Model – Alpha DX Antenna
Operating Manual, Version 1.3, June 25, 2018
Overview
The Alpha DX is designed to operate from 10 through 80 meters as a capacity hat antenna. It is
rated at 250W PEP SSB, 100W CW, and 50W Digital.
Operation
The Alpha DX Antenna system is a complete ultra‐portable multiband and multipurpose HF
antenna that fits in an included canvass Field Bag. This system requires no moving clips on coils
or readjusting of whips for tuning. An integrated leveling bubble enables precise spatial
alignment of all elements, which results in equal take‐off angles for your signal. You may also
use an external antenna tuner if your antenna is installed over a poor ground or not placed in
a clear area.
Excess RF Exposure Warning
In the United States, the Federal Communications Commission has established guidelines for
human exposure to Radio Frequency (RF) electromagnetic fields. The commission's
requirements are detailed in parts 1 & 2 of the FCC's rules and regulations {47 CFR, 1.1307(b),
1.1310, 22.1091, 2.1093}. It is the responsibility of the owner/operator of this device to follow
all applicable warnings and precautions regarding human exposure to RF fields. Additional
references: http://www.arrl.org/rf‐exposure
Support Contacts
If you have questions about your antenna, please feel free to contact us.
Email: support@alphaantenna.com
Phone: 1‐888‐482‐3249
WEB: www.alphaantenna.com
Page 1
Advertisement
Table of Contents
Related Manuals for Alpha Antenna DX
Summary of Contents for Alpha Antenna DX
- Page 1 ______________________ Model – Alpha DX Antenna Operating Manual, Version 1.3, June 25, 2018 Overview The Alpha DX is designed to operate from 10 through 80 meters as a capacity hat antenna. It is rated at 250W PEP SSB, 100W CW, and 50W Digital. Operation The Alpha DX Antenna system is a complete ultra‐portable multiband and multipurpose HF antenna that fits in an included canvass Field Bag. This system requires no moving clips on coils or readjusting of whips for tuning. An integrated leveling bubble enables precise spatial alignment of all elements, which results in equal take‐off angles for your signal. You may also use an external antenna tuner if your antenna is installed over a poor ground or not placed in a clear area. Excess RF Exposure Warning In the United States, the Federal Communications Commission has established guidelines for human exposure to Radio Frequency (RF) electromagnetic fields. The commission’s requirements are detailed in parts 1 & 2 of the FCC’s rules and regulations {47 CFR, 1.1307(b), 1.1310, 22.1091, 2.1093}. It is the responsibility of the owner/operator of this device to follow all applicable warnings and precautions regarding human exposure to RF fields. Additional references: http://www.arrl.org/rf‐exposure Support Contacts If you have questions about your antenna, please feel free to contact us. Email: support@alphaantenna.com Phone: 1‐888‐482‐3249 WEB: www.alphaantenna.com Page 1...
- Page 2 Assembly A) Locate then assemble the Alpha Match and Tripod: Screw the Alpha Match onto the Tripod (A), taking care not to cross‐thread either one. B) Locate and install the four black 26 inch MilStick elements, and screw each hex nut onto the bolts (B). C) Locate the 12 foot Counterpoise wire & secure the ring connector over the bolt (C) with the loose hex nut. C.1) Proper placement of 12 foot Counterpoise is so that it is run above one of the tripod legs, otherwise the system will tip over. This is a Counterpoise, so please ensure this wire slopes away from the antenna and isn’t laid on the ground, before staked. D) Locate and install the one black 26 inch MilStick element, to the top bolt of the Alpha Match (D to D). E) Extend the Legs (E) on the Tripod, and secure each with the locking mechanism. E.1) Extend and stake the NVIS elements into the ground with the included aluminum stake. F) Rotate the Crank (F) till the mast is fully extended, & tighten the set screw. G) Connect your coax to your equipment first and then to the SO239 ...
- Page 3 Page 3...
