- Page 1 375 Marcus Boulevard Hauppauge, NY 11788 • • 631.273.0500 Fax: 631.273.0771 • e-mail: info@ultraviolet.com Extensive Product Information Available at: ultraviolet.com Document No. 98-1137A1 • Revised September 2007 • © 2003-2007 Atlantic Ultraviolet Corporation...
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY WARNINGS...3 SAFETY INSTRUCTIONS ...4 PRODUCT APPLICATION ...4 ...4 ONSTRUCTION ...4 IMITATIONS INSPECTION ...5 INSTALLATION ...5 ...5 OCATION LIND 24-EVO ...6 NSTALLATION OF LIND 24-EVO-2PM ...7 NSTALLATION OF ...7 ECOMMENDED PTIONS ...7 RECAUTIONS MAINTENANCE...8 LTRAVIOLET UTPUT DJUSTMENT LEANING ERMICIDAL AMPS... -
Page 3: Safety Warnings
SAFETY WARNINGS • All personnel should be alerted to the potential hazards indicated by the product safety labeling on this fixture. • The following conventions are used to indicate and classify precautions in this manual and on product safety labeling. Failure to observe precautions could result in injury to people or damage to property. This is the safety alert symbol. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS WARNING: To guard against injury, basic safety precautions should be observed, including the following: 1. Read and follow ALL safety instructions. WARNING: Avoid exposure to direct or strongly reflected germicidal ultraviolet rays. Germicidal ultraviolet rays are harmful to the eyes and skin. 3. -
Page 5: Inspection
IINSPECTION ® Hygeaire Remove the fixture from its shipping carton. Inspect the fixture, and wire leads for damage. Do not oper- ate if there is any damage to the fixture, and/or wire leads. Lamp(s) are packed separately, to ensure maximum protec- tion to the lamp(s). -
Page 6: Installation Of Lind 24-Evo
INSTALLATION LIND 24-EVO NSTALLATION OF The fixture is to be mounted on a plumb, vertical surface, at a minimum height of 6 ½ to 7 feet from the floor. Installation must be able to support approximately 16 pounds. Remove thumbscrews and open fixture to expose interior lamp holders and reflectors. Remove one mounting screw from each end of the reflector so that the reflector will be able to pivot toward the lamp holder. -
Page 7: Installation Of Lind 24-Evo-2Pm
LIND 24-EVO-2PM NSTALLATION OF Installation and all wiring should confirm to state and local electrical codes as well as the current National Electrical Code (NEC). Installation must be able to support approximately 32 pounds. After fixture is mounted and wired, open louver panels by removing thumbscrews. Install lamps (packed separately), close panels and replace thumbscrews. -
Page 8: Maintenance
MAINTENANCE ® Hygeaire is designed to operate with a minimal amount of maintenance. Besides occasional ultraviolet measure- ments to insure that ultraviolet intensities in the treated areas remain within the allowable exposure limits and above minimum levels, a regular cycle of cleaning, the germicidal lamp and interior reflectors, should be established based on visual inspection and experience. -
Page 9: Troubleshooting
TROUBLESHOOTING CAUTION: Always disconnect power to the fixture, before performing any service. Use personal protection equipment, such as gloves; long sleeves with no gaps between cuffs and gloves, and ultraviolet resistant face shield, if troubleshooting • IMPORTANT: This fixture is to be serviced ONLY by qualified, and appropriately licensed, personnel. Problem Possible Cause No electrical power…... -
Page 10: Replacement Parts
REPLACEMENT PARTS LIND 24-EVO Item No.: Description: Germicidal Ultraviolet Lamp, G24T6L Electronic Variable Output Ballast, 120v 50/60Hz Electronic Variable Output Ballast, 220-240v 50/60Hz Lamp Holder Set Safety Interlock Switch Thumbscrew, 8-32 x 3/8" Lg Plug, ½" ID Other replacement parts are available. Consult the Factory for specific requirements. Figure 3 - Replacement parts Model LIND 24-EVO Quantity: Part No. -
Page 11: Replacement Parts
REPLACEMENT PARTS LIND 24-EVO-2PM Figure 4 - Replacement parts Model LIND 24-EVO-2PM Item No.: Description: Germicidal Ultraviolet Lamp, G24T6L Electronic Variable Output Ballast, 120v 50/60Hz Electronic Variable Output Ballast, 220-240v 50/60Hz Lamp Holder Set Safety Interlock Switch Thumbscrew, 8-32 x 3/8" Lg Plug, ½"... -
Page 12: User Assistance
USER ASSISTANCE Atlantic Ultraviolet Corporation makes every effort to ensure that ® the Hygeaire Ultraviolet Air Disinfection Fixtures are products of superior quality and workman- ship. This manual describes the installation, operation and mainte- ® nance of the Hygeaire Ultraviolet Air Disinfection Fixtures.
