Ultra electronics MAGICARD Sprinter Hardware Replacement Manual

Instructions for replacement of printhead and printhead assemblies
Hide thumbs Also See for MAGICARD Sprinter:
1
2
3
4
5
6
7
8

Advertisement

Quick Links

Download this manual
MAGICARD PRINTER
INSTRUCTIONS FOR REPLACEMENT OF
PRINTHEAD AND PRINTHEAD ASSEMBLIES
WARNING - The Magicard colour printer contains hazardous voltages.
CAUTION - The following procedures involve contact with Electrostatic Sensitive
Devices. All Precautions for handling Electrostatic Sensitive Devices should be
followed at all times, including the use of a grounded wrist strap.
HOW TO USE THESE
INSTRUCTIONS
The following procedures are intended to be used for replacement of
Magicard
Thermal Printheads and Magicard Thermal Printhead Assemblies.
If replacing a Thermal Printhead Assembly do NOT carry out those parts of this
document written in italics . These procedures, for head angle adjustment, require some
previous Magicard product training or experience, and must not be undertaken by end
users. Therefore end users are supplied with replacement Printhead Assemblies, which
have already been adjusted for correct head angle.
3461/07/01 ISSUE 2
PRINTHEAD INSTALLATION & COMMISSIONING SPEC.
DCR No. 26106
I

Advertisement

loading
Need help?

Need help?

Do you have a question about the MAGICARD Sprinter and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ultra electronics MAGICARD Sprinter

Summary of Contents for Ultra electronics MAGICARD Sprinter

  • Page 1 MAGICARD PRINTER INSTRUCTIONS FOR REPLACEMENT OF PRINTHEAD AND PRINTHEAD ASSEMBLIES WARNING - The Magicard colour printer contains hazardous voltages. CAUTION - The following procedures involve contact with Electrostatic Sensitive Devices. All Precautions for handling Electrostatic Sensitive Devices should be followed at all times, including the use of a grounded wrist strap. HOW TO USE THESE INSTRUCTIONS The following procedures are intended to be used for replacement of...
  • Page 2 (a) Removing the cover Magicard 300 and Sprinter models. (1) Set the printer On/Off switch to off(0) and isolate from the mains supply. Remove the card cassette and Dye-Film from the printer. (2) Position the printer on its side with the rear of the printer facing towards you and remove the five securing screws from the base of the printer plus the...
  • Page 3 (b) Removing the cover Magicard Turbo models. (1) Set the printer On/Off switch to Off(O) and isolate from the mains supply. Remove the card cassette and the Dye-Film from the printer. (2) Position the printer upside down with the rear of the printer facing towards you and remove the four securing screws from the base of the printer plus the eight at the rear of...
  • Page 4 2. Removing old printhead/assembly (1) Remove the dye-film and dye-film carrier from the printer. (2) If a tye-wrap is fitted to the grey ribbon cable plug on the back of the printhead, cut this tye-wrap taking great care not to cut the ribbon cable itself. (3) Disconnect both cables from the printhead.

  • Page 5: The Printer

    3. Fitting the new printhead to the heatsink assembly (Magicard Dealers Only) CAUTION - The following procedures involve contact with the new printhead, all precautions for handling Electrostatic Sensitive Devices should be followed at all times, including the use of a grounded wrist strap. Furthermore great care must be taken not to touch or damage the printing elements of the printhead.

  • Page 6: Refitting The Cover

    (3) Check that the springs at the back of the printhead assembly are neatly compressed and are not bulging outwards or inwards. If they are bulging the assembly will have to be removed and refitted again until they remain neatly compressed. (4) If a head bar was fitted, refit it with its two securing screws ensuring that the left hand screw is also fitted through the terminal of the printhead earthing strap (Loctite 222 threadlocker should be used on these screws).
  • Page 7 (4) The printhead angle has been factory set. In order to ensure that it is still correct, compare the test card with the images on the back page of this document. N.B. If your test card shows a completely different test image from those on the back page, you will need to download the correct test image from the Ultra website at www.ultra.co.uk/support .
  • Page 8 7. And finally... If your new thermal printhead fails to produce a good test image after following the above steps then please contact your supplier. Too Negative Front or most of the grey square is pale and washed out. Density can suddenly increase in the last third of the square.
