- Page 1 Earphone User Guide...
- Page 2 We have taken all that we have learned about professional ear monitors and applied it to what we believe are the best consumer earphone products available on the market today: our UE5Pro and the UE5EB.
-
Page 3: Table Of Contents
Safe Listening & Proper Use ....5 Earphone Description ......6 Special Features . -
Page 4: Warnings
WARNINGS Be sure to read all warnings and instructions before using your Super.fi Earphones. Always turn music volume down on your listening device before inserting Super.fi Earphones into your ears. Once earphones are inserted, gradually increase the volume to a moderate listening level. Using earphones at high volumes can permanently damage your ears. -
Page 5: Safe Listening & Proper Use
Do not submerge or expose the earphones to water (see page 14 for Earphone Care and Maintenance). When using your earphones with an unfamiliar or unstable sound system (airplane, public access ports, etc…) make sure volume is low and is kept at a moderate level to prevent “break-in”... -
Page 6: Earphone Description
Super.fi 5 Pro Earphones Delivers professional quality sound by combining two precision balanced armatures in each earphone: one for lows and one for mids and highs. The dual armature technology provides exceptional frequency response and extended headroom delivering a rich, full-range, distortion-free personal audio experience. -
Page 7: Special Features
SPECIAL FEATURES OF THE SUPER.FI 5 PRODUCTS Feature Durable Construction Stylish Earphone Design Noise Isolating Components Flexible Ear Loops with Low Friction Cables Ear Tips Crush-Proof Metallic Storage Case Black Leather Travel Case Additional Accessories Included Limited Warranty Benefit Small form factor, lightweight, durable design ideal for active lifestyles. -
Page 8: Included With Your Purchase
INCLUDED WITH YOUR PURCHASE OF THE SUPER.FI 5 PRO AND 5 EB: • Earphone User Guide • Earphones (46 inch cord, cable adjuster and gold plated1/8 inch input plug) • Ear Tips Kit: 6 single flange silicone ear tips (2 small, 2 medium,... - Page 9 SUPER.FI 5 EB SUPER.FI 5 PRO Accessories Metallic Storage Case Leather Travel Case...
-
Page 10: Fitting The Ear Tips
FITTING THE EAR TIPS Super.Fi has included a variety of ear tips for you to choose from to ensure a good earphone seal for your ears. All ears are unique and you will need to determine which tips are most comfortable for you. -
Page 11: Attaching The Ear Tips
ATTACHING THE EAR TIPS The ear tips can be attached or removed by using a gentle grasping and twisting motion. The ear tip should fit securely over the ear conductor and once the ear tip is in place, the ear conductor should not be exposed. CARE AND CLEANING OF FLANGED SILICONE EAR TIPS The silicone ear flanges are reusable and need to be cleaned with an... -
Page 12: Earphone Insertion "Rock N' Roll
(Note: if you are using an unstable sound device please see page 15 for Using the Sound Level Attenuator). STEP 1 Identify the left earphone (marked with an “L”) and the right earphone (marked with an “R”). Holding each earphone with the cord pointing straight up and against your head, gently glide the ear tip into the ear canal. -
Page 13: Proper Earphone Removal
PROPER EARPHONE REMOVAL – REVERSE “ROCK N’ ROLL” To remove, grasp the earphone and gradually rock forward to break the seal. Once the seal is broken gently slide the earphones out of the canal, clean them for your next use and store them in either the leather travel case or metallic storage case. -
Page 14: Earphone Care & Maintenance
• Avoid physical abuse of earphones. Dropping or striking the earphones may damage components. • Do not pull on the cables to remove earphone from your ear. • Do not pull the cables to remove the input plug from a listening device. -
Page 15: Sound Level Attenuator
To use the sound level attenuator, insert the 1/8 inch input plug at the end of your earphone cable into the sound level attenuator and then plug the attenuator into the listening device. -
Page 16: Suggestions For Using Ear Tips
(marked with an “R”). Inserting one earphone at a time, gently grasp the top ridge of your ear and extend the ear upward and outward to open up the ear canal while you rock the earphone forward and then roll it back into your ear canal. -
Page 17: Troubleshooting
TROUBLESHOOTING DIMINISHED SOUND OVER TIME If you experience lower performance over time, use the cleaning tool to make certain that the ear conductor is unobstructed. NO SOUND If you are not receiving any sound, make certain that the jack is properly attached to your listening device and that the volume has been gradually increased. -
Page 18: Product Specifications
PRODUCT SPECIFICATIONS Specification Speaker Type Input Sensitivity Impedance Cable length Complete Assembly Weight Input Connector Frequency Response Noise Isolation OPTIONAL ACCESSORIES Description Bag of Disposable Foam Ear Tips (20 Count) Bag of Single Flange Silicone Ear Tips (10 Count), Black or Gray Bag of Double Flange Silicone Ear Tips (10 Count), Black or Gray Replacement Cables 46”... -
Page 19: Professional Custom Ear Monitors
This product conforms to European EMC Directive 89/336/EEC. Meets applicable tests and performance criteria in European Standard EN 55103 (1996) Parts 1 and 2, for residential (E1) and light industrial (E2) environments. UE, Ultimate Ears and SUPER.FI are trademarks of Ultimate Ears, LLC All Rights Reserved. -
Page 20: Limited Product Warranty
Product’s earphone external shell or in its earphone internal components for a period of two (2) years from the date of original retail purchase. If this Product is determined to be defective during the warranty period, the Company will, at its sole option: (1) repair the defective Product at no charge, using new or refurbished replacement parts;... -
Page 21: Making A Warranty Claim And Returning A Product
This limited warranty applies only to new Products purchased from Ultimate Ears or through authorized retail sellers. Warranty coverage will be provided only to the original retail purchaser. Transfer of any Product through any unauthorized distributor or retail seller renders this limited warranty null and void. Any Product sold by a private party or unauthorized distributor or retail seller is sold on an “as... -
Page 22: Limitations Of Liability
You are solely responsible for all shipping and insurance costs for returning the Product to the Company, and the Company will not reimburse you or compensate you for any such costs. After you have received an RMA from the Company and you have returned the Product to the Company for warranty service, the Company will determine if the Product is defective and whether it meets the warranty requirements of this limited warranty. -
Page 23: Register Your Product
If you are unable to register, please submit your name, address, email address, the product model number and the date you purchased the product by mail to: Ultimate Ears, LLC. Attn: Product Registration Dept. 5 Jenner Street, Suite 100, Irvine, CA 92618... - Page 24 Ultimate Ears, LLC. 5 Jenner Street, Suite 100, Irvine, CA 92618 T (866) 837-7734 F (949) 502-8379 www.UltimateEars.com UE, Ultimate Ears and SUPER.FI are trademarks of Ultimate Ears, LLC. All rights reserved. UG-P510-00 - 4/05...
