OPERATOR'S MANUAL
21-inch Rotary Mower — Model 429
IMPORTANT
READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATION
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-
covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester
for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland,
Ohio 44136-0019.
Troy-Bilt LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
PRINTED IN U.S.A
FORM NO. 769-02338
01/18/2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 429 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Troy-Bilt 429

  • Page 1 (Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-0019. Troy-Bilt LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 PRINTED IN U.S.A FORM NO. 769-02338...
  • Page 2: Table Of Contents

    Troubleshooting... 12 Safety Labels ... 13 Parts List ... 14 Warranty ... Back Cover Model Number www.troybilt.com Customer Support contacting Customer Support. Serial Number TROY-BILT LLC P. O. BOX 3 6 1 1 3 1 CLEVELAND, OH 44136 330-558-7220 866-840-6483...
  • Page 3: Slope Gauge

    Use this page as a guide to determine slopes where you may not operate safely. Do not operate your lawn mower on such slopes. Slope Gauge WARNING Do not mow on inclines with a slope in excess of 15 degrees (a rise of approximately 2-1/2 feet every 10 feet).
  • Page 4: Safe Operation Practices

    DANGER: This machine was built to be operated according to the rules for safe operation in this manual. As with any type of power equipment, carelessness or error on the part of the operator can Safe result in serious injury. This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death.
  • Page 5: Safe Handling Of Gasoline

    The cutting blade continues to rotate for a few seconds after the engine is shut off. Never place any part of the body in the blade area until you are sure the blade has stopped rotating. 20. Never operate mower without proper trailshield, discharge cover, grass catcher, blade control handle, or other safety protective devices in place and working.
  • Page 6: Setup And Adjustment

    Setup and Adjustment Figure 3-1: Unfold handle and tighten hardware. Stand behind the mower as if you were going to ���� ���� ��� operate it. Your right hand corresponds to the right side of the mower; your left hand corre- sponds to the left side of the mower.
  • Page 7 5. Follow steps below to assemble the grass catcher (if needed). Make certain bag is turned right side out before assembling (warning label will be on the outside). a. Place bag over frame so that its black plastic side is at the bottom. b.
  • Page 8: Operating Your Lawn Mower

    Operating Your Lawn Mower Recoil Starter WARNING The blade control mechanism is a safety device. Never attempt to bypass its operations. Use extreme care when handling gasoline. Figure 4-1: The main components on the mower. Gasoline is extremely flammable and the vapors Now that you have setup your lawn mower, its important to become acquainted with its controls and features.
  • Page 9: Starting Engine

    WARNING: The operation of any lawn mower can result in foreign objects being thrown into the eyes, which can damage your eyes severely. Always wear safety glasses while operating the mower, or while performing any adjustments or repairs on it. Starting Engine WARNING: Be sure no one other than the operator is standing near the lawn mower...
  • Page 10: Maintaining Your Lawn Mower

    Maintaining Your Lawn Mower Figure 5-1: Areas to lubricate on the mower. Recommendations WARNING • Always observe safety rules when performing any type of maintenance. Always stop engine, • The warranty on this lawn mower does not cover disconnect spark plug, items that have been subjected to operator abuse and ground against or negligence.
  • Page 11: Blade Care

    Blade Care WARNING: When removing the cutting blade for sharpening or replacement, protect your hands with a pair of heavy gloves or use a heavy rag to hold the blade. Periodically inspect the blade adapter for cracks, especially if you strike a foreign object. Replace when necessary.
  • Page 12: Troubleshooting

    Problem Engine fails to start Trouble Shooting Engine runs erratic Engine overheats For repairs beyond the minor adjustments listed here, contact Occasional skips an authorized service (hesitates) at high speed dealer. Idles poorly Excessive Vibration Mower will not mulch grass Uneven cut Cause 1.
  • Page 13: Safety Labels

    Safety Labels Found On Your Lawn Mower �� ������ ��� ���� �� ������� �� ��� ������� ������ ��������� ����� �� ����� ������� �� �� ��� ������ ������ �� �������� ������� ������������ � � � � � � � � � �...
  • Page 14 � � � �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� �� � � �� �� �� �� �� �� �� �� �� �� �� �� �� � �� � �� �...
  • Page 15: Parts List

    731-04204 Blade Control Handle Cover 747-1161A Blade Control Handle 746-1130 Control Cable - 40” 726-0240 Cable Tie 664-04011 Grass Bag Assembly 747-04080 Grass Bag Frame 732-0700 Trailshield Wire 731-04998 Trailshield 747-04035 Rear Door Pivot Rod 10 731-04134A Rear Discharge Door 11 687-02068 Handle Bracket Assy - RH 687-02069...
  • Page 16 MANUFACTURER’S LIMITED WARRANTY FOR The limited warranty set forth below is given by Troy-Bilt LLC with respect to new merchandise purchased and used in the United States, its posses- sions and territories. “Troy-Bilt” warrants this product against defects in material and workman-...
