Tripp Lite Internal SAS Cable S502-20N Specifications

20-inch (0.5m) internal sas cable - 4-in-1 32pin (sff-8484) to 4 x 7pin cable
Hide thumbs


Advertisement

Model #: S502-20N
20-inch (0.5M) Internal SAS Cable - 4-in-1 32Pin (SFF-8484) to 4 x 7pin Cable
Description
Tripp Lite's 32-pin SFF-8484 to 4 x 7-pin internal SAS cable (Serial Attached SCSI) cable is ideal for connecting SAS controllers to individual
SAS/SATA disk drives. High-performance cable provides differential pair signaling with less than 5ps/m in pair skew, improved EMI protection, and
3.0Gbs data rate with rates up to 6.0Gbs. Thinner, flexible cable enables more efficient routing, with improved airflow and thermal mechanics.
Configuration of storage devices is simplified. Tripp Lite SAS assemblies are RoHS compliant and feature a
Applications
SAS Host Bus Adapters (HBA) such as LSI Logic SAS3442X-R and SAS3442E-R, utilizing internal SFF-8484 mating connectors
System Requirements
SAS Host Bus Adapter and Backplane with SFF-8484 mating connector
Package Includes
0.5-Meter ( 20 inch ) Internal SAS 4-in-1 SFF-8484 to 4 x 7pin Cable
Features
SFF-8484 to 4 x 7pin SAS Cable - 0.5 meter ( 20inch )
Supports data rates up to 3.0Gbs
Thin, flexible cable for easy routing and increased airflow
RoHS Compliant

Specifications

OVERVIEW
Intended Application
Model Type
INPUT
Cable Length (m)
Highlights
Connecting Drives
Internal
0.5
32-pin SFF-8484 to 4 x 7-pin internal SAS cable
Supports data rates of up to 3.0Gbs
Straight backshell configuration
0.5 meter in length ( 20 inch )
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail:
saleshelp@tripplite.com
