webEntry™ II Controller
OVERVIEW
The webEntry™ II controller is a unique, low cost 'entry level' access control
system that is at the forefront of today's IP-based security technologies.
The webEntry II controller uniquely combines a Web server interface and
access control functionalities into one control panel allowing complete system
administration and monitoring on any network connected PC using Microsoft
Internet Explorer web browser.
Available in various configurations, the webEntry II controller supports up to 64
doors and can manage up to 10,000 cardholders.
With an onboard battery backup the webEntry II controller can continue online
for approximately three hours.
webEntry™ II Controller
www.cemsys.com
FEATURES
• Self contained access
control system
• Controller managed via web
browser on any networked
PC – no additional control
software required!
• Supports four multidrop
networks of card readers (64
doors total) using RS485
CAT 5 cabling
• Full operational battery
backup available in the
event of power failure
• 64 MB compact flash for
database with expansion
available
• Storage capacity for up to
10,000 card records
• Database is retained even in
the event of battery backup
failure
• Upgrade path to form part
of a larger CEM AC2000
system

Advertisement

loading
Need help?

Need help?

Do you have a question about the Controller webEntry II and is the answer not in the manual?

Questions and answers

Summary of Contents for CEM Systems Controller webEntry II

  • Page 1 webEntry™ II Controller OVERVIEW The webEntry™ II controller is a unique, low cost ‘entry level’ access control system that is at the forefront of today’s IP-based security technologies. The webEntry II controller uniquely combines a Web server interface and access control functionalities into one control panel allowing complete system administration and monitoring on any network connected PC using Microsoft Internet Explorer web browser.
  • Page 2: Technical Specifications

    Onboard Database The webEntry II Controller supports its own database of up to 10,000 card records. The records include card numbers, access level and time zone details. The database allows the controller to validate card requests from readers. Rack mounted Enclosure The webEntry II Controller comes mounted in a sturdy 19- inch 1U rack-mounted enclosure providing easy integration into existing server locations.

This manual is also suitable for:

Webentry ii
