ALFATRON ALF-5/10/12/20X-CAM
ALFATRON ALF-5X/10X/12X/20X-CAM
HD Color Video Camera
ALFATRON ELECTRONICS GmbH GERMANY
User Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALF-5X-CAM and is the answer not in the manual?

Questions and answers

Related Manuals for ALFAtron ALF-5X-CAM

Summary of Contents for ALFAtron ALF-5X-CAM

  • Page 1 ALFATRON ALF-5/10/12/20X-CAM ALFATRON ALF-5X/10X/12X/20X-CAM HD Color Video Camera ALFATRON ELECTRONICS GmbH GERMANY User Manual...
  • Page 2 ALFATRON ALF-5/10/12/20X-CAM Attention Electrical Safety Installation and operation must comply with electrical safety standards Caution while in transportation Avoid stress, vibration, and soakage in transportation, storage, and installation. The polarity of power supply The power supply of the product is ±12V, the max electrical current is 2A. The polarity of the power supply drawing.

  • Page 3: Table Of Contents

    ALFATRON ALF-5/10/12/20X-CAM Content 1. Fast Installation ................................. 5 1.1 Camera Interface Explanation ......................... 5 1.2 Power-on Initial Configuration ........................5 1.3 Video Output .............................. 5-6 2. Product Overview 2.1 Product Introduction............................9 2.1.1 Product Model ............................. 9 2.1.2 Dimension………………………………......................10 2.1.3 Accessory ............................10...
  • Page 4 ALFATRON ALF-5/10/12/20X-CAM...

  • Page 5: Fast Installation

    ALFATRON ALF-5/10/12/20X-CAM 1. Fast Installation 1.1 Camera Interface Explanation (USB2.0, USB3.0, HDMI Output) 1 Lens 5 Tripod Screw Hole HDMI Output 2. Base 6 RS232 (IN) 10 LAN 3 Remote Controller Receiver Light 7 USB2.0 11 Power Supply 4 Button Dial Switch 8 USB3.0...
  • Page 6 ALFATRON ALF-5/10/12/20X-CAM 5) USB3.0 compatible with USB2.0 output a. USB3.0 video cable connection b. Connect the camera and the monitor via USB3.0 video cable, open video display software, select image device, and then video output will be available. 6) USB2.0 video output a.
  • Page 7 ALFATRON ALF-5/10/12/20X-CAM 2. Upside down mount step...
  • Page 8 ALFATRON ALF-5/10/12/20X-CAM...

  • Page 9: Product Overview

    ALFATRON ALF-5/10/12/20X-CAM 2. Product overview 2.1 Product Introduction 2.1.1 Product Model Model NO.X—XXX—XXX—XX IR ---IR Remote Controller WR---Wireless Remote Controller U2U3 - USB3.0, USB2.0, HDMI 05---05x Optical Zoom Lens 10---10 x Optical Zoom Lens 12---12x Optical Zoom Lens 20---20x Optical Zoom Lens...

  • Page 10: Dimension

    ALFATRON ALF-5/10/12/20X-CAM 2.1.2 Dimension Figure 2.2 Camera dimension 2.1.3 Accessory When you unpack, check that all the supplied accessories are included: Model Configur 5X-10X-12X-20X ation Power adapter 1 piece USB3.0 and USB2.0 cables User manual 1 Standard Double-side glue shim 4pcs...

  • Page 11: Main Features

    ALFATRON ALF-5/10/12/20X-CAM 2.2 Main Features 2.2.1 Camera Performance The features include advanced ISP processing algorithms to provide vivid images with a strong sense of depth, high resolution, and fantastic color rendition. It supports H.265/H.264 encoding which makes motion video fluent and clear even with less than ideal bandwidth conditions.
  • Page 12 ALFATRON ALF-5/10/12/20X-CAM Video Format HDMI/ video format 1080P60/50/30/25/59.94/29.97;1080I60/50/59.94;720P60/50/30/25/59.94/29.97 interface video format 1)1920X1080P60/50/30/25;1280X720P60/50/30/25;960X540P30;640X360P30;640X480P30;352X 288P30;960X540P30; Optical Zoom f＝3.6～18mm f＝4.7～47mm f ＝ 3.9 ～ f＝5.2～98mm 46.1mm View Angle 16.43°（tele） 6.43°（tele） 6.3°（tele） 3.2°（tele） 80.9°（wide） 60.9°（wide） 72.5°（wide） 55.8°（wide） F1.8 – F2.8 F1.6 – F3.0 F1.8 – F2.4 F1.5 –...

  • Page 13: Interface Instruction

    ALFATRON ALF-5/10/12/20X-CAM Optional Accessory Bracket 2.4 Interface Instruction 2.4.1 External Interface RS232 input, USB3.0, USB2.0, HDMI, LAN, The external interface of the ALF-5/10/12/20/30X-CAM model: DC12V power interface. 2.4.2 Bottom Dial Switch ALF-5/10/12/20X-CAM: two DIP switches are set to ON or OFF to select different modes of operation as shown in Table 2.3 Table 2.3 Dial Switch setting...

  • Page 14: Rs-232 Interface

    ALFATRON ALF-5/10/12/20X-CAM 2) RS-232 Mini-DIN 8-pin Port Definition Port Definition Data Terminal Ready Data Set Ready Transmit Data System Ground Receive Data System Ground IR Commander Signal IR OUT No Connection 3) RS232 (DB9) Port Definition Definition Port Data Carrier Detect...

  • Page 15: Application Instruction

    ALFATRON ALF-5/10/12/20X-CAM 3. Application Instruction 3.1 Video Output 3.1.1 Power-On Initial Configuration Connecting the power, the camera will have initial configuration, R indicator light will be flashing. When the camera return to the HOME position (middle position for P/T), and lens finish zoom in/out, the auto-testing is finished. IR led will also stop flashing. If the preset 0 is set, the camera will rotate to the 0 preset positions after the initial configuration.

  • Page 16: Remote Controller

    ALFATRON ALF-5/10/12/20X-CAM 3.2 Remote Controller 3.2.1 Keys Instruction 1. Standby Key After a 3S long press, the camera will step into standby mode. Long press 3S again, the camera will self-test again and back to the HOME position. (Note: If power-on mode is turned on and Preset 0 is set, and there is no operation within 12s, it will automatically point to the specified preset position.
  • Page 17 ALFATRON ALF-5/10/12/20X-CAM 3.2.2 Applications Finishing initialization, it can receive and execute the IR commands. Press the remote controller button, the indicator light is flashing; release the button, the indicator light stops flashing. Users can control the pan/tilt/zoom, setting and running preset positions via the IR remote controller.

  • Page 18: Menu Setting

    ALFATRON ALF-5/10/12/20X-CAM BLC ON / OFF: support 6) Presets Setting, Running, Clearing 1. Preset setting: to set a preset position, the users should press the “【SET PRESET】” key first and then press the number key 0-9 to set a relative preset, Note: 10 preset positions in total are available by remote controller.
  • Page 19 ALFATRON ALF-5/10/12/20X-CAM SETUP: System setting CAMERA OPTION: Camera setting PTZ OPTION: Pan tilt setting VERSION: camera version setting Restore Default: Reset setting [↑↓] Select: for selecting the menu [← →] Change Value: for modifying parameters [MENU] Back: Press [MENU] to return [Home] OK: Press [Home] to confirm 3.3.2 System Setting...
  • Page 20 ALFATRON ALF-5/10/12/20X-CAM Focus: Enter into focus setting Noise Reduction: Enter into noise reduction 1) EXPOSURE SETTING Move the pointer to the (EXPOSURE) in the Main Menu, click the【HOME】and enter the (EXPOSURE SET) as follow, EXPOSURE ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ Mode Auto Anti-Flicker 50Hz Gain Limit [↑↓]Select [←...
  • Page 21 ALFATRON ALF-5/10/12/20X-CAM 3000K、3500K、4000K、4500K、5000K、5500K、6000K、6500K、7000K WB Mode: Auto, , Manual, One Push Red Gain: 0~255(only available in Manual mode) Blue Gain: 0~255(only available in Manual mode) Saturation: 60%,70%,80%,90%,100%,110%,120%,130% Hue: 0~14 AWB Sensitivity: high/middle/low Color Style: Default, style1~4. Color Temp: high/middle/low 3) IMAGE Move the pointer to the (IMAGE) in the Menu, click the【HOME】and enter the (IMAGE) as follow,...
  • Page 22 ALFATRON ALF-5/10/12/20X-CAM 5) NOISE REDUCTION Move the pointer to the (NOISE REDUCTION) in the Menu, click the【HOME】and enter the (NOISE REDUCTION) as follow, NOISE REDUCTION ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ NR-2D Auto NR-3D Dynamic Hot Pixel [↑↓]Select [← →]Change Value 2D Noise Reduction: Auto, close, 1~7...
  • Page 23 ALFATRON ALF-5/10/12/20X-CAM VIDEO FORMAT ＝＝＝＝＝＝＝＝＝＝＝＝＝＝＝ 1080P60 1080P50 1080I60 1080I50 1080P30 1080P25 720P60 720P50 720P30 720P25 1080P59.94 1080I59.94 1080P29.97 720P59.94 720P29.97 ]Select ↑ ↓ [Menu]Back Note: 1. S: 1080P60 Downward Compatibility; M: 1080P30 Downward Compatibility 2. Exit menu after modifying parameter to save it after powered off S Version：1080P60，1080P50、1080P30、1080P25、1080I60、1080I50、720P60、720P50、720P30、...

  • Page 24: Network Connection

    ALFATRON ALF-5/10/12/20X-CAM Note: If the address of former remoter is not 1 but another one from 2,3,4, the corresponding camera address will restore to 1 when all parameters or system parameters are restored. User should change the remoter address to be 1 (press No.1 according to the camera so to get normal operation ) 4.
  • Page 25 ALFATRON ALF-5/10/12/20X-CAM Note: The IP address to be added cannot be the same as that of other computers or devices. The existence of this IP address needs to be verified before adding. Click the “Start” and select “Operation” to input cmd as the picture below to verify if the network segment has been successfully...
  • Page 26 ALFATRON ALF-5/10/12/20X-CAM Click “OK” and open the DOS command window, input ping 192.168.5.26 and press Enter key, it will show the message as below: which means network segment adding is succeeded. Users can verify network connection as steps above mentioned after the finish of the camera self-check. If IP is the default, open the DOS command window and input 192.168.5.163, then press Enter key.

  • Page 27: Ie Log In

    ALFATRON ALF-5/10/12/20X-CAM 4.2 IE Log In 4.2.1 Web client 1) Web client Log In Input the IP address 192.168.5.163 of the device in the address field of browser and click Enter button to enter into Web Client login page as below picture. User can log in as administrator and normal user. If login as the administrator (Default User name/Password: admin), users can preview, playback, configuration and cancel in the Web Client;...
  • Page 28 ALFATRON ALF-5/10/12/20X-CAM Including audio compressing format, sampling frequency, sampling precision, compressing code rate Audio configure settings, etc. Including video encoding,video parameters,character-overlapping,character size,video output Video configure setting etc. Network configure Including basic parameters, Ethernet, DNS, wireless network setting, GB28181, etc. Including equipment property,system time,user management,version update,Reset,Reboot device System configure settings etc.
  • Page 29 ALFATRON ALF-5/10/12/20X-CAM Protocol：RTP or TS Address：Default 224.1.2.3. It can be edited. Port：Main Stream Default Port: 4000，Sub Stream Default Port: 4002） Visit：Address comes up after setting. Eg; RTP://224.1.2.3:4000；udp://@224.1.2.3:4000； 3) Video Parameters a Focus: Focus mode, focus range, focus sensitivity can be set.
  • Page 30 ALFATRON ALF-5/10/12/20X-CAM Title Content: Set title content (default CAMERA1). Time Content: Set time content (default 1970/01/10 05:36:00) Click on the "Save" button and display the "Save successful" message, then valid 5)Character Size Mainstream character size: Set the character size of the display, the device will restart...
  • Page 31 ALFATRON ALF-5/10/12/20X-CAM Alarm Zone: Users can add their own Equipment installation address: Users can add their own Local SIP Port: 5060 Range 0-65535 GB28181 Server Address: IP address of the computer Server SIP Port: 5060 Range 0-65535 Server ID: 34020000002000000001 Click on the "Save"...

  • Page 32: Serial Communication Control

    ALFATRON ALF-5/10/12/20X-CAM 4.2.8 Logout Point "Logout" pop-up "Confirmation" dialog; select "Yes" or "No", choose “Yes” to exit the current page and return to the user login interface again. 4.2.9 Wireless network If the user's equipment has a wireless network module, Web page "Network Configuration" has "Wireless Network"...
  • Page 33 ALFATRON ALF-5/10/12/20X-CAM Command packet Note Returned when the command format is different or when a Syntax Error z0 60 02 FF command with illegal command parameters is accepted Returned when a command cannot be executed due to current Command Not Executable z0 61 41 FF conditions.
  • Page 34 ALFATRON ALF-5/10/12/20X-CAM Command Function Command packet Note Down 8x 01 04 04 03 FF Direct 8x 01 04 44 00 00 0p 0q FF pq: B Gain Full Auto 8x 01 04 39 00 FF Automatic Exposure mode Manual 8x 01 04 39 03 FF...
  • Page 35 ALFATRON ALF-5/10/12/20X-CAM Command Function Command packet Note 8x 01 04 66 03 FF P=0-7 CAM_ColorSaturation Direct 8x 01 04 49 00 00 00 0p FF 0:60% 1:70% 2:80% 3:90% 4:100% 5:110% 6:120% 7:130% CAM_IDWrite 8x 01 04 22 0p 0q 0r 0s FF...
  • Page 36 ALFATRON ALF-5/10/12/20X-CAM y0 50 01 FF 3000K y0 50 02 FF 4000K y0 50 03 FF One Push Mode y0 50 04 FF 5000K y0 50 05 FF Manual y0 50 00 FF 6500K y0 50 06 FF 6500K y0 50 07 FF...

  • Page 37: Pelco-D Protocol Command List

    ALFATRON ALF-5/10/12/20X-CAM ab cd: vender ID ( 0220 ) mn pq: y0 50 ab cd CAM_VersionInq 8x 09 00 02 FF （3950） mn PQ rs tu vw FF rs tu: ARM Version reserve P: 0~E Video format 0:1080P60 8:720P30 1:1080P50...

  • Page 38: Pelco-P Protocol Command List

    ALFATRON ALF-5/10/12/20X-CAM Response Byte Byte 5.3 Pelco-P protocol command list Function Byte1 Byte2 Byte3 Byte4 Byte5 Byte6 Byte7 Byte8 0xA0 Address 0x00 0x08 Pan Speed Tilt Speed 0xAF Down 0xA0 Address 0x00 0x10 Pan Speed Tilt Speed 0xAF Left 0xA0...
  • Page 39 ALFATRON ALF-5/10/12/20X-CAM b, Whether the machine could do self-inspection after restarted. c, Check whether the bottom of the DIP switch is the normal operating mode d, Check whether the video output cable or video display is normal 2) No image sometimes ——a, Check whether the video output cable or video display is normal...

  • Page 40: Warranty

    ALFATRON ALF-5/10/12/20X-CAM 1. Limited warranty in respect of Alfatron Products Only 1.1 This limited warranty covers defects in materials and workmanship in this product. 1.2 Should warranty service be required, proof of purchase must be presented to the Company. The serial number on the product must be clearly visible and not have been tampered with in any way whatsoever.
  • Page 41 ALFATRON ALF-5/10/12/20X-CAM 1.15 Any claim by the Customer which is based on any defect in the quality or condition of the goods or their failure to correspond with specification shall be notified in writing to the Company within 7 days of deliver or (where the defect or failure was not apparent on reasonable inspection by the Customer) within a reasonable time after discovery of the defect or failure, but, in any event, within 6 months of delivery.
  • Page 42 ALFATRON ALF-5/10/12/20X-CAM...
