Summary of Contents for Hummer H-120 ARGB
- Page 1 H-120, H-240 & H-360 ARGB...
- Page 2 EN - Warning Improper installation will result in damage to the processor. Never switch the computer system on until the cooler and the fans are connected to the motherboard power connector. Always use the included screws. Screw the radiator with care to avoid damaging it. Electrostatic discharge (ESD) can damage system components.
-
Page 4: Warranty
The water cooler may cause interference with some motherboards. If you face an interference between Hummer cooler and your motherboard, please stop installing it. Be careful not to hurt yourself by the radiator while installating &... - Page 5 Backplate mounting holes illustration LGA 1366 LGA 1150 / 1151 / 1155 / 1156 Socket AM3+ / AM3 / AM2+ / FM2+ / FM2 / FM1 Socket AM4 Intel mounting Intel bracket mounting Align the arrows on the bracket and the pump base, turn the bracket clockwise to secure it to the pump base.
- Page 6 comes from previous page Clean the CPU surface and apply a Put the pump onto the CPU. Secure the thin layer of thermal grease onto block using the tightening nuts. the surface. Intel mounting: LGA2066 / 2011 installation Thread the LGA20XX standoff into the Clean the CPU surface and apply a Put the pump onto the CPU.
- Page 7 AMD mounting: AM4 / FM2(+) / FM1 / AM3(+) / AM2(+) installation Choose the right mounting holes Put the washer onto the long screws according to CPU Socket. Insert the first, and then fasten the knurled long screws through the backplate and threaded nuts into the screws.
- Page 8 Use the fan mounting screws to secure Use the radiator mounting screws to the fan(s) onto the radiator. secure the radiator to the case panel. HUMMER H-240 ARGB lighting connection guide CAUTION! Connection through motherboard RGB control Wrong connection will damage the...
