MX28
• Three stereo inputs - 2: 1/4" unbal per channel.
• Individual 1/4" Right and Left outputs
• Pan control for each channel
• Two Stereo Phone Outs; 1/4" and 1/8" (3.5mm)
The MX28 is the ideal mixer for anyone needing to mix up to
three stereo signals. Keyboards, stereo guitar effects, even
sources like CD players or cassette players can be mixed together
maintaining their true stereo separation.
75889 00280
6
5
M
M
INI
IX VI
Rolls Corporation
Salt Lake City, UT
10/18
MX28
Mini-Mix VI
L
1
R
R
MADE IN USA
www.rolls.com
LEVEL
LEVEL
1
2
BAL
BAL

SPECIFICATIONS

10K Ω
Input Impedance:
100 Ω
Output Impedance:
Max Gain:
+27 dBV
Max Input Level: +30 dBV
Max Output Level:
+13 dB
Frequency Response:
20Hz - 20kHz +/- 1 dBV
THD + Noise:
<.005%
Power:
12 VDC 150 mA adapter (center negative)
Weight:
1.2 lbs. (.49 Kg)
Size:
4.25" x 1.75" x 4.5" (WxHxD)
DC IN
L
L
L
2
3
12 - 16
OUTPUT
VDC
R
R
STEREO
MINI-MIX VI
MX28
LEVEL
3
MASTER
HEADPHONE
LEVEL
LEVEL
BAL
Owners Manual
