1135 SERIES WIRELESS SIREN
Installation Guide
Figure 1: 1135 Wireless Siren
DESCRIPTION
The 1135 Series Wireless Siren
provides up to 110 decibels of
annunciation. The 1135 includes
a wall tamper and cover tamper,
Survey LED operation, and two
batteries. Multiple sirens can be
activated simultaneously by the
panel using the Trip with Panel
Bell option. This option allows the
siren to follow the panel bell output
including the bell cutoff time.
The 1135E Wireless Siren also
features 128‑bit AES encryption.
Compatibility
• 1100X and 1100D Series
Wireless Receivers
• All DMP Burglary Panels
What is Included?
• One 1135 Series Wireless Siren
• Two 3.0 V Lithium CR123A
Batteries
• Hardware Pack
1

PROGRAM THE PANEL

To Follow Panel Bell (Option 1)
Refer to the panel programming guide as needed.
1. In OUTPUT INFO (XR150/XR550) or OUTPUT SETUP
(XT30/XT50, XTLplus, and XTLtouch), enter the output
number.
2. Enter the OUTPUT NAME and press CMD.
3. Enter the eight‑digit SERIAL# and press CMD.
Enter the SUPRVSN TIME and press CMD.
4.
5. Leave TRIP WITH PANEL BELL as the default YES.
6. Set BELL CUTOFF to 1‑15 minutes.
Note: Outputs operate with a 3 second response time when
used with the 1135‑W.
7. (1135E only) In SYSTEM OPTIONS, at 1100 ENCRYPTION,
select ALL to only add encrypted wireless devices to the
system. Select BOTH to allow both encrypted and non‑
encrypted wireless devices to be programmed.
8. (1135E only) The default passphrase appears at ENTER
PASSPHRASE. Press CMD to keep the default. Press any
select key or area to change the passphrase and enter an
8‑character hexadecimal string (0‑9, A‑F).
9. For wireless output troubles to display at a keypad on an
XR150/XR550 Series system, the keypad address must be
specified at the AUX 1 ZONES (Auxiliary 1 Zones) option in
the Status List programming menu. See the
Programming Guide (LT‑1232)
To Stand Alone as an Output (Option 2)
To allow the 1135 to be turned on or silenced by the panel, the
transmitter serial number must be programmed as an output in
OUTPUT INFORMATION. Refer to Silence the Sounder for more
information.
In OUTPUT INFO (XR150/XR550) or OUTPUT SETUP
1.
(XT30/XT50, XTLplus, and XTLtouch), enter the output
number.
2. Enter the OUTPUT NAME.
Enter the eight‑digit SERIAL# and press CMD.
3.
4. Enter the SUPRVSN TIME (Supervision Time) and press
CMD.
5. Set the TRIP WITH PANEL BELL option to NO.
XR150/XR550
for more information.
