- Page 1 IDS NXT Setup IDS NXT rio IDS Imaging Development Systems GmbH Dimbacher Str. 6-8 D-74182 Obersulm, Germany T: +49 7134 96196-0 E: info@ids-imaging.com W: http://www.ids-nxt.com...
-
Page 2: Table Of Contents
5 IDS NXT rio ............................8 5.1 Ambient conditions ........................8 5.2 System requirements ........................9 5.3 Connecting a IDS NXT rio ......................9 6 Electrial specifications ........................11 6.1 Pin assignment GigE connector (RJ45) ..................11 6.2 Pin assignment I/O connector ..................... 11 7 Status LED ............................ -
Page 3: Preface
Please contact your local IDS distributors for first level support in your language. For a list of IDS distributors worldwide please go to our website http://www.ids-nxt.com. -
Page 4: Symbols In The Manual
IDS NXT: Setup IDS NXT rio 2 Symbols in the manual Symbols and hints This symbol indicates hints with useful information for better understanding and using features and functions. This symbol indicates important warnings for product safety to prevent damage. -
Page 5: Safety Instructions
All warranty will be spoiled in this case. Intended use IDS industrial cameras are to be used to capture images for visualization and image processing tasks. They are designed for use in industrial environments. Please comply with the requirements for the proper use of this product. - Page 6 IDS NXT: Setup IDS NXT rio Operation and power supply The camera power supply must meet the requirements for SELV (safety extra low voltage)/LPS (limited power source) or ES1/PS2. WARNING! Non-approved power supplies for camera operation may cause painful or dangerous electric shock.
-
Page 7: Standards And Directives
IDS NXT: Setup IDS NXT rio 4 Standards and directives (only valid for devices with housing) IDS Imaging Development Systems GmbH hereby confirms that this product has been developed, designed and manufactured in compliance with the following European directives ·... -
Page 8: Ids Nxt Rio
55 °C (131 °F). Notes on ambient conditions · Avoid high air humidity levels and rapid temperature changes when using IDS cameras. · Temperatures below +4 °C (39 °F) combined with excessive relative air humidity levels can cause icing. -
Page 9: System Requirements
IDS NXT: Setup IDS NXT rio Vibration and shock resistance Vibration and shock resistance of the cameras corresponds to EN 60068-2-6 and EN 60068-2-27. 5.2 System requirements For operating the cameras, the following system requirements must be met: Camera IDS NXT rio... - Page 10 IDS NXT: Setup IDS NXT rio · GigE network adapters for PCI slots are limited in its transfer rate to approximately 80-90 MByte/s. · It is recommended to set the "Receive Descriptors" in the network card settings to the maximum value.
-
Page 11: Electrial Specifications
Bl_DC- cam era rear Bl_DB- view Bl_DD+ Bl_DD- The RJ45 socket of the IDS NXT rio complies with the IEC 60603-7 standard. 6.2 Pin assignment I/O connector 12-pin M12 connector (Attend 216A-12MSR) Signal Description VBUS Power supply: 12-24 V DC +20 %... - Page 12 12 V. To supply the IDS NXT rio camera with power using PoE or PoE+, you can use PoE injectors or switches that are compatible with IEEE standard 802.3af or IEEE standard 802.at.
-
Page 13: Status Led
IDS NXT: Setup IDS NXT rio 7 Status LED Fig. 4: Status LEDs The camera has two LEDs that indicate information of the current status. · LED 1: camera status (two-color) · LED 2: Network status (two-color) LED 1 Camera is off/no power... -
Page 14: Setup In Network
After launching, you will be in the "Device overview". IDS NXT Cockpit scans the network for IDS NXT cameras and lists them in this overview. A log-on to IDS NXT cameras is possible by direct entry of an IP address. -
Page 15: Logging On To The Device
The passwords for the user classes "admin" and "service" are "ids" when delivered. They can be changed using the administrator profile. No password is required for the "user" user class. How to change the passwords is described in the manual "IDS NXT - Operation with the IDS NXT Cockpit". -
Page 16: Network Configuration In Ids Nxt Cockpit
8.5 Network configuration in IDS NXT Cockpit After logging onto a IDS NXT camera, you will see the “Dashboard” which displays various device information. To set the network parameters select "Configuration > Network". · The "Obtain IP address automatically (DHCP)" option is activated by default. It is recommended to keep this setting. -
Page 17: Firmware Update
IDS NXT: Setup IDS NXT rio 9 Firmware update The IDS NXT rio cameras are based on the Vision standard and can be updated like a Vision camera using a GUF file. Prerequisites · Install the software package IDS peak. -
Page 18: Troubleshooting/Faq
If the camera is running in the service firmware , the IP address can only be changed using Vision-compliant tools, e.g. the IDS Vision Cockpit. The change of the IP address is only effective as long as the camera is running in the service firmware. Passwords How can the administrator password be reset? ·... -
Page 19: Resetting The Camera To Factory Settings
60 seconds. IDS Vision Cockpit Fig. 8: Reset to factory settings 1. Open IDS Vision Cockpit (Windows: either via the icon on the desktop or under "Start > All Programs > IDS peak > IDS Vision Cockpit“). 2. Open the camera. -
Page 20: Booting The Camera In Runtime Firmware
IDS Vision Cockpit Fig. 9: Boot runtim e firm w are in IDS Vision Cockpit 1. Open IDS Vision Cockpit (Windows: either via the icon on the desktop or under "Start > All Programs > IDS peak > IDS Vision Cockpit“). - Page 21 The camera powers off briefly and boots in the service firmware. ids_devicecommand Use the ids_devicecommand tool from IDS peak to boot the camera in runtime firmware. Fig. 10: Boot the runtim e firm w are 1. Open the ids_deviceupdate tool at the command prompt.
-
Page 22: Index
IDS NXT: Setup IDS NXT rio - A - - N - Ambient conditions Network cable Authorization admin card service initial setup user Network adapter - C - - O - Camera Operating system factory setting 18, 19 Linux log on...
