pause button counts as one digit. Pressing pause increases the length of the pause between numbers. 5551212 5551212 pause more than once pause EXS9005... -
Page 28: Storing A Mixed Number
An error tone will sound and the programming procedure will be canceled if more than 30 seconds elapse between each keystroke entry or step. 1. Remove Handset from the Base Unit. 2. Press LED blinks. talk • batt low EXS9005... - Page 29 Example: for memory location 07, you would press 0, then 7. A confirmation tone (double beep) indicates that the number is stored. If you enter a invalid two-digit memory location, a loud single beep sounds. 5551212 3300 3300 pause more than once pause EXS9005...
-
Page 30: Dialing A Stored Number
1. Remove the Handset from the Base Unit. 2. Press talk 3. Press 4. Press the two-digit memory location number (01-20). Example: for memory location 02, you would press 0, then 2. If you enter a invalid two-digit memory location, a loud single beep sounds. EXS9005... -
Page 31: Chain Dialing
If you enter a invalid two-digit memory location, a loud single beep sounds. If more than 30 seconds elapse between each keystroke entry or step, an error tone will sound and the erase procedure will be canceled. followed by the memory location EXS9005... -
Page 32: Troubleshooting
If your Cordless Telephone is not performing to your expectations, please try these simple steps. If you are still unable to resolve the problems, contact Uniden Customer Service at (800) 297-1023, 8:00 a.m. to 5:00 p.m. Central, Monday through Friday. -
Page 33: Specifications
Specifications General – The EXS9005 complies with FCC Parts 15 and 68. Frequency Control Modulation DBPSK Frequency 903.6 to 926.4 MHz (20 Channels) Base Unit Power Requirements 9 V 250 mA (from AC Adapter) Size 5-1/2 in.(W) x 2-1/2 in. (D) x 7-3/4 in. (H) Weight Approx. -
Page 34: One Year Limited Warranty
Uniden service center for a defect or malfunction covered by this warranty, (E) used in any conjunction with equipment or parts or as part of any system not manufactured by Uniden, or (F) installed or programmed by anyone other than as detailed by the Operating Guide for this product. - Page 35 Covered under one or more of the following U.S. patents: 4,511,761 4,523,058 4,595,795 4,797,916 5,426,690 ©1997 Uniden America Corporation. All rights reserved. Printed in China.
