- Page 1 Mortch International Ltd FALCON User’s Manual...
- Page 2 This manual gives you information about the general structure, function, operation and maintenance methods of FALCON. In order to enable your beloved motorcycle to render a best performance and a longer life, please read this manual carefully, pay particular attention to the running-in part in it and follow all the operating instruction. It is of great importance to make your riding safer and more comfortable.
-
Page 3: Table Of Contents
Mortch International Ltd CONTENTS Guidance …………………………………………………………………………………………… Names of parts ……………………………………………………………………………………… Controlling parts ……………………………………………………………………………………… …………………………………………………………………………………………… 6 Fuel tank Fuel and engine oil …………………………………………………………………………………… Starting pedal ………………………………………………………………………………………… Pre-riding inspection ………………………………………………………………………………… Engine starting ……………………………………………………………………………………… Running-in …………………………………………………………………………………………… Regular maintenance ………………………………………………………………………………… Tools ………………………………………………………………………………………………… Technical Parameters …………………………………………………………………………………... -
Page 4: Guidance
Mortch International Ltd □ □ □ □ Guidance Please keep safety in your mind and observe the regulations of transportation while enjoying your riding. Pay attention to the following rules: 1. Pre-riding inspection Please read the details in the relevant chapter for your safety. - Page 5 Mortch International Ltd Positions of the numbers The frame number and the engine number are for the purpose of registering the motorcycle. When your motorcycle needs inspection, repair or other special service, the number will enable you to get good service from our sale agency. Please note down...
-
Page 6: Names Of Parts
Mortch International Ltd □ □ □ □ Names of parts 8 9 1011 12 13 1 2 3 15 16 17 18 1. brake disc 6. side stan d 11. drum bra ke 16 . r ight fro nt tu rning ligh t 2. -
Page 7: Controlling Parts
Mortch International Ltd □ Controlling parts 1. Rear brake lever Left turning light Hold it tight and the rear brake works. Right turning light . Horn button . Danger signal button 3. Meters and indicating lights 2. Switches on the left . - Page 8 Mortch International Ltd 4. Front brake lever When the ignition switch is at ON position, hold Hold it tightly and the front brake works. the brake and press the button and then the engine starts. 6. Ignition switch ---ON ---OFF ---LOCK 5.
-
Page 9: Fuel Tank
Mortch International Ltd □ □ □ □ Fuel tank □ □ □ □ Fuel and engine oil Usage of the fuel tank lock: A. Gasoline 1. Insert the key and open the seat. High quality fuel is essential to the engine. -
Page 10: Pre-Riding Inspection
Mortch International Ltd □ □ □ □ Pre-riding inspection Please check the following parts before you drive. Items Inspection content Steering handlebar 1.Flexibility 2.No gap or loosing appearance 1.Travel of front brake and rear brake 2.No break on the cable Brake system 3.Flexible function... -
Page 11: Engine Starting
Mortch International Ltd □ □ □ □ Engine starting 1. Please check the volume of engine oil and 3. Engine Starting gasoline before starting. The main stand and Press the starting button and then the engine the side stand should not be stood up while will be started. -
Page 12: Running-In
Mortch International Ltd Warning Warning ◆ After the engine starts, the starting pedal ◆ 5 seconds is the maximum limit for each starting should be turned to its original position. and10 seconds is the minimum interval. Otherwise, it will affect the driver’s safety. -
Page 13: Regular Maintenance
Mortch International Ltd □ □ □ □ Regular maintenance Interval 1000 3000 6000 12000 Item Month New motor Battery Engine oil strainer Gasoline strainer Carburetor Air cleaner core Clean it every 2000km Spark plug Clean every 3000km, replace when necessary... - Page 14 Mortch International Ltd . Battery 12V/5.7Ah battery Warning ① When the voltage is less than 11.5V, please ◆ It has been fully adjusted to the highest use kicking start in stead of electric starting. position when manufactured. ② Put the ignition switch on position before battery replacement.
- Page 15 Mortch International Ltd b----Press the core in palm to squeeze the 5. Fuel detergent out of it. Never twist it in case that Refill the recommended unleaded gasoline it is broken. with an appointed number of 90# or higher c----Immerse the core into engine oil.
- Page 16 Mortch International Ltd ② Remove the oil plug for displacement to drain ②The rear brake (drum brake) the used oil. Turn the adjusting nut to get a proper stroke. ③ Reinstall the oil plug for displacement, paying attention to be tightened .
- Page 17 Mortch International Ltd ☆ Disk brake ② Check if there is any leakage or crack on the ◆Grip the brake lever and check the wear & tear oil pressed hose; ③ The brake lever should be kept with a certain indicator .
- Page 18 Mortch International Ltd Warning Warning ◆ Brake oil is corrosive material. It would damage ◆ The standard tire is 110/70-12 47J for front and rear tires. Another type of tire may cause and corrupt the painting of the part. It should be trouble.
-
Page 19: Tools
Mortch International Ltd 11. Gear oil Please use the recommended gear oil: SAE85W/90 Total capacity: 110ml Replacing capacity: 100ml How to change gear oil Stand up the main stand. oil plug for displacement oil plug for supplying Take off the oil plug for supplying. -
Page 20: Technical Parameters
Mortch International Ltd □ □ □ □ Technical Parameters Items Specifications Length 1965mm Size Width 700mm Height 1120mm Wheel base 1420mm Unloaded weight 98kg Weight Max. load 188kg Max. Speed 45km/h Capacity ≥21° Slope Spark plug A7RC Battery 12V/5.7AH Fuse... - Page 21 Mortch International Ltd Items Specifications Model 139QMA Type 4 stroke Cylinder Bore and stroke 39mm×41.4mm Cylinder volume 49cm Compression ratio 10.5±0.1:1 Engine Max. power 2.61 kw/8000r/min Max. torque 3.56N·m/5500r/min Carburetor Air cleaner Sponge core Ignition type Starting mode Electric/kicking start...
-
Page 22: Electrical Circuit Chart
Mortch International Ltd...
