Tripp Lite B132-004A Specifications

Model #: B132-004A
VGA + Audio over Cat5 Extender 4-Port Transmitter
Description
Tripp Lite's B132-004A allows you to split a single VGA Video and Stereo Audio signal into 5 (1 local, 4 remote). Increase the number of
displays/speakers to up to 25 (1 local, 24 remote) by daisychaining up to six B132-004A units together. When used with a B132-100A or
B132-100A-WP-1 remote unit, you can extend a 1920 x 1440 (60Hz) Video and Stereo Audio signal up to 500 ft., or a 1024 x 768 (60Hz) Video and
Stereo Audio signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable. For optimal video image quality between 500 and 1,000 ft., use
Zero-Skew cable, such as Tripp Lite P524-01K. Includes mounting hardware that allows unit to be wallmounted, rackmounted or pole mounted. Up to
three B132-004A units can be mounted in 1U of rack space using a Tripp Lite B132-004-RB Extender/Splitter 19 in. rackmount bracket. Ideal for
digital signage situations, such as retail, schools, churches, etc.
Package Includes
4 Port Extender/Splitter local (Transmitter) unit
1 ft. VGA + Audio daisychain cable
Mounting hardware
External power supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)
Owner's Manual
Features
Splits a single VGA Video and Stere Audio signal into 5 (1 local, 4 remote)
Increase the number of displays/speakers to up to 25 (1 local, 24 remote) by daisychaining up to six B132-004A units together
When used with a B132-100A or B132-100A-WP-1 remote unit, extends a 1920 x 1440 (60Hz) Video and Stereo Audio signal up to 500 ft.,
or a 1024 x 768 (60Hz) Video and Stereo Audio signal up to 1,000 ft., when using 24Awg, Solid Wire Cat5e/6 cable
For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable, such as Tripp Lite P524-01K
Includes mounting hardware that allows unit to be wallmounted, rackmounted or pole mounted
Up to three B132-004A units can be mounted in 1U of rack space using a Tripp Lite B132-004-RB Extender/Splitter 19 in. rackmount bracket
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule purchases

Specifications

OVERVIEW
Display Style
PHYSICAL
Shipping weight (lbs)
Highlights
Cat5 Extender
1.8
Splits a single VGA Video and Stereo Audio signal into 5 (1 local, 4 remote)
When used with a B132-100A or B132-100A-WP-1 remote unit, extends a
1920 x 1440 (60Hz) Video and Stereo Audio signal up to 500 ft., or a 1024 x
768 (60Hz) Video and Stereo Audio signal up to 1,000 ft., when using 24Awg,
Solid Wire Cat5e/6 cable
For optimal image quality between 500 and 1,000 ft., use Zero-Skew cable,
such as Tripp Lite P524-01K
Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule
purchases
