Model #: SU20K3/3
SmartOnline 20kVA On-Line Double-Conversion UPS, 3 Phase input / output
Description
Tripp Lite's SU20K3/3 20kVA SmartOnline 3-Phase Intelligent, True On-Line UPS System has been redesigned to save valuable space and simplify
runtime scalability. Power and battery components are combined into a single, small-footprint module (the smallest in its class). A robust internal
battery runtime capability can be easily extended by installing additional optional internal battery packs through the convenient front panel access
door.
The SU20K3/3 provides mission-critical equipment with the highest level of power protection available. Large capacity 20,000VA/16,000 watt UPS
continually converts incoming AC power into filtered DC power, and then resynthesizes it back into AC power with a pure sine wave. Perfectly
regulated, continuous sine wave output with zero transfer time offers compatibility with all equipment types. IGBT inverter technology produces
output power with <3% THD (total harmonic distortion), allowing connected equipment to perform at its peak. A 3:1 crest factor safely supports a
variety of equipment, even those with wildly-fluctuating power demands. Extremely efficient operation saves money by lowering electricity
consumption. Hardwire input and output connections support a variety of permanent or PDU style power connections. SU20K3/3 features 120/208V
AC, 3-phase, 4-wire (plus ground), wye input and output. It also features a wide input voltage correction range: 96-144/166-250V AC. Frequency is
50 or 60 Hz (auto-selectable). SU20K3/3 includes internal power and battery components in a single small-footprint tower module. Battery support
can be extended with additional internal battery packs. A manual bypass switch as well as an automatic bypass function ensure 100% availability of
connected equipment by safely passing through AC power when the UPS requires maintenance. Three built-in communication ports (RS-232,
contact closure and AS-400) work with included PowerAlert Software to simultaneously provide shutdown commands and reporting on multiple
servers without the need for costly accessories. An accessory slot accepts an optional internal SNMP card (model # SNMPWEBCARD) for remote
shutdowns, reboots and more. A Battery Start Switch allows cold restart of UPS during a prolonged blackout to utilize its batteries for periodic
system access or data retrieval. An Emergency Power Off button turns UPS output OFF and disables Bypass output. Built-in Emergency Power Off
(EPO) interface supports remote emergency shutdown in large facilities. Front panel combination LCD/LED display alerts users to a variety of UPS
operational modes and conditions. A start-up service program is recommended to enhance the reliability of the installation.
Package Includes
SU20K3/3 UPS System (power and battery components in one module)
PowerAlert Software and cabling
Warranty information
Instruction manual
Highlights
20,000 VA (20kVA) tower UPS with internal batteries
Saves valuable space: power and battery components combined into a single
small-footprint module
Simplifies runtime scalability: convenient front panel battery access for
expandable runtime with additional internal battery packs
3-phase hardwire input and output (120/208VAC). Wide input voltage
correction range (96 - 144V AC / 166 - 250V AC)
IGBT technology and zero transfer time, on-line, double-conversion operation
3 communication ports, SNMP card slot and EPO jack
Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +(773) 869 1234
E-mail:
saleshelp@tripplite.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SmartOnline SU20K3/3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tripp Lite SmartOnline SU20K3/3

  • Page 1 Description Tripp Lite's SU20K3/3 20kVA SmartOnline 3-Phase Intelligent, True On-Line UPS System has been redesigned to save valuable space and simplify runtime scalability. Power and battery components are combined into a single, small-footprint module (the smallest in its class). A robust internal battery runtime capability can be easily extended by installing additional optional internal battery packs through the convenient front panel access door.
  • Page 2 3:1 crest factor safely supports a variety of equipment, even those with wildly-fluctuating power demands Extend runtime by installing optional internal battery packs (model # SURBC2030) through the front panel access door. SU20K3/3 includes 2 internal battery packs and accepts 2 additional internal battery packs. A standalone battery module compartment with a 4 battery pack capacity and daisy-chain capability (model # SUBF2030) is available to further extend runtime.
  • Page 3 Output AC Pure Sine wave waveform (battery mode) INPUT Rated input current (at maximum load) Nominal Input 120V / 208V 3 phase wye Voltage(s) Supported UPS input Hardwire connection type UPS input 120/208V (3-Phase, 4 Wire, wye) connection description BATTERY Full load runtime 5 min.
  • Page 4 Front panel LCD SELECTABLE LCD DISPLAY: indicates a wide range of UPS operational and fault/warning conditions including display operational mode, alarm/shutdown conditions, input/output voltage/frequency, battery voltage, load percentage and more (see manual) Alarms Alarms warn against a variety of operational conditions: low-battery, overload, shutdown, bypass and more Alarm cancel Power-fail alarm can be silenced using alarm-cancel switch operation...
  • Page 5 UPS Shipping 111.5 x 71.1 x 113 dimensions (height x width x depth / Shipping weight 607.2 (lbs) Shipping weight 273.2 (kg) UPS housing Steel material Cooling method Fans ENVIRONMENTAL Operating +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius Temperature Range Storage +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius...
  • Page 6 External Battery Frame for Extended Runtime - Compatible with Select SmartOnline 20kVA & 30kVA 3-Phase UPS System External battery pack for use with select Tripp Lite UPS Systems External battery pack for use with select Tripp Lite UPS Systems External battery pack for use with select Tripp Lite UPS Systems...
  • Page 7 Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
