EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL
Wireless, programmable thermostat for all types of heating and air conditioning devices
MANUFACTURER: P.H.P.U. AS, Chumiętki 4, 63-840 Krobia, Poland
In order to take full advantage of thermostat capabilities please read this installation and
operation manual carefully.
This manual is intended for 26.08.2019 version of thermostat.
1.
THERMOSTAT APPLICATION
Euroster
4040TXRX
temperature in living and utility rooms. It is used to control the operation of CH boiler and
other heating system components. It controls electrical equipment, floor heating and air-
conditioning systems. Sensors used in Euroster 4040TXRX thermostats enable read-out and
programming accuracy of 0.1°C. The thermostat operates with two temperature levels:
comfort (day
) and economical (night
within the range of 5 °C...35 °C. The thermostat is programmable in seven-day cycles with
an accuracy of 0.5 hour, therefore it enables 48 temperature changes in 24 hours. It is possible
to program different time ranges for each day of the week.
2.
BASIC THERMOSTAT FUNCTIONS
•
Does not require leading cable connections between the thermostat and the controlled
device
•
User-friendly thermostat enabling easy control of temperature in living and utility rooms
•
Bidirectional communication ensures high operational reliability and resistance to inter-
ference
•
Ability to cooperate with the maximum of 6 4040RX receivers
•
Information on radio signal strength
•
Clear, back-lit E Ink display
•
Two temperature levels: comfort and reduced
•
0.5-hour accuracy of range programming
•
Simultaneous display of current and preset temperature value
•
Thermostat interlock with a selectable 4-digit code
•
Numerous useful functions: temporary temperature setting, constant temperature, va-
cation mode, discharged batteries indication
•
Temperature read-out accuracy of 0.1 °C
•
Possibility to switch the thermostat off with an active frost protection temperature after
the heating season
•
Temperature reading correction
•
Surface mounting
EUROSTER 4040TXRX
is a state-of-the-art, wireless thermostat
) temperature. Each temperature is modifiable
designed to
control
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for EUROSTER 4040TXRX
Summary of Contents for EUROSTER 4040TXRX
- Page 1 It is used to control the operation of CH boiler and other heating system components. It controls electrical equipment, floor heating and air- conditioning systems. Sensors used in Euroster 4040TXRX thermostats enable read-out and programming accuracy of 0.1°C. The thermostat operates with two temperature levels:...
- Page 2 EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL VISIBLE ELEMENTS OF 4040TX THERMOSTAT BODY a) Operation mode switch: • In thermostat heating mode it switches the thermostat on and off • In thermostat cooling mode it switches between heating and cooling operation...
-
Page 3: Installation
EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL INSTALLATION 5.1. Safety rules CAUTION! • Prior to the commencement of any installation works read this manual carefully! Incorrect installation and improper use may lead to serious hazards to users or other persons and result in property damage! •... -
Page 4: User Settings
EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL 5.4. Sample Connection Diagrams The following diagrams are simplified and do not cover all elements necessary for the correct installation. In arrangement with a 230 V 50 Hz device 1. Electrical connection block 2. - Page 5 EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL 6.2. Temperature level modification Two temperature levels are available in the thermostat: comfort temperature and economical temperature. These temperatures apply for all days of the week. Temperature values may be changed freely within the range of 5 °C...35 °C (in cabled sensor mode: 5 °C...85 °C). Factory settings are the following: comfort temperature 21 °C, economical temperature 20 °C.
- Page 6 EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL 6.6. TX THERMOSTAT SETTINGS In this menu you may change and select the following functions: • Date/time The date setting sequence is year > month > day. Using buttons select a year. Confirm with the central button. Set a month and day.
-
Page 7: Service Settings
EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL • Thermostat interlock The thermostat features a setting interlock function. A four-digit code of your choice may be entered. In such case it is not possible to change the settings. A setting interlock does not affect the thermostat operation. To activate the interlock, go... -
Page 8: Error Indication
EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL CAUTION! The floor temperature sensor is not included in the basic kit. Please order it separately. Connecting the sensor requires changing the thermostat basis, therefore the thermostat must be wall mounted. • Pairing mode Used to establish radio connection between the thermostat and the receiver (receivers). -
Page 9: First Start
EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL If you intend to pair several receivers (maximum 6) take the following steps: • after finding the first receiver (“1” displayed) • connect the second receiver to a power socket • press the receiver button 3 times – the blue LED will switch on •... -
Page 10: Maintenance
EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL 9.4. Receiver signal table Function Signaling Pairing Blue Reception of radio signal Green No signal Green – flashing Heating device switch-on Manual mode in heating mode Red – flashing Air-conditioning device switch-on Blue Manual mode in air-conditioning mode Blue –... -
Page 11: Kit Contents
14. SIMPLIFIED DECLARATION OF CONFORMITY P.H.P.U. AS AGNIESZKA SZYMAŃSKA-KACZYŃSKA hereby represents that the type of EUROSTER 4040 TXRX equipment conforms to the following directives: 2014/35/EU (LVD), 2014/30/EU (EMC), 2014/53/EU (RED), 2011/65/EU (RoHS). The complete text of the Declaration of EU conformity is available at the following Internet address: www.euroster.pl... -
Page 12: Warranty Certificate
EUROSTER 4040TXRX – INSTALLATION AND OPERATION MANUAL WARRANTY CERTIFICATE EUROSTER 4040TXRX thermostat Warranty terms: 1. The warranty is valid for 24 months from the device sale date. 2. Rights under the warranty shall be exercised within the territory of the Republic of Poland.
