Tripp Lite SUPDM15 Specifications

Model #: SUPDM15
Corded UPS Backplate Outlet Kit - Adds AC plug-in connection and AC output receptacles to SU6000RT3U
and SU6000RT3UXR UPS for use with 240V UPS output voltage configurations
Description
Tripp Lite's SUPDM15 corded backplate kit converts Tripp Lite's hardwire SU6000RT3U or SU6000RT3UXR UPS system into one with AC plug and
outlets. 10 ft./3m input line cord with L6-30P plug enables simple connection to 240V 30A mains power. Includes 3 L6-30R and 10 5-15/20R output
receptacles. Easy quick-connect wiring installs in minutes.
VOLTAGE COMPATIBILITY NOTE - SUPDM15 supports SU6000RT3U and SU6000RT3UXR applications configured for 240V nominal input
voltage only (See SUPDM16 for 208V input voltage configurations).
Applications
Ideal for 240V applications calling for Tripp Lite's SU6000RT3U and SU6000RT3UXR UPS systems where plug-in AC input and output
connections are required
Features
Converts Tripp Lite's hardwire SU6000RT3U or SU6000RT3UXR UPS system to one with an AC plug and outlets
10 ft./3m AC line cord with L6-30P input plug-in connection
Includes 3 L6-30R and 10 5-15/20R output receptacles
Easy quick-connect wiring installs in minutes
Specifications
OVERVIEW
Model Type
OUTPUT
Output nominal voltage
Overload protection
Outlet quantity / type
Highlights
Outlet Kits
Simultaneous 240 and 120V output
120V outlets are protected by 2 separate 20A branch rated circuit breakers
240V: 3 L6-30R / 120V: 10 5-15/20R
Converts Tripp Lite's hardwire SU6000RT3U UPS systems to one with AC
plug and outlets
For use with 240V mains and UPS output voltage configurations
10 ft. / 3m AC input power cable with NEMA L6-30P input plug
3 L6-30R and 10 5-15/20R output receptacles
Easy quick-connect wiring installs in minutes
