INSTRUCTIONS
05011451(200)
2760 Ridgeway Court
Walled Lake, MI 48390-1662 USA
1-800-444-4351
This manual contains important information
concerning the installation and operation of the
equipment listed below. Read manual
thoroughly and keep for future reference.
Fax 248-960-7109
Part# 1000163
3-7-01
TN
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for HERKULES Partsmobile Series
Summary of Contents for HERKULES Partsmobile Series
- Page 1 This manual contains important information concerning the installation and operation of the equipment listed below. Read manual INSTRUCTIONS thoroughly and keep for future reference. 05011451(200) Herkules Equipment Corporation 2760 Ridgeway Court Walled Lake, MI 48390-1662 USA 248-960-7100 1-800-444-4351 Fax 248-960-7109...
- Page 2 Model Information: Shelf Capacity Shelves Weight Dim. A Dim. B Dim. C Model Capacity (kg.) (per unit) (kg.) (mm.) (mm.) (mm.) (kg.) 100 lbs 47 in. 21.75 in. 66.5 in. PM-1 600 lbs. 200 lbs (272) (91) (45) (1194) (552) (1689) 600 lbs.
- Page 3 Partsmobile Parts Layout Figure 2 Top Shelf Assembly #1001419 S-Hook #001-600A *Small Shelf #1001418 *Parts Tray #001-401 Upright Tube #1001421 *Middle Shelf #1001417 Large Shelf #1001416 Upright Tube #1001420 Ridged Caster #001-700 05011451(200) *Support Peg #10185 Swivel Caster Bottom Shelf #001-701 #1001415 *PM-1 Only...
