- Page 1 Pro USB AC Adapter WiFi Hidden Camera User’s Guide...
- Page 2 In the Box: In the box you’ll find the Pro USB AC Adapter WiFi Hidden Camera and this User’s Guide. Camera...
- Page 3 SD card Usb Port SD Cover...
-
Page 4: Getting Started
Getting Started The first step in using the Pro USB AC Adapter WiFi Hidden Camera is to remove the back cover of the device and insert a microSD card. Insert the card with the gold contacts facing downward; if inserted properly you will hear and feel a spring click. - Page 5 Navigating the Mobile Application The free “Fuvision” application is compatible with both iOS and Android devices. After you’ve downloaded and opened the app, follow the in-app instructions to register an account. This information will help you retrieve your password if it’s lost or forgotten. The default password for your device will be “9999”.
- Page 6 Now that your account is registered, you will open your smartphone or tablet’s WiFi settings. From here you will locate the Pro USB AC Adapter WiFi Hidden Camera device name: “ETxxxxxxxxxxxxxx” (with the X’s representing a unique combination of numbers and letters specific to your camera). Select this network and connect.
- Page 7 You are now connected to the camera’s WiFi Wireless Hotspot Network. By connecting to your camera through its WiFi hotspot connection (known as “Direct Connect”), you’re able to view your video locally within 100 feet of the device. Now that you are in a Direct Connect with your device, you can open the Fuvision app again.
- Page 8 Log in to the app by using the email address and default password that you originally registered with. Your camera will appear online. Configuring a LAN (Local Area Network) Connection To configure your device to your wireless network you will select the settings cog wheel.
- Page 9 Select the the Wi-Fi button to turn on the WiFi receiver, and then select the icon located next to the SSID. Choose your wireless network and enter your network password. Select “Save” in the upper right-hand corner. Your camera will reboot—wait 60 seconds and then refresh the page by pulling down on the screen.
- Page 10 LAN typically means a wired network connection while WLAN is used to refer to a wireless network. In LAN mode you can view recorded video directly from the mobile application. You can also select to record or take a photo manually from the application.
- Page 11 Configuring a WLAN (Wireless Local Area Network) Connection Now that you are connected to your wireless LAN you can set the camera to WLAN mode. In WLAN mode you can remotely view your camera from anywhere. You can also manually record video or photos directly from the Fuvision application.
- Page 12 Select the blue, circled exclamation point icon next to your camera on the main screen—you will be prompted to add your camera to your account; this will allow your camera to function wirelessly so you can remotely view your video feed.
- Page 13 Adjusting Your Camera Information To change your camera information settings, select the cog wheel on the main screen; from here you will be able to access the menu settings. Alias: The camera’s current name will be listed as the camera ID (ex: Camera ET890xxxxx).
- Page 14 Record Mode: Choose between Continuous record or Motion Detection to select how your camera is triggered. is not an active option. Turn Off mode will prevent your camera from recording any video. Format SD-Card: Make sure the microSD card is properly inserted before selecting this option.
- Page 15 camera will begin to record when sound is detected. Voice Sensitivity: Choose High, Middle or Low. Again, we recommend the Middle setting. Note: The FTP and Email Settings options are not available for this device. Navigating the Bottom Menu Selections In the bottom of your app menu there are four selection options: Device, Albums, Events, and More.
- Page 16 • Video Playback & Download from SD Card can only be accessed in LAN mode. • To access video playback or enable a download, select the Play Button icon located next to the Cog Wheel icon below your camera’s name. All recorded saved files will appear in this menu;...
- Page 17 reset the device by pressing and holding the reset button for four seconds. Wait two minutes for the device hotspot to transmit the camera’s ID. Problem: I forgot my password. Solution: Simply select “Forget password” from the main login menu; an email with a temporary password will be sent to the email address with which you registered the device.
