Introduction Thank you for purchasing this product. We feel you now own one of the finest pieces of outdoor power equipment available. All information in this manual is based on the latest product information available at the time of printing. This manual is considered a permanent part of the unit and must stay with the unit if resold.
Unit Service and Repair Contact your authorized dealer or the factory to service the unit. Provide your dealer with the unit’s model/serial number and the part’s description. Do not return parts directly to the factory. Warranty Service Warranty service is available from your authorized dealer. Left and Right Sides Left and right sides of the unit are determined from the operator's position, facing the direction of forward travel.
Section 1 Safety This is a safety alert symbol. It is used in this manual and on decals on the unit to alert you to potential hazards. Whenever you see this symbol, read and obey the safety message that follows it. Failure to obey the safety message could result in personal injury or property damage.
Page 5
Before Operation Before each use, clear work area of objects such as rocks, toys, wire, etc., which could be picked up and thrown by mower blades. Keep unit in safe operating condition. Check the following each time before starting unit: a.
Page 6
Safety (continued) without either the entire grass catcher or the guard in place. If you strike a foreign object, disengage attachment/PTO drive, shut off engine, wait for all moving parts to come to a stop. Remove ignition key. Inspect for and repair any damage before operating equipment again.
Page 7
If unit is unable to continue moving uphill, disengage attachment drive (PTO), check area on ground immediately behind unit, watch area to rear and proceed backward slowly. Do not operate unit on steep slopes where there is a risk of an overturn. Do not mow slopes with an incline of more than 10°.
Page 8
Safety (continued) 14. Check brake operation frequently. Adjust and service as necessary as indicated in Section 7 “Maintenance.” 15. Chock wheels (place blocks of wood in front and behind wheels) when performing maintenance with the parking brake off. Securely support unit if it must be raised for any reason.
If electrolyte contacts skin or eyes: a. Flush affected area with water. b. Apply baking soda to neutralize acid. c. Flush eyes with water for 10-15 minutes. d. Call a physician immediately. If electrolyte is swallowed: a. Drink large amounts of water or milk.
Section 2 Attachments, Kits & Specifications Engine ...*16 HP Briggs and Stratton (GTX 16) Governor Speed ... 3600 +/- 75 RPM Start ... Electric Transmission ... Eaton Model 11 Hydrostatic Transaxle ... Garden Way - Single Speed (GTX 16 & 18) Garden Way - Two Speed (GTX 20) Speeds ...Infinitely Variable Forward ...0 - 6.8 mph (GTX 16 &...
Page 11
Below is a list of attachments and kits available for this tractor. The information below is the most current, available at the time this manual was printed. Check with your nearest authorized dealer for current information. Attachment, Kits and Specifications (continued) Number Description 14025...
Section 3 Controls Attachment Lift Lever (G) Auxilliary Hydraulic Lever Hour Meter (H) (Model 13076 Only) Light Switch (E) Cruise Control Switch (Models 13074 & 13076) Choke Lever (C) Brake/Neutral Pedal (B) Fig. 3 Two-Speed Transmission Lever (Model 13076 Only) Fuel Gauge (Models 13074 &...
Page 13
Identification and Function of Controls and Features Before operating this tractor, become familiar with the function and location of each control. This will help ensure proper, safe and efficient operation. See the “Operation” section for instructions. A. Parking Brake Lever Locks brake.
Section 5 Before Operation MODELS 13074 and 13076 Fig. 5-1 DANGER BEFORE OPERATION, READ AND UNDERSTAND ALL CONTROL, OPERATING, AND SAFETY INSTRUCTIONS IN THIS MANUAL. READ ALL MATERIAL PROVIDED WITH ANY ATTACHMENTS USED WITH THE UNIT. READ AND FOLLOW ALL INSTRUCTIONS ON THE DECALS ON THE UNIT AND ATTACHMENTS.
Lift seat adjustment lever (Z) and slide seat forward or backward. Models Fig. 5-2 13074 & 13076 Loosen adjustment knobs (ZZ), slide seat forward or backward. Fig. 5-3 Model 13101 4. Visually Check Check for and repair loose or missing screws, nuts, and damaged parts.
Section 6 Operation Auxilliary Attachment Lift Hydraulic Lever Lever (K) (Model 13076 Only) Light Switch (E) Cruise Control Switch (Models 13074 & 13076) Choke Lever (G) Brake/Neutral Pedal (F) Fig. 6-1 Starting Engine Move the attachment/PTO drive switch (X, Fig 6-1) to "OFF". The starter will not activate unless this switch is off.
PLACE. NEVER USE HANDS TO FEEL FOR HYDRAULIC LEAKS. HOT HYDRAULIC FLUID LEAKING AT HIGH PRESSURE COULD PENETRATE SKIN. ® USE ONLY TROY-BILT APPROVED ATTACHMENTS. Other attachments could damage the hydraulic system and void the warranty. INSPECT ALL HYDRAULIC COMPONENTS FOR HIGH PRESSURE LEAKS BEFORE TESTING OR REPAIRING.
Moving Tractor Manually DO NOT TOW OR PUSH THIS TRACTOR WITH ANOTHER VEHICLE OR RISK DAMAGING THE DRIVE SYSTEM. When pushing the tractor, push it slowly to prevent a temporary lock-up of rear wheels. 2-Speed Models (20 HP Units): Stop tractor when shifting.
Section 7 Lubrication and Maintenance MODELS 13074 and 13076 Fig. 7-1 WARNING BEFORE PERFORMING ANY MAINTENANCE OR ADJUSTMENTS TO THE TRACTOR, ENGINE OR ATTACHMENTS: DISENGAGE THE ATTACHMENT/PTO DRIVE, SHUT OFF THE ENGINE AND WAIT FOR ALL MOVING PARTS TO STOP. SET THE PARKING BRAKE AND ALLOW THE ENGINE AND MUFFLER TO COOL.
Close oil drain valve (L). Place cap on oil drain tube. Install side panel. Engine Air Intake Screen STOP ENGINE BEFORE CLEANING AIR SCREEN! Check engine air intake screen (C, Fig. 7-1) for debris and clean regularly. A dirty air screen and engine can reduce airflow and cause the engine to overheat.
Maintenance (continued) Carburetor The carburetor is adjusted at the factory. It should not need resetting. If black exhaust is noted, check the air cleaner first. An over-rich fuel mixture is usually caused by a poorly serviced or clogged air cleaner element, not an improperly adjusted carburetor.
Proper Jack Placement A floor jack (not a bottle jack) or an overhead hoist may be used to lift the front of the tractor. Do not attempt to use any other device to lift the tractor. WARNING USE EXTREME CARE WHEN JACKING OR HOISTING TRACTOR.
Maintenance (continued) Transmission Oil Filter: Replace filter after first five hours and every 100 hours thereafter. Filter is located under the tractor, in front of the transmission. Hydrostatic Neutral Adjustment Hydrostatic neutral is set at the factory. If tractor creeps forward or backward while hydrostatic pedal is in neutral position, adjust as follows: Shut off engine and wait for all...
NOTE: A hand type grease gun is recommended when greasing your unit. High pressure type grease guns could cause damage to the fittings and bearing seals. Lubricate all linkages, levers and pins not equipped with grease fittings, with an oil can once each week; more often depending on operating conditions.
Maintenance (continued) Troubleshooting Chart Problem Engine turns over but won't start. Engine will not turn over. Engine doesn't turn over but start light comes on. Starts only after repeated tries. Stalls in a few seconds. Stalls when hot. Idles rough. Engine overheats.
Storing the Tractor Always store tractor in a dry and protected place when not in use. If tractor will not be used for a season, store it in the following manner. CLEAN: Completely clean all accumulated dirt or grass from all parts –...
Page 28
For customer assistance, contact your nearest authorized dealer or: GARDEN WAY INCORPORATED • 1 Garden Way • Troy, New York U.S.A. 12180 Customer Service: 1-800-437-8686 • Technical Service: 1-800-520-5520 • Parts Service: 1-800-648-6776 • FAX: (518) 391-7332 Outside the U.S.A. and Canada: Customer Service: (518) 391-7007 •...
