Tripp Lite SmartOnline SU750XL Specifications

Model #: SU750XL
SmartOnline .75kVA On-Line Double-Conversion UPS, Tower, 100/110/120V NEMA outlets
Description
The SU750XL on-line, double-conversion UPS protects critical server, networking or telecommunications equipment from blackouts, brownouts,
voltage fluctuations and surges. Large-capacity 750VA/600W UPS continuously converts incoming AC to DC, then back to perfect sine wave AC
output at 120V AC (+/-2%). Removes harmonic distortion, fast electrical impulses, frequency fluctuations and other hard-to-solve power problems not
addressed by other UPS systems. True sine wave output and zero transfer time offer guaranteed compatibility with all equipment types. Includes 6
UPS supported outlets; 2 single-outlet load banks can be independently controlled via a software interface to selectively reboot remote equipment or
shed less critical loads to extend battery runtime for the most critical equipment. Extended runtime available with optional BP24V15RT2U,
BP24V28-2U, or BP24V70-3U external battery packs. Includes slot for internal SNMP/WEB card, plus DB9 enhanced serial monitoring port for
unattended shutdown, remote control and monitoring of UPS system and power data. Includes USB and DB9 serial ports. Built-in DB9 port offers
both enhanced RS-232 enabled monitoring data, plus contact closure monitoring ability. HID-compliant USB interface enables integration with
built-in power management and auto shutdown features of Windows and Mac OS X. Includes Tripp Lite's PowerAlert UPS power management
software. Compatible with Tripp Lite's Watchdog service monitoring/rebooting software. Upright tower form factor; attractive all-black color scheme.
Package Includes
SU750XL UPS System
PowerAlert Software CD and cabling
EPO (Emergency Power Off) cabling
Owner's manual with warranty information
Features
True on-line, double-conversion UPS provides constant, pure sine wave AC output
Maintains continuous operation with zero transfer time through blackouts, brownouts, voltage fluctuations and surges
Removes harmonic distortion, electrical impulses, frequency variations and other hard-to-solve power problems
Accepts input voltages between 80-150V (65-150V at loads under 70%), regulating output to 120V AC +/-2%
750VA/600W output capacity with 6 x NEMA5-15R outlets
Two built-in individually switchable load banks can be controlled via software interface to selectively reboot remote equipment or shed less
critical loads to extend battery runtime for the most critical equipment (1 outlet per bank)
Standard internal battery set provides 11 min. runtime at half load and 4 min. at full load
Extended runtime available with optional BP24V15RT2U, BP24V28-2U, or BP24V70-3U external battery packs
Some external battery configurations require the use of Tripp Lite's
Highlights
750VA / .75kVA / 600 watt on-line double-conversion tower UPS
100/110/120V +/-2% output at 50/60Hz, high efficiency economy mode option
Expandable runtime, Hot-swappable battery modules
USB, RS232 & EPO ports; support for SNMP/WEB card options
Front panel status LEDs with detailed load and battery metering
2 independently switchable output load banks
NEMA 5-15P input; 5-15R outlets
External Battery Configuration Software
