Underwater Kinetics C8 eLED Plus Specifications

High intensity eled dive light

Advertisement

Quick Links

C8 eLED
High intensity eLED
®
C8 eLED
Plus
The First High Intensity Dive Light That Runs
Brighter Underwater.
®
The C8 eLED
Plus combines two intense LEDs into one narrow, incredibly
even 10-watt beam pattern free of uneven spots and 'beam borders'. Unlike
conventional xenon filament lamp lights that grow dim with use, UK's unique
®
eLED
circuitry maintains constant brightness for the life of the batteries.
When longer burn times are needed, the user can switch to low power mode
to extend the life of its eight alkaline C batteries. Polarized battery contact
plates make it possible to interchange individual battery cells and rechargeable
packs as well as prevent potentially dangerous reverse battery insertion.
Featuring a proprietary "through the lens" heat sink and a unique dual power
electronic circuit to control the matched pair of 5-watt LED's developed by UK,
®
the new C8 eLED
Plus offers scuba divers a high-intensity dive light that runs
brighter underwater and maintains constant brightness throughout the
battery's life. For every one-degree drop in temperature, the new C8 eLED
Plus increases its lumen output by 2 percent. When immersed in water, heat is
drained from the LEDs, improving the lumen rating of the unit by 10 to 15
percent. By using the ocean as an immense heat sink, UK's through-the-lens
heat sink technology ensures that the two high-flux LEDs run at optimum
temperature and provide consistent illumination while diving.
®
The C8 eLED
Plus also features a dovetail handle slot, which is molded into
the case for balancing the location of optional pistol or lantern style grips.
Other features include a lamp that will not burn out, locking switch mechanism
which prevents accidental activation during travel and a rubber lens guard.
Offering more than twice the output of its predecessor (a maximum of 170
®
lumens), the C8 eLED
Plus is the brightest in its class, perfect for piercing the
darkness and looking into the great unknown.
®
Plus
®
dive light
matched high
intensity white
LEDs project a
beam which
travels farther
underwater
protective rubber
bezel cover
C8 eLED ® plus Brightness in Air and Water
water (alkaline batteries)
air (alkaline batteries)
2
4
6
8
Time (hours)
sealed case will not
corrode dent or leak
locking switch
for high/off/low
power selection
includes nylon
wrist lanyard
with rubber sleeve
and adjustable lock
UK's own
proprietary
LED conduction
cooling element
allows LED to
burn brighter
10
12
14

Specifications

Brightness
Lamp
Burn Time
Materials
Battery
Size
Test Depth
Model Numbers & Part Numbers
19502 C8 eLED
®
19504 C8 eLED
19505 C8 eLED
UK International
Uncompromising performance since 1971™
13400 Danielson Street
Poway, CA 92064
tel (858) 513-9100 fax (858) 513-9111
www.ukinternational.com
©2006 UK. All Rights Reserved. "UNDERWATER
KINETICS, " the logo and product names and logos
are trademarks of Underwater Kinetics.
tough ABS o-ring
3-position
available with
removable
pistol or
lantern grip
170/60 Lumens (High/Low)
2x High Intensity White LEDs
10/4 Hours (Air/Water)
ABS, Polycarbonate
8 C Alkaline
7.2 x 3.2 x 7.0 Inches
500 Feet Waterproof
®
Plus
Blue
®
Plus
Black
®
Plus
Fluorescent Yellow
