Model #: S506-18N
18-inch (0.5M) Internal SAS Cable mini-SAS (SFF-8087) to mini-SAS (SFF-8087)
Description
Internal Mini-SAS Double-Ended Plug with Sidebands, SFF-8087 to SFF-8087, 36 Circuits, 30 AWG, 18 in. length, controller to backplane.
Package Includes
18inch Internal SAS Cable, SFF-8087 to SFF-8087
Features
Positive and passive latching ensures that the plug remains mated to receptacle
All internal mini SAS assemblies are capable of supporting SAS/SATA generation I and II bandwidths
Reduced mechanical size offers up to 4 times the port density of the current x4 solution
For Controller to Backplane applications
Specifications
OVERVIEW
Intended Application
Model Type
INPUT
Cable Length (in.)
PHYSICAL
Color
Style
CONNECTIONS
Connector A
Highlights
Connecting Drives
Internal
18
Black
SCSI
SFF-8087
Positive and passive latching ensures that the plug remains mated to
receptacle
All internal Mini-SAS assemblies are capable of supporting SAS/SATA
generation I and II bandwidths
Reduced mechanical size offers up to 4 times the port density of the current x4
solution
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail:
saleshelp@tripplite.com
