Tripp Lite SmartOnline SU6000RT3UHV Specifications

Model #: SU6000RT3UHV
SmartOnline 6kVA On-Line Double-Conversion UPS, 6U Rack/Tower, 200-240V Hardwire output
Description
Tripp Lite Smart Online UPS systems offer high performance power protection ideal for critical server and network equipment in datacenters,
computer rooms and network closets. Online, double-conversion Uninterruptible Power Supply (UPS) maintains perfectly regulated output power by
continuously converting raw AC input to DC, then re-converting output back to AC. Fully regulated sine wave AC output with +/-2% voltage regulation
powers network equipment continuously, even during severe brownouts and overvoltages, all without depleting UPS battery reserves. Maintains
battery-derived AC output during power failures with zero transfer time. Extended runtime options available. Interactive LCD interface reports UPS
operating mode, detailed UPS and site-power data, plus enables a variety of UPS setup and configuration options. Highly efficient operation in
optional economy mode saves BTU heat output and energy costs. Network management interfaces support communications via RS-232,
contact-closure and optional SNMPWEBCARD network interface. Built-in DB9 port offers both enhanced RS-232 data and basic contact closure
monitoring ability. Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. LED display reports UPS
operating mode, line power availability, battery mode operation, inverter operation, ECO mode status and output power availability. Audible alarm
with push-button momentary alarm-cancel and silent-mode LCD configuration options. Programmable self-test. Fault-tolerant auto-bypass mode.
Field-replaceable, hot-swappable internal batteries and external battery packs.
Package Includes
SU6000RT3UPM 3U Power Module
BP240V7RT3U non-expandable 3U battery pack
PowerAlert software and complete cabling
Complete mounting hardware for 4 post rack installation
2-9USTAND tower stand set
Warranty information
Instruction manual
Features
True on-line, double conversion UPS provides pure, sine wave AC output at all times
World-wide compatibility with Euro 50Hz and High Voltage North American 60Hz power
Maintains continuous operation through blackouts, voltage fluctuations and surges with zero transfer time
Removes harmonic distortion, electrical impulses, frequency variations and other hard to solve power problems
6000VA/4200 watt power capacity with hardwire input/output connections
Accepts input voltages between 156 and 276, regulating output within 2% of selectable 200/208/220/230/240v AC output
20 minutes runtime at half load (2100W) / 8 minutes at full load (4200W) with included BP240V7RT3U external battery pack
Expandable runtime with multiple external battery packs
Innovative design makes unit adaptable for rackmount, tower, or stacking applications
Power module and battery pack require only 3 rack spaces each (6U total rack space usage)
DB9 serial port for network interface; SNMP compatible
Slot for optional SNMP/web card (part# SNMPWEBCARD)
Highlights
6000VA / 6kVA / 4200W on-line double-conversion UPS
200/208/220/230/240V 50/60Hz output, Economy mode option
6U Rack/Tower compatible; Hot-swappable battery modules
RS232 & EPO ports; support for SNMP/WEB card options
Front panel LEDs with detailed LCD monitoring and control screen
Ships with standard capacity BP240V7RT3U battery pack
Hardwire input (3 wire); Hardwire output
