Ultra Start 32xx Series Owner's Manual

2way remote vehicle starter

Advertisement

Quick Links

Covers All 32xx and 33xx Series Remote Starters
-The system must be placed into Service Mode before any service work is started on the vehicle. It is
the sole responsibility of the vehicle owner to ensure that this is done. The manufacturer accepts no
liability or responsibility for accidental starting of the vehicle.
- CARBON MONOXIDE - Never Start in an Enclosed Building (Garage, Carport etc...)
- The Hood Pin Safety Switch Must Always be Installed!
- Never Install Automatic Transmission Remote Starters into a Manual Transmission Vehicle!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 32xx Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Ultra Start 32xx Series

  • Page 1 Covers All 32xx and 33xx Series Remote Starters -The system must be placed into Service Mode before any service work is started on the vehicle. It is the sole responsibility of the vehicle owner to ensure that this is done. The manufacturer accepts no liability or responsibility for accidental starting of the vehicle.
  • Page 2: Table Of Contents

    OWNER’S GUIDE Page 2 Table Of Contents Table Of Contents Welcome Feature List About Ultra Start FCC Notice Remote Starter Functions Remote Starting Extended Runtime Remote Stop Idle Mode Turbo Timer Mode Reservation Mode (Manual Transmissions Vehicles) Optional Features Lock Doors...
  • Page 3: Welcome

    Our limited lifetime warranty provides one of the best protection plans in the industry, giving both the consumer and the retailer confidence when they invest in an Ultra Start product. FCC Notice This device complies with Part 15 of the FCC rules.
  • Page 4: Remote Starter Functions

    OWNER’S GUIDE Page 4 Remote Star ter Functions Remote Starting 1.Press and release Button #3 on the remote transmitter. 1 2 3 2.The Park lights will flash and the horn (optional) will honk one time. 3. The remote will beep 3 times and the key icon will begin flashing. 4.When the vehicle has started, the system will flash the park lights four times then remain “On”...
  • Page 5: Reservation Mode (Manual Transmissions Vehicles)

    2WAY REMOTE VEHICLE STARTER Manual transmission remote starters must be set into Reservation Mode before the remote starter will activate. There are two different ways to place the system into Reservation Mode. The activation type of Reservation Mode is determined when the system is installed.
  • Page 6: Panic

    OWNER’S GUIDE Page 6 Optional Features... Lock Doors 1.Press and release button #1 on the remote transmitter. The park lights will 1 2 3 flash, the horn (optional) will honk one time and the doors will lock. 3. The remote will beep once to confirm. The Lock icon will appear on the LCD display of the remote.
  • Page 7 2WAY REMOTE VEHICLE STARTER Cold Start Mode Cold Start Mode will start the vehicle at a user selectable start interval or temperature setting. The vehicle can be set to start once every 1, 2, 3 or 4 hours in Timer Mode or to start at 0,-5,-15 or -25 Celsius in Temperature Mode (LT Models Only) for a maximum 12 starts.
  • Page 8: Lcd Display

    OWNER’S GUIDE Page 8 LCD DISPLAY STATUS CHECK MODE This feature is used to check the status of the alarm system or the remote starter. 1. To check the status press and release Button #4 on the remote transmitter. 2. The remote will display the icons of the active features on the LCD screen. STATUS ICONS These icons are located at the top of the LCD screen.
  • Page 9: Setting The Digital Clock

    OWNER’S GUIDE Setting The Digital Clock To Enter Clock Adjust Mode Press and hold buttons #1 and #4 until the minute portion of the clock located on the LCD begins to flash To Adjust The Time of day To set the minute, press and release button #3 to increase the minute or press button #2 to decrease the minute.
  • Page 10: Entering Service Mode

    OWNER’S GUIDE Page 10 Service Mode ATTENTION: TO AVOID SERIOUS INJURY, this remote start system must be set into Service Mode before any under hood servicing is started. Service Mode will prevent the vehicle from starting while the vehicle is being serviced. It is the sole responsibility of the vehicle’s owner to place the system into Service Mode.
  • Page 11: Diagnostics Chart

    2WAY REMOTE VEHICLE STARTER Diagnostics/ Diagnostics Chart If the remote starter does not activate when the start button is pressed the park lights will flash a diagnostic to indicate what shutdown input has been triggered. Example when the start button is pressed the park lights flash 3 times slowly. Looking at the chart below this would indicate that the system is in Service Mode.
  • Page 12: Limited Lifetime Warranty

    OWNER’S GUIDE Page 12 Limited Lifetime Warranty The manufacturer warrants to the original purchaser of their remote starters and alarms, that the product shall be free from defects in material and workmanship. However, should this product be proven to be defective, within a two year period from the original date of purchase, the manufacturer will, without charge to the purchaser (excluding any charges incurred to have the product delivered to the manufacturer), repair or replace any part of the remote starter and/or alarm which the manufacturer agrees...

This manual is also suitable for:

33xx series32 series33 series
