Argus Green Stream VO-P 414 Service Manual

Volumetric pump
Hide thumbs

Advertisement

Quick Links

Service Manual for Volumetric Pump
®
green stream
VO-P
ARGUS 414 D
Made in Switzerland
IMPORTANT
This service manual is intended for the exclusive use of authorized persons who have been trained by ARGUS
Medical AG in the maintenance and repair of the infusion apparatus mentioned above.
ARGUS Medical AG shall not assume any responsibility for any manipulations which have been carried out on the
unit by a non-authorized person.
ARGUS Medical AG, CH-3627 Heimberg/Switzerland
(A member of the CODAN group)
14.148.- / A414D en / Software 1.30
14.10.2003
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Green Stream VO-P ARGUS 414 and is the answer not in the manual?

Questions and answers

พลอย
April 23, 2025

ราคาแต่ละชิ้นส่วนของเครื่อง infusion pumpรุ่นgreen stream VO-P argus 414

0

Related Manuals for Argus Green Stream VO-P ARGUS 414

Summary of Contents for Argus Green Stream VO-P ARGUS 414

  • Page 1 Made in Switzerland IMPORTANT This service manual is intended for the exclusive use of authorized persons who have been trained by ARGUS Medical AG in the maintenance and repair of the infusion apparatus mentioned above. ARGUS Medical AG shall not assume any responsibility for any manipulations which have been carried out on the unit by a non-authorized person.
  • Page 2 Drip chamber External drop detector green stream VO-P Air detector ml total ml total Tube guide ml inf. ml inf. h. min h. min Door (opened) Door handle Stop flow lock Display "infusion rate" ALARM ALAR M Display "total" START STOP MODE MODE...

  • Page 3: Table Of Contents

    Table of contents Page Special key inputs and configurations History and pump configurations printout Fault finding Replacement of parts Safety standard check Mechanical drawings Wiring diagram Bloc schematic 14.148.- / A414D en / Software 1.30 14.10.2003...

  • Page 4: Special Key Inputs And Configurations

    Special key inputs and configurations Special key inputs: Configuration CAUTION! The configuration possibilities mentioned below constitute a modification of the pump and may only be carried out by authorized persons. If the decimal points are flashing in a display, this display is ready to accept an input by means of the keys "100, 10, 1".
  • Page 5 Configuration mode without PIN code Hold both keys pressed START MODE MODE STOP Important! Do not release the keys "MODE" and "START/STOP" ml total ml inf. h. min START STOP ml total ml inf. h. min MODE MODE ml total ml inf.
  • Page 6 Programming mode: first input of write protection (code) IMPORTANT ! Remember to make a note of your code and keep it in a safe place. Description Display (8) Display (9) 1 "MODE" & Keep both keys pressed before switching "START/STOP" the unit on.
  • Page 7 List of the interrogation- and configuration functions: CAUTION! Before you make a new configuration or replace an EPROM or the mainboard make a note of the programmed values. Afterwards you can re-enter the old not writeprotected values. Address Write Default Function prot.
  • Page 8 Address Write Default Function prot. Value 0 = No Start with >= 1bar allowed 1 = Yes Start without infusion set 1 = Yes High resolution if calculated rate <100 ml/h 0 = No Micro mode after power on as default (Clear = 0.0 ml/h) 0 = No 0 = No 0 = No...
  • Page 9 Address Write Default Function prot. Value 0 = No 0 = No 0 = No 0 = No 0 = No 0 = No 0 = No 0 = No 0 = No 0 = No Set 2 definition 0 = No 0 = No 0 = No 0 = No...
  • Page 10 Address Write Default Function prot. Value 0 = No Set 4 definition 0 = No 0 = No 0 = No 0 = No 0 = No 0 = No 0 = No 0 = No 0 = No Infused sum in ml (xxxxyyyy) [xxxx .
  • Page 11 Address Write Default Function prot. Value Max. rate in ml/h (1...999 ml/h) Prime rate in ml/h (1...999 ml/h) Max. bolus rate in ml/h (1...999 ml/h) Max. bolus total in ml (1...99 ml) Pressure limit "PrL" default value micro mode (1..10 * 100 mbar) Pressure limit "PrL"...
  • Page 12 Special configuration options - Configuration of a reminder alarm for the safety standard check: First the service interval has to be configured either in months or in hours of operation, or both (addresses 393, 394). Next the last service date has to be entered on address 390. Any value higher than 0 entered at the adresses 393 and/or 394 will release the reminder alarm after the set service interval has elapsed (check also the correct settings of the internal clock).

  • Page 13: History And Pump Configurations Printout

    History and pump configuration printout Connecting of the ARGUS414 to the serial interface Caution: The infusion pump must be disconnected from the patient before any connection over the serial interface can be done. A connection of the ARGUS414 to a computer is useful to the read the actual configuration or history of the pump.
  • Page 14 History printout The transfer of the last events made on the pump can be done either by this way: Switch the pump on while keeping the key "100" pressed. Or by this way: Switch the pump on while keeping the keys "MODE" and "START/STOP" pressed and go in the configura- tion mode.
  • Page 15 Monitoring of the ARGUS414 Caution: The monitoring of the infusion pump ARGUS414 over the serial interface of a PC is only for demonstration purposes; any connection with patients has not been tested under the conditions of EN 60601-1 and are not allowed. Switch the pump on with an inserted filled infusion set.
  • Page 16 Format statusbyte-1: Format statusbyte-2: P 1 X X X X X X P 1 X X X X X X Format statusbyte-3: Format statusbyte-4: P 1 X X X X X X P 1 X X X X X X Format statusbyte-5: P 1 X X X X X X A sample of a monitoring session:...

  • Page 17: Fault Finding

    Fault finding The fault code in case of a failure is displayed by pressing "MODE" key (21). (F-XX) appears in display (9), and the source of the failure is listed in the table below: Error Error reason Assembly group F-21...22 ROM test Mainboard F-23...24...

  • Page 18: Replacement Of Parts

    Switch the unit off and disconnect the mains cable from the power outlet before opening the housing. The antistatic protection have to be strictly adhered to when the ARGUS infusion pump is disassembled (the use of an antistatic table mat and a grounded clip are recommended, for example).
  • Page 19 Pressure sensor calibration 1 Go to the program mode (without IV-administration set). 2 Enter in address 399 the value 1234. 3 Press the key "START/STOP" The display shows e.g. [Set] [-2- ]. Choose the IV set (no. 1 to 4) by pressing the key [1]. 4 Press the key "START/STOP"...
  • Page 20 Pressure sensor signal If the value meassured by the sensor after put in a tube without pressure is higher then the stored value Sensor signal for 1 bar, the pump cannot be started. mVolt 5000 System limit 4700 mV 4000 3000 2000 1000...
  • Page 21 Volume calibration general 1 Go into the program mode. 2 Decide which IV set should be calibrate and check its release address. - address 101 for IV set no. -1- - address 102 for IV set no. -2- - address 103 for IV set no. -3- - address 104 for IV set no.
  • Page 22 Volume calibration by the integrated program 1 Go to the program mode. 2 Enter in address 399 the value 123. 3 Press the key "START/STOP". The display shows e.g. [Set ] [-2- ]. Choose the IV set (no. 1 to 4) by pressing the key [1]. 4 Press the key "START/STOP".

  • Page 23: Safety Standard Check

    1 Visual check for damage, cleanness and completeness: - Housing, labels, accessories, connectors, power cable, etc. 2 Test the function of the stop flow lever: 3 Keep key "START" (ARGUS 200/400/404) or - Display shows the software release: V ...."MODE" (ARGUS 414) pressed while switching on - Display of 2, 4, 7, F., ml total, ml inf., h.min...

  • Page 24: Mechanical Drawings

    10.006 Air detector with O-sealing 11.105 Sealing 10.008 Transformer 230V 11.061 Clamp holder 10.016 Battery 12V/1,2Ah 11.127 Identification plate ARGUS 414 10.053 Clamp with screws 11.120Fixing screw M5x20 black 10.076 Main board ARGUS 414 12.001 Equipotential plug 10.084 Casing with rubber foot 12.007 Cable staff alert (opt.)
  • Page 25 11.128 11.081 10.036 10.077 11.019 11.021 Front A414 10.036 Display PC-board 10.077 Pump unit without door 11.019 Spring (Front-housing) 11.021 Cable assy 26pol 11.081 Front PVC 11.128 Frontpanel A414 14.148.- / A414D en / Software 1.30 14.10.2003...
  • Page 26 10.081 10.037 10.080 11.038 11.037 11.010 11.039 10.083 12.006 11.101 10.002 11.100 11.031 10.013 10.009 11.038 12.006 11.129 Pump unit A414 10.002 Camshaft 11.036 10.009 Clutch assembly kit 10.013 Stepper motor 10.078 10.037 Pressure sensor 10.082 10.078 Hall PC-board 10.080 Stop flow lever with spring 10.081 Stop latch with spring...
  • Page 27 10.089 10.056 11.111 11.008-1 (d=0,7 D=6,0 l=15,0 n=7,5) 10.079 11.017 Cover and Door A414 10.056 Cover with magnet 10.050 Door complet 10.079 Door with handle 10.089 External drop detector 01 11.008-1 Pressure spring no. 1 11.017 Door cover 11.111 Counter plate 14.148.- / A414D en / Software 1.30 14.10.2003...

  • Page 28: Wiring Diagram

    Serial External Nurse-call Interface Drop-Detector Alarm RS 232 Serial External Nurse-call Interface Drop-Detector Alarm RS 232 Internal Drop-Detector AC Input Trafo External Buzzer Batt. 12 V DC Air Bubble External Detector 15 V DC Hall Door + Wheel µC Buzzer Pressure Sensor Stepper...

  • Page 29: Bloc Schematic

    Bloc schematic 14.148.- / A414D en / Software 1.30 14.10.2003...
