- Page 1 High Power Electronic Crimping Tool Model 6 PN 297060 Operation Guide © BGB Analytik AG Manual Part Number: DR-BGB-1907 July 2019...
-
Page 2: Safety Notices
The high power electronic crimping tools do not contain user serviceable parts. Support and Repair If the crimping tool is still in the warranty period, contact BGB Analytik office for support. If the warranty period has expired, please contact BGB Analytik. Find contact details on www.bgb-shop.com. -
Page 3: Table Of Contents
Table of Contents Safety Notices Maintenance and Cleaning Support and Repair Storage and Shipping Product Content Safety and Regulatory Certifications Symbols Instrument Specification Sound pressure Intended use Limits Warnings Warnings Disposal of battery Description and Setup Description Crimping tool setup Operation Connecting the power supply Settings... -
Page 4: Product Content
Product Content Part No. Description Part No. Description 297060 High Power Electronic Crimping Tool 295061 Base with Mounting Kit (Crimping Tool not included) Crimper Jaw Set Description 11mm 13mm 13mm 20mm 20mm for Flip Off Caps for Flip Off Caps Part No. -
Page 5: Safety And Regulatory Certifications
Warnings in the manual or on the instrument must be observed during all phases of operation, service and repair of this instrument. Failure to comply with these precautions violates safety standards of design and the intended use of the instrument. BGB assumes no liability for the customer‘s failure to comply with these requirements. -
Page 6: Instrument Specification
Instrument Specification Sound pressure Sound pressure LpA = 79 dB(A). Intended use Electronic Crimping Tools are intended for use in a laboratory environment, all other uses are prohibited. Limits Temperature 15 - 35 °C Maximum humidity 75% Pressure 0.75 - 1 bar... -
Page 7: Warnings
Warnings Warnings Wear safety glasses when crimping or decapping. The crimper or decapper jaws can pinch severely. Never insert fingers into the crimper or decapper. Do not disassemble or dispose of in fire. Use only the 12 v DC power supply supplied with the crimping tool. Use of other batteries may cause fire during charging or use. -
Page 8: Description And Setup
Please read through this entire guide to familiarize yourself with the operation of the tool before pro- ceeding. Use the same degree of care as you wold with any precision instrument. If there is any visible damage, contact BGB Analytik immediately. ③... -
Page 9: Operation
Operation Connecting the power supply Connect the 12 v DC supply to an electrical outlet with the power cord provided, and also to the con- nector on top of the crimping tool. (see Figure 1) Figure 1. Power supply connector at the top of the HPS crimper Settings Push... -
Page 10: Statistics
Statistics Using the Tool for Crimping The cycle button must be held down until the crimp is complete. If the switch is released early the crimper will retract and show an error. Adjust the crimper setting for satisfactory form and tightness. Note: Crimping the same vial two times will not generally give the same results and sometimes will result in vial breakage. -
Page 11: Selecting Or Changing A Jaw Set
Selecting or changing a jaw set Deconnect Power (necessary) To lock out the tool, press the lock button and rotate. Insert the jaw set into the bushing at the bottom of the tool. Push up against the spring load and then twist until the set locks into position. -
Page 12: Log Of Recent Crimping Results
Jaw Set Push Use the cycle button to make a selection. Log of recent crimping results... -
Page 13: Adjusting The Tool For Decapping Jaws
Adjusting the tool for decapping jaws Probably, the factory settings are satisfactory and it won‘t be necessary to adjust the de- capping jaws. If the caps are not removed sufficiently, the decapper jaws can be adjusted as follows: The 11mm decapping jaws should close around the neck of the vial and strip the cap off. If the cap is not removed completely, increase the strength of the decapper stepwise by pushing the button until the cap is removed completely. -
Page 14: Error Conditions And Display Codes
The decapper will have to be replaced or hanging on vials. repaired. Jaws are worn or broken. Please go in Contact with BGB Analytik. Find contact details on www.bgb-shop.com Motor does not come on or moves in Contact BGB Analytik. -
Page 15: Appendix - Accessory Base For Electronic Crimpers
Appendix - Accessory Base for Electronic Crimpers... - Page 16 Switzerland: BGB Analytik AG • Rohrmattstrasse 4 • 4461 Böckten • Phone +41 61 991 00 46 • Fax +41 61 991 00 25 • sales@bgb-analytik.com BGB Analytik SA • Route de Pré-Bois 20 • 1215 Genève 15 • Phone +41 22 788 49 43 • Fax +41 22 788 49 45 • sales.fr@bgb-analytik.com Benelux: BGB Analytik Benelux B.V.
