Ultra electronics Magicard Latin Series Hardware Replacement Manual

Instructions for replacement of the printhead

MAGICARD LATIN SERIES PRINTER

INSTRUCTIONS FOR REPLACEMENT OF THE

CAUTION – The following procedures involve contact with Electrostatic

Sensitive Devices. All precautions for handling Electrostatic Sensitive Devices

should be followed at all times, including the use of a grounded wrist strap.

Your replacement printhead is despatched to you fully set up in the factory.

All you are required to do is:

1. Physically replace the printhead

2. Adjust the Printhead density setting in the Magicard Support Tools.

to the figure given on the enclosed test card.

Full instruction to carry out both of these tasks are given in the following text:

3506/07/01 Issue 1

PRINTHEAD INSTALLATION & COMMISIONING

PRINTHEAD

ASSEMBLY

HOW TO USE THESE

INSTRUCTIONS

LATIN SERIES

DCR No. 26759

Table of Contents

Need help?

Do you have a question about the Magicard Latin Series and is the answer not in the manual?

Page 1: Printhead Assembly
MAGICARD LATIN SERIES PRINTER INSTRUCTIONS FOR REPLACEMENT OF THE CAUTION – The following procedures involve contact with Electrostatic Sensitive Devices. All precautions for handling Electrostatic Sensitive Devices should be followed at all times, including the use of a grounded wrist strap.
Page 2 3506/07/01 Issue 1 LATIN SERIES DCR No. 26759 PRINTHEAD INSTALLATION & COMMISIONING...
Page 3 Removal of the Unserviceable Printhead Ensure that the printer is switched off and disconnected from the mains supply. Release the door catch and lift open the door assembly. 3. Locate and release the Quick Release Fastener on the Print head Assembly.
Page 4 Adjusting the Print Density To adjust the Print Density, ensure that there is power to the printer, the printer is connected to the computer and the printer is on line (Green light illuminated) CAUTION WHEN ADJUSTING THE PRINT DENSITY SETTING IT IS IMPORTANT TO NOTE THAT TOO HIGH A SETTING WILL CAUSE THE DYE FILM TO OVERHEAT AND ADHERE TO THE CARDS AN EXCESSIVELY HIGH SETTING WILL CAUSE THE DYE FILM TO...
