Pro-Switch/8F
8 Port 100FX
Fast Ethernet Switch
FEP-37008-C (SC)
FEP-37008-T (ST)
U
SER'S
M
ANUAL
Advertisement
Table of Contents
Related Manuals for UNICOM Pro-Switch 8F
Summary of Contents for UNICOM Pro-Switch 8F
- Page 1 City of Industry, CA 91748 U.S.A. Phone: 626.964.7873 or 800.346.6668 Fax: 626.964.7880 www.unicomlink.com e-mail: info@unicomlink.com ©UNICOM 2001. UNICOM and “A Network Systems Solution” are trademarks of UNICOM Electric, Inc. All rights reserved. Specifications subject to change without notice. Rev: 10.03 Pro-Switch/8F...
-
Page 3: Package Contents
Package Contents Package contents include the following: Pro-Switch/8F; 100Base-FX Fast Ethernet Switch Power cord Four (4) adhesive-backed rubber feet Rack-mount brackets User’s manual Warranty card Pro-Switch/8F Power Cord User’s Guide Rack-mount Brackets with screws IMPORTANT: If any piece is missing or damaged, please contact your local dealer or reseller for service. -
Page 4: Table Of Contents
Table of Contents Package Contents ……………………………1 Table of Contents ……………………………2 Preface ………………………………………3 Introduction……………………………………4 Key Features …………………………………4 Hardware Description Front Panel ……………………………………5 Ports …………………………………………5 DIP Switch Set-up ……………………………6 LEDs …………………………………………7 Connecting to Power …………………………8 General Installation Selecting a Site for the Switch ……………9 Rackmount Installation ……………………10 Connecting the Power………………………11 Networking Application ……………………12... -
Page 5: Preface
Preface Benefits of Switching Ethernet switching technology has dramatically boosted the total bandwidth of a network. It puts configuration flexibility and bandwidth adaptability into the local workgroups where the majority of work is generated. It further eliminates congestion problems inherent to the CSMA/CD protocol and improves predictable response time under heavy network loads. -
Page 6: Introduction
Introduction The 8 Port Pro-Switch/8F is a high-speed, professional-grade Fast Ethernet switch that provides wire-speed, a Fast Ethernet switching technology that allows high-performance, low-cost connections up to Full- Duplex, 100Mbps Ethernet networks. With the Fiber Optic ports, this is a perfect, flexible backbone switch. -
Page 7: Network Application
Network Application This section provides a few samples of network topology in which the Switch is used. The Pro-Switch/8F is designed to be used as a backbone switch. With its large address table (4000 MAC address), Fiber ports, and high performance, it is ideal for connecting WANS to LAN network segments. -
Page 8: Dip-Switch Setup
DIP-Switch Setup The DIP-switch is used to configure full- or Half-duplex switching. The DIP- switch setup is as follows: Position Description Enables Full-Duplex Operation for 100Based-FX ports DOWN: Enables Half-Duplex Operation for 100Based-FX ports Figure 2. LED view of Pro-Switch/8F Power On Connect the power cord to the power socket on the rear panel of the Switch. -
Page 9: Rackmount Installation
Rackmount Installation Included with the Pro-Switch/8F are brackets allowing the switch to be mounted in a standard EIA-sized, 19-inch rack. The Switch can be placed in a wiring closet with other equipment. Perform the following steps to rack mount the switch: A. -
Page 10: Connecting To Power
Connecting to Power Connect the supplied AC power cord to the receptacle on the back of the switch, and then plug the cord into a standard AC outlet with a voltage range from 100 to 250 VAC. Figure 3. Rear panel view of Pro-Switch/8F Turn the switch on by flipping the ON/OFF switch on the rear of the unit to the I (ON) position.
