Troy-Bilt 42027 Parts Catalog
Troy-Bilt 42027 Parts Catalog

Troy-Bilt 42027 Parts Catalog

21", 6 hp

Advertisement

Model
42027 — 21", 6 HP
Serial Number:
420270100101 - 420271199999
© 1997 Garden Way Incorporated
®
Parts Catalog
Snowthrower
Form 1774034 Rev B (9/97)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 42027 and is the answer not in the manual?

Questions and answers

Summary of Contents for Troy-Bilt 42027

  • Page 1 Model 42027 — 21", 6 HP Serial Number: 420270100101 - 420271199999 © 1997 Garden Way Incorporated ® Parts Catalog Snowthrower Form 1774034 Rev B (9/97)
  • Page 2 21", 6 H.P. Snowthrower TRACTOR ASSEMBLY 5 95 TOUCH-UP PAINT 200 Black Spray Paint 202 Loctite 242 201 Red Spray Paint 203 Tire Chains S/N: 420270100101- 420271199999 SERVICE PARTS...
  • Page 3 Loctite #242, .02 oz..A/R 1725381 Tire Chains ... NI 1760190 Wheel and Tire Assembly, (Incl. Refs. 56, 57 & 58)... 1774199 Service Kit ... 1771748 Lead Assembly ... 1774122 Bracket, Shift Decal ... 1773817 Decal, Instructions ... Model 42027 Qty.
  • Page 4 21”, 6 H.P. Snowthrower AUGER ASSEMBLY Add Loctite #242 to sheave bore when assembling S/N: 420270100101- 420271199999 See breakdown 49 A/R page 7...
  • Page 5 1737499 Grip ... 1723643 Adjusting Lever ... 1771274 Chute Deflector ... 1737940 Truss Head Bolt. 10-24 ... 1740471001 Gear Case Assembly (See Breakdown page 7) ... 1757861 Logo Decal ... 1757032 Loctite #242, .02 oz..NI Model 42027 Qty.
  • Page 6 21”, 6 H.P. Snowthrower TRANSMISSION ASSEMBLY — PEERLESS MODEL 700—005 Order parts from your local factory-authorized Peerless/Tecumseh dealer. Ref. # Part # Description 776061 Case, Transmission ... 772083 Cover, Transmission ... 776171 Shaft, Output ... 778121 A Gear, Spur (20 Teeth)... 786072 Spacer, Keyed ...
  • Page 7 1100276 1185568 1105620 1740468 1740472 1185840 1741775 1112634 1700182 Model 42027 GEAR CASE ASSEMBLY Description Thrust Race ... Worm Gear, 20T ... Spacer ... Woodruff Key, 1/4 x 7/8 ... Needle Bearing ... Pipe Plug, 1/4–18 ... Impeller Shaft ...
  • Page 8: Wiring Diagram

    “Engines–Gasoline” for the name of your nearest authorized engine dealer. An authorized engine dealer can handle all parts, repairs, and warranty service concerning the engine. Note: All TROY-BILT ® replacement parts must conform to our rigid quality specifications. Although some replacement parts we...
